ViewSonic · ViewBoard IFPG1 series
ViewSonic IFP86G1 86-inch 4K interactive display
ViewSonic Platinum Tier 1 Partner
We work closely with ViewSonic to secure competitive pricing for your project.
Buying multiple displays? Ask us for a tailored deal.
- Visa
- Mastercard
- American Express
- PayPal
Seen it cheaper? We price-match genuine like-for-like quotes. How it works
- In UK stock, ships from the UK
- UK manufacturer warranty
- UK-based engineers
- No import duty or customs charges
- GBP pricing, UK VAT invoices
An 86-inch 4K interactive display with no onboard operating system, driven by one USB-C cable from a presenter's laptop or by a Windows, Linux or EDLA slot-in PC in its OPS slot.
TopAV buying advice
Is the ViewSonic IFP86G1 right for your lecture theatre?
The big screen, with the computer left to you.
Shortlist this ViewBoard for a lecture space, a large training room or a boardroom where presenters arrive with their own laptop and the estate would rather not manage software on the screen itself. At 86 inches the back rows can read ordinary slide text, which is the main reason to step up from the smaller panels in the series. If the room also needs standalone whiteboarding, specify the slot-in PC at the same time.
Reasons to shortlist it
- 86 inches at 4K, so a full slide or a spreadsheet stays readable from the back of a deep room without enlarging the content.
- One USB-C cable carries video, touch and up to 65W of charge from a laptop, so a visiting presenter is connected and charging from a single lead.
- 40 touch points with a Windows source and 20 with an Android source, on an infrared Ultra Fine Touch layer, so a large panel still supports more than one person writing.
- An OPS slot takes a Windows, Linux, EDLA or Chromebox slot-in PC, so the computing half can be replaced on its own refresh cycle while the panel stays on the wall.
- Three rear HDMI 2.0 inputs, one of them with ARC, so a room's existing lectern and video sources keep working alongside a laptop.
Check before you choose
- Audio is two 15W speakers, which is not enough for a room this size. Treat a soundbar or ceiling speakers as part of the specification, not an upgrade.
- An 86-inch panel is heavy enough that wall construction, the mount rating and a multi-person lift all have to be confirmed before it is ordered. A trolley or a lift-assist mount is often the practical answer.
- With no connected device and no slot-in PC there is nothing on screen. If you need the display to whiteboard, cast or run apps standalone, the slot-in PC is not optional and must be quoted with it.
See the 86" on your wall, to scale
On a phone, point your camera at the wall and see the 86" there at its real size. On a computer, upload a photo of the wall (or scan the QR code to take one with your phone and it will appear here) and drag the display around it to scale.
Not sure 86" is the right size for the room? The screen size calculator shows how far a 86" display carries for presentations, touch work and video.
What to plan before installing the IFP86G1
01
Size & sightlines
Measure the longest viewing distance and confirm the whole panel is visible from the back rows without a head in the way.
02
Mount & connections
Check wall construction, the mount rating, mounting height, power and data. ViewSonic lists a 800 x 600 mm VESA pattern.
03
Source & installation
Decide whether presenters will connect their own laptops over USB-C or use a slot-in PC, and confirm which operating system that PC should run. Tell us if you need mounting, cabling, audio or a camera.
Display price is for the panel. Installation and optional equipment are quoted separately. Purchase-order terms are available to approved education customers.
Build a quote you can compare
Include these details in your project enquiry so the quote covers the room as well as the screen.
- Number of displays, site postcode and required date.
- Furthest viewing distance and available wall space.
- Wall type, fixed mount or adjustable trolley, and cable routes.
- Laptop model, teaching apps, and any camera or Windows PC needs.
Ask for separate equipment, delivery, installation and licence costs, with a total including VAT. Confirm warranty coverage and any registration requirements before placing the order.
Complete your setup
What else the IFP86G1 needs
The price above is for the display on its own. A wall mount or trolley is a separate purchase, and installation is quoted per site. Add what you need here and it joins the same basket.
Choose a mount
Professional Installation
Want it installed by our AV experts? We offer professional on-site installation including mounting, cable management, and system configuration.
Compare your shortlist
ViewSonic IFP86G1 vs IFP55G1: 86-inch or 55-inch?
Choose around the room and the content people need to read, not the model number.
| Feature | IFP86G1 | IFP55G1 |
|---|---|---|
| Panel Size | 86" | 55" |
| Resolution | UHD 3840x2160 | UHD 3840x2160 |
| Brightness | 450 nits | 450 nits |
| Touch Points | 40 (Windows) / 20 (Android) | 40 (Windows) / 20 (Android) |
| Speakers | 2 x 15W | 2 x 15W |
| USB-C Power Delivery | 65 W (USB-C port) | 65 W (USB-C port) |
| VESA Mount | 800 x 600 mm | 400 x 200 mm |
Specifications checked on 13 September 2026: ViewSonic IFP86G1 (opens in a new tab) and ViewSonic IFP55G1 (opens in a new tab). Buying advice is based on published specifications; confirm the supplied configuration for either model.
See this 86-inch display to scaleViewSonic IFP86G1 specifications and documents
ViewSonic specifications (opens in a new tab)Choose a section to view its specifications.
