A 105-inch 21:9 interactive display running at 5120x2160, sized to replace a screen-plus-whiteboard pair in a meeting room and to show a video call and shared content side by side.
TopAV buying advice
Is the ViewSonic IFP105UW right for your meeting room?
One ultra-wide panel instead of a screen next to a whiteboard.
Shortlist this for a meeting room or a board room where two things need to be on screen at once: a video call on one side and a document or a whiteboard on the other. Read the shape carefully before you plan the wall. This panel is 21:9, not 16:9, and its active area is 2449.92 mm wide by 1033.56 mm high, so it is wider and shorter than a 16:9 panel of the same diagonal. Screen-size guidance, wall visualisers and diagonal-to-width rules of thumb written for 16:9 displays will overstate its height and understate its width. Measure the wall against 2507.2 mm of chassis width and 1130.1 mm of height, and check that a 21:9 layout suits the content you actually show: a single full-screen 16:9 video will letterbox with unused area at each side.
Reasons to shortlist it
- 5120x2160 across a 21:9 panel, which is 1280 more horizontal pixels than a 3840x2160 display, so two documents or a call and a document sit side by side at full width each.
- 2449.92 mm of active width in a single panel, replacing the screen-plus-whiteboard pair that a room this size usually carries on two separate walls.
- 40 touch points under Windows through the OPS slot, or 20 under the built-in Android 13 system, using an infrared touch layer.
- A built-in 8-microphone array and a 2.1-channel speaker system of two 16W front drivers and a 15W subwoofer, so a meeting room needs no separate conferencing mic for speech.
- Two RJ45 ports wired as one in and one out, plus seven USB-A ports and four HDMI inputs, so a room system, a laptop input and a fixed PC can all stay connected.
Check before you choose
- The built-in Android system reads 20 touch points, not the 40 ViewSonic quotes; 40 applies under Windows through a slot-in PC. If you need the higher figure, budget for the OPS module.
- Single-cable laptop connection is on the rear USB-C port at 65W with a slot-in PC fitted. The front USB-C port delivers 15W, so it will not charge a laptop.
- At 91.4 kg net and 116.1 kg boxed, on a 2507.2 mm wide chassis, delivery and mounting need planning before you order. Confirm the access route, the wall or structure, and the mount rating.
What to plan before installing the IFP105UW
01
Shape & wall space
This is a 21:9 panel, so measure the wall against 2507.2 mm of width and 1130.1 mm of height rather than converting the 105-inch diagonal with a 16:9 rule. Check the sightline to both ends of a panel this wide, not just the centre.
02
Delivery, mount & connections
The chassis weighs 91.4 kg net and 116.1 kg boxed. Check doorways, lifts and the access route, confirm the wall construction and mounting height, and plan power and data. ViewSonic rates it at 176W in use. ViewSonic lists a 1000 x 400 mm VESA pattern.
03
Software, PC & installation
Decide early whether a slot-in Windows PC is part of the room, because it changes both the touch-point count and the USB-C charging behaviour. Confirm the supplied software configuration with your IT team, and tell us if you need mounting, cabling, a PC or a camera.
Display price is for the panel. Installation and optional equipment are quoted separately. Purchase-order terms are available to approved education customers.
Build a quote you can compare
Include these details in your project enquiry so the quote covers the room as well as the screen.
- Number of displays, site postcode and required date.
- Furthest viewing distance and available wall space.
- Wall type, fixed mount or adjustable trolley, and cable routes.
- Laptop model, teaching apps, and any camera or Windows PC needs.
Ask for separate equipment, delivery, installation and licence costs, with a total including VAT. Confirm warranty coverage and any registration requirements before placing the order.
Complete your setup
What else the IFP105UW needs
The price above is for the display on its own. A wall mount or trolley is a separate purchase, and installation is quoted per site. Add what you need here and it joins the same basket.
Choose a mount
Professional Installation
Want it installed by our AV experts? We offer professional on-site installation including mounting, cable management, and system configuration.
ViewSonic IFP105UW specifications and documents
ViewSonic specifications (opens in a new tab)Choose a section to view its specifications.
Display (12)
- Panel Type
- TFT LCD Module with DLED Backlight, VA
- Display Area (mm)
- 2449.92(H) x 1033.56 (V) (104.6”diagonal)
- Aspect Ratio
- 21:9
- Viewing Angles
- H = 178, V = 178 (Typ.)
- Backlight Life
- 30,000 Hours (Min.)
- Panel Size
- 105"
- Resolution
- WUHD 5120x2160
- Brightness
- 400 nits (typ.)
