Home / Fixed Wall Mounts / Chief XSD1U Extra-Large Electric Height-Adjustable Wall Mount
Chief

Chief XSD1U Extra-Large Electric Height-Adjustable Wall Mount

£2,198.40inc. VAT
£1,832.00 ex. VAT
Out of stock
1

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →
  • Sourced through UK distribution
  • UK manufacturer warranty
  • UK-based engineers
  • No import duty or customs charges
  • GBP pricing, UK VAT invoices
Call 01342 580255
Return within 14 days
Installation services availablePurchase orders: education customers only
5 Years Warranty Included
Key specifications
Weight Capacity140.6 kg
Typical Screen Size50 - 80 in
VESA Mounting Pattern200 x 200mm - 860 x 510mm
AdjustabilityAutomated, Height Adjustable, Micro-Adjustable
AdjustmentsLeveling adjustment: up to 1.5" (38mm)
ApplicationWall
ColourBlack
Power CordUS Cord
All 14 specifications

Description

The Chief XSD1U is an extra-large electric wall mount that raises and lowers a display through 660 mm (26 in) of powered vertical travel at the touch of a control pad. It suits interactive displays and boardroom screens that must serve seated, standing and wheelchair users from a single fixed position on the wall.

Full specifications Datasheet Compare alternatives

Weight capacity is 140.6 kg and the mount accepts VESA patterns from 200 x 200 mm up to 860 x 510 mm, covering typical screen sizes of 50 to 80 in. Levelling adjustment of up to 38 mm is available after installation, and the mount is micro-adjustable so the display can be trued up without taking it back off the wall.

The unit ships in black and is UL Listed. Note that it is supplied with a US power cord and is not TAA compliant. A pin-out diagram for the electric height-adjust control pad is published by Chief for integrators wiring the mount into a control system.

Supplied by TopAV. Manufacturer part number XSD1U.

Call 01342 580255

Key features

660 mm of powered travel

Motorised vertical lift of 26 in (660 mm) from a control pad.

140.6 kg weight capacity

Rated to 310 lbs (140.6 kg).

50-80 in displays

Typical screen size range of 50 to 80 in (1270-2032 mm).

VESA 200 x 200 to 860 x 510 mm

Wide interface range for extra-large commercial panels.

Post-install levelling

Up to 1.5 in (38 mm) of levelling adjustment plus micro-adjustment.

UL Listed

Certified UL Listed; supplied with a US power cord.

Technical specifications

Display
Typical Screen Size50 - 80 in
Power & Physical
Weight Capacity140.6 kg
VESA Mounting Pattern200 x 200mm - 860 x 510mm
ColourBlack
Shipping Dimensions40" x 30" x 11.5" (101.6 x 76.2 x 29.2 cm)
Shipping Weight60.3 kg
Certifications & Warranty
CertificationsUL Listed
General
AdjustabilityAutomated, Height Adjustable, Micro-Adjustable
AdjustmentsLeveling adjustment: up to 1.5" (38mm)
ApplicationWall
Power CordUS Cord
Special FeaturesHeight Assist
TAA CompliantNo
Vertical Lift660 mm
Call 01342 580255

Documents

Chief XSD1U specification sheet (PDF) published by Legrand AV.