Display (9)
- Screen Size
- 86 in
- Contrast Ratio
- 4000:1 (6000:1 dynamic)
- Touch Technology
- Ultra Fine Touch (infrared recognition)
- Aspect Ratio
- 16:9
- Panel Type
- TFT LCD with DLED backlight
- Panel Size
- 86"
- Resolution
- UHD 3840x2160
- Brightness
- 450 nits
- Touch Points
- 40 (Windows) / 20 (Android)
Connectivity (3)
- HDMI Inputs
- 3 x HDMI 2.0 (rear; HDMI 1 and 3 with CEC, HDMI 2 with CEC and ARC)
- USB-C Ports
- 1 (DP 1.2, touch, data sharing, 65W PD, Ethernet 10/100)
- USB-C Power Delivery
- 65 W (USB-C port)
Audio (1)
- Speakers
- 2 x 15W
Power & Physical (2)
- Size Band
- 80 - 99"
- VESA Mount
- 800 x 600 mm
Certifications & Warranty (1)
- Warranty
- 5 years manufacturer
General (5)
- Operating System
- OS-free — bring your own device; accepts Windows, Linux, EDLA or Chromebox OPS slot-in PC
- Orientation
- Landscape
- OPS Slot
- Yes, 1 x PC slot
- Manufacturer part number
- IFP86G1
- GTIN
- 0766907024685
Specifications are ViewSonic's published figures. Checked on 13 September 2026. The buying advice is our own, from specifying and installing equipment like this in UK classrooms and meeting rooms.
ViewSonic IFP86G1 questions answered
Who is the ViewSonic IFP86G1 best suited to?
Consider it for a lecture theatre, a large training room or a boardroom where presenters bring their own laptop. It is the right choice when the software and the data should stay on the connected device rather than on the panel, and when the room is deep enough to need 86 inches.
Does the IFP86G1 have Android built in?
No. ViewSonic publishes no embedded operating system for this model, and its specification table has no RAM or storage row either. The operating system comes from a laptop over USB-C or from a slot-in PC in the OPS slot. An EDLA-certified slot-in PC is what adds licensed Google Play access.
How many touch points does the IFP86G1 support?
40 with a Windows source and 20 with an Android source, as listed in ViewSonic's specification table. The touch layer is infrared Ultra Fine Touch.
Can I connect a laptop with a single USB-C cable?
Yes. The USB-C port carries video, touch and data sharing and supplies up to 65W of power delivery, so most laptops charge from the same cable. Your laptop and cable must support the required functions; a laptop needing more than 65W will still want its own charger.
Is the built-in audio enough for a lecture theatre?
No. ViewSonic lists two 15W speakers on this model, which is a small-room specification on a large-room screen. Quote a soundbar or a ceiling speaker system with it, and add a microphone if the room is used for video calls.
What does mounting an 86-inch panel involve?
Plan it as an installation, not a delivery. Confirm the wall construction and the mount's weight rating, agree the mounting height with the people who will write on it, and arrange enough people to lift it safely. Where the wall cannot take it, a floor-standing trolley is the usual alternative. Ask us to survey the room if you are unsure.
How bright is the IFP86G1?
ViewSonic lists 450 nits for this model, with an anti-glare surface. That suits a normally lit room. A lecture space with large unshaded windows behind the audience will need blinds; check the panel against the actual light levels before committing.
Should I choose the 86-inch or the 55-inch IFPG1?
Choose by viewing distance and the smallest text people need to read. Both are 4K, so the larger panel makes text bigger rather than sharper. Compare the 55-inch IFP55G1 for close-up small-room work, and note that the two use different mounting patterns, so the mount is not interchangeable.
Can TopAV quote for installation and school purchase orders?
Yes. Request a project quote for mounting, cabling, audio, the slot-in PC and installation. Installation is quoted separately. Approved education customers can apply for purchase-order terms; eligibility and credit terms are subject to approval.
Is the advertised price a complete working room?
No. The displayed price is for the display. Request an itemised quote for mounting, installation, the slot-in PC, audio, any camera and any software licences. Compare the total including VAT, delivery and all required equipment.
How does the ViewSonic IFP86G1 compare with a SMART Board or Clevertouch?
SMART builds its teaching workflow around SMART Notebook and Ink and Clevertouch around LYNX Whiteboard, while ViewSonic builds around myViewBoard, which this model cannot run on its own: it ships with no onboard operating system, so the software lives on the laptop you connect over its 65W USB-C port or on a slot-in PC in the OPS slot. Our comparison guides use the IFP51 series as ViewSonic's reference, and that series has a built-in Android system where this IFPG1 panel deliberately has none. Our SMART Board vs ViewSonic and three-brand school comparison guides cover software, accounts and installed cost in detail.
Trusted by thousands of customers
Explore recent installations
See recent installations supplied by StriveAV, TopAV’s parent company. Customer names are masked for privacy.
Alternative products
Closest matches in this category on price and capability. Not sure which way to go? Our technical team will talk it through.
BenQ RE8604 86" Interactive Display
BenQ RE8605A 86-inch Board Essential RE05A Interactive Display
Promethean 86" ActivPanel LE
