iiyama T1633MSC-B1 15.6" Touch Monitor

Name: iiyama T1633MSC-B1 15.6" Touch Monitor
Brand: iiyama
SKU: T1633MSC-B1
Price: 291.48 GBP
Availability: OutOfStock

Return within 14 days

3-year manufacturer warranty

Installation services available

£291.48inc. VAT

£242.90 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £97.17 with PayPal Pay in 3.

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

3-year manufacturer warranty

Installation services available

Key specifications

DesignEdge to edge glass

Diagonal15.6", 39.5cm

PanelIPS

Native resolution1920 x 1080 @60Hz (2.0 megapixel)

Aspect ratio16:9

Panel brightness450 cd/m²

Brightness385 cd/m² with touch

Light transmittance85%

All 62 specifications

Talk to an Expert

Description

ProLite T1633MSC-B1 15.6" PCAP 10 points multi-touch monitor with edge-to-edge glass and IPS panel technology The ProLite T1633MSC-B1 uses projective capacitive touch technology, built into an eye catching bezel with edge-to-edge glass. The screen guarantees high durability, scratch-resistance, clarity and a perfect picture performance. Featuring IPS Panel Technology and Full HD (1920x1080) resolution, it offers natural, highly accurate colours and wide viewing angles. The flexible stand can be positioned at several angels creating a comfortable and ergonomic user experience and the integrated cable management system hides all the cables and electrical wires giving a neat and cable-free workspace. In addition to the superb image quality, the screen comes with an IP54 rating, which means the screen and bezel is dust and water resistant from the front. A perfect solution for retail applica

Also in this range:15" model 15.6" T1624MSC-B1 17" model 21.5" model Full specifications Datasheet Compare alternatives

Technical specifications

Choose a section to view its specifications.

Display (10)

Panel: IPS
Native resolution: 1920 x 1080 @60Hz (2.0 megapixel)
Aspect ratio: 16:9
Panel brightness: 450 cd/m²
Brightness: 385 cd/m² with touch
Static contrast: 1000:1
Touch technology: projective capacitive
Touch points: 10 (HID, only with supported OS)
Touch method: stylus, finger, glove (latex)
Touch interface: USB

Connectivity (6)

Colour support: 16.7mln
Supported operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Digital signal input: HDMI x1DisplayPort x1
Audio output: Speakers 2 x 2W
USB HUB: x2 (2.0 (DC5V, 500mA))
OSD languages: EN, DE, FR, ES, IT, PT, CN, RU, JP, CZ, NL, PL

Power & Physical (5)

VESA mounting: 100 x 100mm
Product dimensions W x H x D: 389 x 284 x 200mm
Box dimensions W x H x D: 475 x 343 x 169mm
Weight (without box): 3.4kg
Weight (without stand): 5.3kg

General (41)

Design: Edge to edge glass
Diagonal: 15.6", 39.5cm
Light transmittance: 85%
Response time (GTG): 5ms
Viewing zone: horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89°
Horizontal Sync: 30 - 68kHz
Viewable area W x H: 344.2 x 193.6mm, 13.6 x 7.6"
Pixel pitch: 0.179mm
Bezel colour and finish: black, matte
Reommended usage: retail
Palm rejection: yes
HDCP: yes
Water and dust protection: IP54 (front)
OSD key lock: yes
Control buttons: Power, Menu, Volume +, Volume -, Input
User controls: Luminance (contrast, brightness, i-Style color, adv. contrast, overdrive), image setup (aspect ratio), color temp., OSD setup (H. position, V. position, timeout, language, touch wake up), extra (input select, DDC/CI, reset, opening logo, LED, volume, information)
Convenience: Kensington-lock™ prepared
Blue light reducer: yes
Plug&Play: DDC2B
Tilt angle: 90° up; 5° down
Fanless design: yes
Cable management system: yes
MTBF: 50 000 hours (excluding backlight)
Cables: power, USB, HDMI
Guides: quick start guide, safety guide
Other: AC adapter
Cable cover: yes
Power supply unit: external
Power supply: DC 12 V
Power usage: 12W typical, 8W stand by, 0.5W off mode
Regulations: CE, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH, UKCA
Energy efficiency class (Regulation (EU) 2017/1369): C
REACH SVHC: above 0.1%: Lead
EAN code: 4948570122523
Product series: ProLite TF1633MSC-B1
User manual: T_TF1633MSC-B1-usermanual-e-revB.pdf
Technical specification: ProLite T1633MSC-B1 - gb_en.pdf
Drawing: T1633MSC-dim.pdf
EU Energy Label: T1633MSC-B1 EU Energy Label (1629639).pdf
UK Energy Label: T1633MSC-B1 UK Energy Label (1629639).pdf
CE & TUV: T1633MC-1 CE_TUV.pdf
