Kramer MTX3-88-HSA 8x8 4K60 4:4:4 HDMI+Audio Scaler Based Matrix/Switcher

Name: Kramer MTX3-88-HSA 8x8 4K60 4:4:4 HDMI+Audio Scaler Based Matrix/Switcher
Brand: Kramer
SKU: MTX3-88-HSA
Price: 4820.40 GBP
Availability: OutOfStock

£4,820.40inc. VAT

£4,017.00 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Call 020 3815 8642

Return within 14 days

Installation services available Purchase orders: education customers only

3 Years Warranty Included

Key specifications

Inputs - 8 HDMIOn female HDMI connectors

Inputs - 4 Stereo analog balanced audio inputsOn terminal-block connectors

Outputs - 8 HDMIOn female HDMI connectors

Outputs - 4 Stereo analog balanced audio inputsOn terminal-block connectors

Ports - 1 RS-232On a 3-pin terminal block connector

Ports - 1 EthernetOn an RJ-45 female connector for device control and management

Video - Max. Output Resolution4K@60Hz (4:4:4)

Video - Max Data Rate18Gbps bandwidth (6Gbps per graphic channel)

All 25 specifications

Description

MTX3-88-HSA is a high-quality scaler-based matrix with eight HDMI inputs independently routable to eight HDMI outputs. The video scaling processor provides a fast and clean ( Manufacturer part number MTX3-88-HSA.

Full specifications Datasheet Compare alternatives

Call 020 3815 8642

Key features

Flexible and Safe Matrix Routing - Clean and fast switching between

Flexible and Safe Matrix Routing - Clean and fast switching between inputs, with smooth and safe transition between presented content on displays, for convenient presentation experience of end-users.

Auto Switcher Ease of Use - Automatically plays the switched source

Auto Switcher Ease of Use - Automatically plays the switched source signal on the connected display according to user-configured preferences, such as priority or last-connected input.

HDMI Signal Switching - HDCP 2.3 compliant, supporting deep color

HDMI Signal Switching - HDCP 2.3 compliant, supporting deep color, ARC, up to 7.1 uncompressed audio channels, and 3D, as specified in HDMI 2.0b.

Multiview support - Each HDMI output can display content from two

Multiview support - Each HDMI output can display content from two inputs in several layouts including picture-in-picture and side-by-side

Splash screens support - Up to 16 pre-loaded images can be selected

Splash screens support - Up to 16 pre-loaded images can be selected to any HDMI output. This provides a simple implementation of useful features like room welcome screens, emergency announcement screens and more.

OSD - User defined information may be defined and displayed in OSD

OSD - User defined information may be defined and displayed in OSD format on any output

IP Gateway support - CEC control messages to sinks or sources as well

IP Gateway support - CEC control messages to sinks or sources as well as GPIO control messages may be defined and generated using the IP control gateway mechanism.

I-EDIDPro™ Kramer Intelligent EDID Processing™ - Individual EDID

I-EDIDPro™ Kramer Intelligent EDID Processing™ - Individual EDID management per input for flexibly capturing and storing EDID from output-connected displays or custom files. Intelligent EDID handling and processing ensures plug & play operation for HDMI source and display systems.

Independent Audio Breakaway and Routing - The digital audio signals

Independent Audio Breakaway and Routing - The digital audio signals passing through to the selectable outputs, and ARC (Audio Return Channel) signals from the output-connected displays, are extracted, converted to analog audio signals, and input to the built-in audio matrix. Flexible matrix routing enables insertion of any audio input signal, either the breakaway input signals or from the matrix input ports, to any AV matrix output port or audio matrix analog balanced ports. This allows playing the audio on a locally connected professional audio system (such as DSP) and speakers, in parallel t

Simple Control - The unit is controlled over secured IP integrated

Simple Control - The unit is controlled over secured IP integrated web GUI or alternatively by any controller supporting Kramer's P3K API commands.

Technical specifications

Choose a section to view its specifications.

Display (2)

Video - Max. Output Resolution: 4K@60Hz (4:4:4)
Control - Front Panel: 8x8 select buttons + 12 control buttons with integrated LED for device operation

Connectivity (6)

Inputs - 8 HDMI: On female HDMI connectors
Inputs - 4 Stereo analog balanced audio inputs: On terminal-block connectors
Outputs - 8 HDMI: On female HDMI connectors
Outputs - 4 Stereo analog balanced audio inputs: On terminal-block connectors
Ports - 1 RS-232: On a 3-pin terminal block connector
Ports - 1 Ethernet: On an RJ-45 female connector for device control and management

Audio (1)

Audio - Routable Signals: Input/output ports, breakaway forward/ARC signals

Power & Physical (4)

Enclosure - Size: 19", 1U
General - Net Dimensions (W, D, H): 43.6cm x 18.3cm x 4.4cm (17.18" x 7.20" x 1.72")
General - Shipping Dimensions (W, D, H): 52.5cm x 33cm x 10.7cm (20.7" x 13" x 4.2")
General - Net Weight: 2.5kg (5.5lbs) approx.

Certifications & Warranty (1)

Video - Compliance: Deep Color, 3D, ARC, up to 7.1 uncompressed audio channels as specified in HDMI 2.0b

General (11)

Video - Max Data Rate: 18Gbps bandwidth (6Gbps per graphic channel)
Video - Content Protection: HDCP 2.3
Video - Max Switching Time: Standard Mode: 1 sec
Power - Source: 100-240V AC, 50/60Hz
Power - Consumption: 66VA
Enclosure - Type: Aluminum
Enclosure - Cooling: FAN ventilation
Enclosure - Max. Noise: 46dBA
Environmental Conditions - Operating Temperature: 0° to +40°C (32° to 104°F)
Environmental Conditions - Storage Temperature: -40° to +70°C (-40° to 158°F)
Environmental Conditions - Humidity: 10% to 90%, RH non-condensing

Call 020 3815 8642

Documents

Kramer MTX3-88-HSA 8x8 4K60 4:4:4 HDMI+Audio Scaler Based Matrix/Switcher — manufacturer spec sheet

Kramer MTX3-88-HSA 8x8 4K60 4:4:4 HDMI+Audio Scaler Based Matrix/Switcher — manufacturer manual