- Contrast Ratio
- 4000:1 (typ.) / 5000:1 (max. with DCR enabled)
- Touch Points
- 40 (Windows) / 20 (Android)
- DisplayPort Input
- 1
- USB-B Touch Ports
- 3 (1 bottom, 2 rear)
Connectivity (7)
- HDMI Inputs
- 4 (3 rear HDMI 2.0 with CEC, 1 rear HDMI 2.1 with CEC)
- HDMI Output
- 1
- USB-C Ports
- 2 (rear: 65W PD with OPS fitted, DP 1.2, data, 10/100M sharing; front: 15W PD, DP 1.2, data, 10/100M sharing)
- USB-C Power Delivery
- 65 W (rear port, with OPS fitted)
- USB-A Ports
- 7 (6 x USB 3.2 Gen 1: 2 top, 2 rear, 2 front; 1 x USB 2.0 bottom)
- LAN
- 2 x RJ45 (1 in, 1 out)
- Audio Output
- Line out, SPDIF optical
Audio (2)
- Speakers
- 2 x 16W front + 15W subwoofer
- Microphone
- Built-in 8-microphone array
Power & Physical (6)
- Weight
- 91.4 kg
- Power Consumption
- 176 W on (Energy Star), under 0.5 W off
- Voltage
- 100-240V AC +/-10%
- VESA Mount
- 1000 x 400 mm
- Dimensions (W x H x D)
- 2507.2 x 1130.1 x 103.2 mm
- Gross Weight
- 116.1 kg
Certifications & Warranty (1)
- Warranty
- 5 years manufacturer
General (16)
- Response Time
- 6.5ms
- Surface Treatment
- Panel Hard Coating 3H
- Processor
- Octa-Core CPU (A76*4 + A55*4)
- Type/ Tech
- IR Recognition
- RAM
- 8GB LPDDR
- Storage
- 128GB eMMC
- Operating System
- Android 13
- OPS Slot
- Yes, 1 x OPS slot
- Light Sensor
- Yes
- Operating Temperature
- 0 to 40 °C
- Energy Star
- 8.0
- EPEAT
- Silver
- Bundled Software
- myViewBoard Whiteboard for Android, myViewBoard Display, vCast, AirSync, ViewSonic Manager, ViewSonic Launcher
- In the Box
- 2 x touch pens (VB-PEN-002), remote control with batteries, 3m HDMI cable, 1.8m USB-C cable, 3m USB touch cable, power cord, RS232 adapter, 5 x clamps, 2 x camera plates, 11 x screws, quick start guide
- Manufacturer part number
- IFP105UW
- GTIN
- 766907029048
Specifications are ViewSonic's published figures. Checked on 13 September 2026. The buying advice is our own, from specifying and installing equipment like this in UK classrooms and meeting rooms.
ViewSonic IFP105UW questions answered
Who is the ViewSonic IFP105UW best suited to?
Consider it for a meeting room or board room that needs a video call and shared content visible at the same time, or that currently uses a display on one wall and a whiteboard on another. The 21:9 shape is the reason to choose it; if you only ever show one full-screen source, a 16:9 panel uses the wall better.
What aspect ratio and resolution is the IFP105UW?
21:9 at 5120x2160, which ViewSonic labels WUHD. That is 1280 more horizontal pixels than a 3840x2160 display and the same 2160 vertical pixels, so the extra resolution buys width, not height.
Will a screen-size calculator built for 16:9 displays give the right answer here?
No. A 105-inch diagonal on a 21:9 panel is wider and shorter than a 105-inch 16:9 panel, so any calculator, wall visualiser or rule of thumb that assumes 16:9 will overstate the height and understate the width. Use the measured figures instead: 2449.92 mm by 1033.56 mm of active area, in a chassis 2507.2 mm wide and 1130.1 mm high.
How many touch points does the IFP105UW support?
40 under Windows and 20 under the built-in Android system, on an infrared touch layer. The 40-point figure needs a slot-in Windows PC in the OPS slot, so confirm which number applies to the way you plan to use the panel.
Can I connect a laptop with a single USB-C cable?
Yes, on the rear USB-C port, which carries DisplayPort 1.2, data, 10/100M network sharing and 65W of power delivery with a slot-in PC fitted. The front USB-C port is 15W and will not charge a laptop, so route the desk cable to the rear port.
How much RAM and storage does the ViewSonic IFP105UW have?
8GB of LPDDR memory and 128GB of eMMC storage, on an octa-core processor, as listed in ViewSonic's specification table for this model.
Which operating system does it run?
Android 13, with ViewSonic's own launcher and the myViewBoard, vCast and AirSync software. Check your app and device-management requirements against that version with your IT team before rollout, and treat a Windows slot-in PC as a separate decision.
What happens when someone shares a normal 16:9 video or slide deck?
It fills the height and leaves unused area at each side, because the panel is wider than 16:9. That is the expected behaviour and it is not a fault. The panel earns its shape when two sources are on screen together, so plan the room around side-by-side use.
Does it include a Windows PC or a video-call camera?
No. ViewSonic lists slot-in PCs and cameras as optional accessories; two camera plates are supplied in the box but not a camera. Ask for a quote that identifies the PC, camera and mounting hardware you need, and note that the PC also determines the touch-point count.
Can TopAV quote for installation on a panel this size?
Yes. Request a project quote for mounting, cabling and installation, which is quoted separately from the display. Send us the room dimensions, the wall construction and the access route, because at 91.4 kg on a 2.5 metre chassis those decide the mount and the labour.
How does the ViewSonic IFP105UW compare with a SMART Board or Clevertouch?
SMART builds its teaching workflow around SMART Notebook and Ink and Clevertouch around LYNX Whiteboard, while ViewSonic builds around myViewBoard, which on this model sits on a panel with a built-in 8-microphone array and 40 touch points under Windows. Our comparison guides use the ViewSonic IFP51 series as the reference, and this is a 105-inch 21:9 meeting-room panel rather than a 16:9 classroom one, so their size and shape guidance does not transfer. Our SMART Board vs ViewSonic and three-brand school comparison guides cover software, accounts and installed cost in detail.
Trusted by thousands of customers
Explore recent installations
See recent installations supplied by StriveAV, TopAV’s parent company. Customer names are masked for privacy.
Alternative products
Closest matches in this category on price and capability. Not sure which way to go? Our technical team will talk it through.
Avocor AVL-1050-T 105-inch 21:9 L Series Interactive Display
LG 105TR5WP-B 105" CreateBoard
ViewSonic ViewBoard IFP110, 110" 4K-UHD Interactive Display with Integrated Software
iiyama TE10518UWI-B1AG 105" 5K Signage Display
