Sony ZRD-CH12D Crystal LED CH Series 1.27 mm Video Wall Cabinet

The ZRD-CH12D is a cabinet from Sony's Crystal LED CH Series, the contrast-led counterpart to the BH Series. Where BH chases brightness, CH chases black. Sony's Deep Black Coating and a very small emitter within a large black surface area give the panel its depth, so faces, product shots and dark cinematic material keep their texture instead of flattening out. The cabinet runs a 1.27 mm pixel pitch across a 480 x 270 pixel array and peaks at 1,300 cd/m2.

The same X1 for Crystal LED processor drives the panel at up to 120 fps with 22-bit internal processing, with Reality Creation to upscale lower-resolution content and Motionflow to smooth motion. Colour coverage is approximately 86% of BT.2020 and 96% of DCI-P3, and contrast in a dark room is quoted above 1,000,000:1. An anti-reflection treatment holds back glare from room lighting.

Physically it matches the rest of the range: 610 x 343 x 69 mm, about 8.6 kg, borderless on all four sides so cabinets tile into any wall shape, and serviceable entirely from the front. Modules arrive pre-assembled and factory-calibrated. Drive the wall with a ZRCT-300 controller, ordered separately.
