Home / 10 - 19" Touch Screens / iiyama T1721MSC-B3 17" Touch Monitor

iiyama

iiyama T1721MSC-B3 17" Touch Monitor

Name: iiyama T1721MSC-B3 17" Touch Monitor
Brand: iiyama
SKU: T1721MSC-B3
Price: 296.75 GBP
Availability: OutOfStock

Return within 14 days

3-year manufacturer warranty

Installation services available

£296.75inc. VAT

£247.29 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £98.92 with PayPal Pay in 3.

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

3-year manufacturer warranty

Installation services available

Key specifications

DesignEdge to edge glass

Diagonal17", 43cm

PanelTN

Native resolution1280 x 1024 @75Hz (1.3 megapixel)

Aspect ratio5:4

Panel brightness250 cd/m²

Brightness230 cd/m² with touch

Static contrast1000:1 with touch

All 60 specifications

Talk to an Expert

Description

ProLite T1721MSC-B3 17” PCAP touchscreen monitor with durable glass overlay, IPX3 front protection and an angle-adjustable stand The ProLite T1721MSC-B3 is a versatile 17” touchscreen monitor designed for smooth, accurate and reliable interaction. Its 10-point PCAP touch technology supports operation by finger, latex glove or compatible stylus, making it well suited to retail, hospitality, education and industrial environments.A protective glass overlay enhances durability and scratch resistance while preserving clear image quality and consistent touch performance. This makes the monitor a dependable choice for applications where the screen is used frequently throughout the day.The IPX3-rated front provides protection against water sprays from different directions at angles of up to 60°, offering added reassurance in environments where occasional exposure to moisture may occur. The stabl

Also in this range:15" model 15.6" T1624MSC-B1 15.6" T1633MSC-B1 21.5" model Full specifications Datasheet Compare alternatives

Technical specifications

Choose a section to view its specifications.

Display (10)

Panel: TN
Native resolution: 1280 x 1024 @75Hz (1.3 megapixel)
Aspect ratio: 5:4
Panel brightness: 250 cd/m²
Brightness: 230 cd/m² with touch
Static contrast: 1000:1 with touch
Touch technology: projective capacitive
Touch points: 10 (HID, only with supported OS)
Touch method: stylus, finger, glove (latex)
Touch interface: USB

Connectivity (8)

Colour support: 16.7mln
Supported operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Analog signal input: VGA x1
Digital signal input: HDMI x1
Audio input: Mini jack x1
Audio output: Speakers 2 x 2W
USB ports: x1
OSD languages: EN, DE, FR, ES, IT, CN, JP

Power & Physical (5)

VESA mounting: 100 x 100mm
Product dimensions W x H x D: 392.5 x 364 x 198mm
Box dimensions W x H x D: 537 x 500 x 172mm
Weight (without box): 4.4kg
Weight (with box): 5.8kg

General (37)

Design: Edge to edge glass
Diagonal: 17", 43cm
Response time (BTB): 5ms
Viewing zone: horizontal/vertical: 170°/160°, right/left: 85°/85°, up/down: 80°/80°
Horizontal Sync: 31 - 80kHz
Viewable area W x H: 338 x 270.5mm, 13.3 x 10.6"
Pixel pitch: 0.264mm
Bezel colour and finish: black, matte
HDCP: yes
Glass thickness: 1.5mm
Glass hardness: 7H
Water and dust protection: IPX3 (front)
OSD key lock: yes
Control buttons: Menu, Up/Left/ Auto adjustment button, Down/Right button, Return/Exit button, Power
User controls: picture (backlight, brightness, contrast, sharpness) display (auto adjustment, H position, V position, pixel clock, phase) colour (colour temp, picture mode) input, audio (volume, mute, audio source), other (reset, OSD time, OSD H position, OSD V position, language) information
Convenience: Kensington-lock™ prepared
Blue light reducer: yes
Plug&Play: DDC2B
Tilt angle: 70° up; 10° down
Cable management system: yes
MTBF: 50000 hours
Cables: power (1.8m), USB (1.8m), HDMI (1.8m)
Guides: quick start guide, safety guide
Other: AC adapter, mylar sheet (for VESA mount)
Cable cover: yes
Power supply unit: external
Power supply: DC 12 V
Power usage: 20W typical, 1.5W stand by, 0.3W off mode
Regulations: CE, RoHS support, ErP, WEEE, cULus, VCCI, REACH
Energy efficiency class (Regulation (EU) 2017/1369): E
REACH SVHC: above 0.1%: Lead, Diboron trioxide, Lead monoxide (lead oxide)
EAN code: 4948570127092
User manual: T1721MSC-B2_3-usermanual-e-revB.pdf
Technical specification: ProLite T1721MSC-B3 - gb_en.pdf
Drawing: T1721MSC.pdf
EU Energy Label: T1721MSC-B3 EU Energy Label (2445143).pdf
UK Energy Label: T1721MSC-B3 UK Energy Label (2445143).pdf
