iiyama T1732MSC-B1SAG 17" Touch Monitor

Name: iiyama T1732MSC-B1SAG 17" Touch Monitor
Brand: iiyama
SKU: T1732MSC-B1SAG
Price: 396.38 GBP
Availability: OutOfStock

Return within 14 days

3-year manufacturer warranty

Installation services available

£396.38inc. VAT

£330.32 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £132.13 with PayPal Pay in 3.

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

3-year manufacturer warranty

Installation services available

Key specifications

Cable management systemyes

DesignEdge to edge glass

Diagonal17", 43cm

PanelTN LED, AG coated glass

Native resolution1280 x 1024 (1.3 megapixel)

Aspect ratio5:4

Panel brightness250 cd/m²

Brightness215 cd/m² with touch

All 54 specifications

Talk to an Expert

Description

ProLite T1732MSC-B1SAG 17" Projective Capacitive 10pt touch screen with AG-coating The ProLite T1732MSC-B1SAG 17" multi-touch screen is based on projected capacitive technology which thanks to a glass overlay covering the screen guarantees high durability, scratch-resistance and perfect picture performance. The anti-glare coating helps to avoid issues with reflections and external light sources affecting colour reproduction, contrast and sharpness. The touch function remains unaffected even if the glass is scratched. A solid and steady base supports the touchscreen with an adjustable stand offering full 90 degree positioning angles. Menu Buttons are located on the side of the screen which can be locked to prevent tampering and includes a handy function to deactivate the touchscreen for cleaning. In addition the edge-to-edge glass design creates an eye-catching finish with high light tran

Full specifications Datasheet Compare alternatives

Technical specifications

Choose a section to view its specifications.

Display (10)

Panel: TN LED, AG coated glass
Native resolution: 1280 x 1024 (1.3 megapixel)
Aspect ratio: 5:4
Panel brightness: 250 cd/m²
Brightness: 215 cd/m² with touch
Static contrast: 1000:1 with touch
Touch technology: projective capacitive
Touch points: 10 (HID, only with supported OS)
Touch method: stylus, finger, glove (latex)
Touch interface: USB

Connectivity (7)

Colour support: 16.7mln
Supported operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Analog signal input: VGA x1
Digital signal input: HDMI x1DisplayPort x1
Audio input: Mini jack x1
Audio output: Speakers 2 x 1W
OSD languages: EN, DE, FR, ES, IT, CN, JP

Power & Physical (3)

VESA mounting: 100 x 100mm
Product dimensions W x H x D: 387 x 378 x 240mm
Weight (without box): 4.9kg

General (34)

Cable management system: yes
Design: Edge to edge glass
Diagonal: 17", 43cm
Light transmittance: 85%
Response time (BTB): 5ms
Viewing zone: horizontal/vertical: 170°/160°, right/left: 85°/85°, up/down: 80°/80°
Horizontal Sync: 31 - 80kHz
Viewable area W x H: 338 x 270.5mm, 13.3 x 10.6"
Pixel pitch: 0.264mm
Bezel colour and finish: black, matte
HDCP: yes
Water and dust protection: IP54 (front)
OSD key lock: yes
Control buttons: Menu, Scroll up/ Brightness, Scroll down/ Mute, Select, Power
User controls: contrast, brightness, auto adjust, H.position, V.position, H.size, fine, OSD H.position, OSD V.position, OSD timeout, reset, input select, OSD language, colour temperature, volume, mute
Convenience: Kensington-lock™ prepared
Plug&Play: DDC2B
Tilt angle: 90° up; 5° down
Cables: power, USB, HDMI, Audio, DP
Guides: quick start guide, safety guide
Cable cover: yes
Power supply unit: internal
Power supply: AC 100 - 240V, 50/60Hz
Power usage: 20W typical, 1.5W stand by, 0.3W off mode
Regulations: CE, EAC, RoHS support, ErP, WEEE, cULus, VCCI, REACH, UKCA
Energy efficiency class (Regulation (EU) 2017/1369): E
REACH SVHC: above 0.1%: Lead
EAN code: 4948570122158
Product series: ProLite T1532MSC-B1S, ProLite T1732MSC-B1S, ProLite T1932MSC-W1SAG , ProLite T1932MSC-B1S
User manual: T15_17_1932MSC-x1S_AG-usermanual-e.pdf
Technical specification: ProLite T1732MSC-B1SAG - gb_en.pdf
Drawing: T1732MSC-B1S_Drawing.pdf
EU Energy Label: T1732MSC-B1SAG EU Energy Label (1518684).pdf
UA Energy Label: T1732MSC-B1SAG UK Energy Label (1518684).pdf
