Home / Touch Screen Wall Mounts / Chief PDRUB Large Flat Panel Swing Arm Wall Mount - 37 in Extension, Black

Chief

Chief PDRUB Large Flat Panel Swing Arm Wall Mount - 37 in Extension, Black

Name: Chief PDRUB Large Flat Panel Swing Arm Wall Mount - 37 in Extension, Black
Brand: Chief
SKU: PDRUB
Price: 812.80 GBP
Availability: OutOfStock

£812.80inc. VAT

£677.33 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £270.94 with PayPal Pay in 3.

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

10 Years Warranty Included

Key specifications

Weight Capacity90.7 kg

Typical Screen Size42 - 71 in

VESA Mounting Pattern200 x 200mm - 862 x 517mm

Wall Stud Compatibility406 mm

AdjustabilityExtension, Height Adjustable, Lateral Shift, Micro-Adjustable, Swivel, Tilt

Tilt+5° / -16°

Post-Installation Leveling RollYes

ApplicationWall

All 20 specifications

Description

The Chief PDRUB is a large dual-arm swing mount that pulls a display 940 mm (37 in) off the wall and swivels it to face wherever the audience is, then folds back to an 86 mm profile when it is not needed. That combination suits corner installations, meeting rooms with several seating arrangements and retail spaces with changing sightlines.

Full specifications Datasheet Compare alternatives

It carries displays of 42 to 71 in weighing up to 90.7 kg on VESA patterns from 200 x 200 mm to 862 x 517 mm, and fits 16 in (406 mm) stud centres. Chief’s Centris tilt mechanism gives +5 to -16 degrees of fingertip tilt, and up to 25 mm of post-installation height adjustment is available for levelling. Both landscape and portrait mounting are supported.

The Q-Latch mounting system secures the display to the mount with a latching flag, and the CableTrac system routes cabling inside the arms so nothing is visible across the swing. Overall dimensions are 560 x 1003 x 86 mm. Note that the quoted depth and extension exclude the interface bracket, which adds 13-38 mm. The mount is UL Listed. It is not TAA compliant.

Supplied by TopAV. Manufacturer part number PDRUB.

Key features

940 mm extension

Extends 37 in from the wall and folds back to an 86 mm profile.

90.7 kg weight capacity

Rated to 200 lbs (90.7 kg) for displays of 42-71 in.

Swivel, tilt and lateral shift

Centris fingertip tilt of +5 to -16 degrees, with swivel and up to 25 mm of post-install height adjustment.

VESA 200 x 200 to 862 x 517 mm

Landscape and portrait mounting both supported.

CableTrac internal cable routing

Cabling runs inside the arms for a clean installation through the full swing.

Q-Latch security

Latching flag secures the display to the mount; UL Listed.

Technical specifications

Choose a section to view its specifications.

Display (1)

Typical Screen Size: 42 - 71 in

Power & Physical (8)

Weight Capacity: 90.7 kg
VESA Mounting Pattern: 200 x 200mm - 862 x 517mm
Colour: Black
Overall Dimensions: 22.0" x 39.5" x 3.4" (560 x 1003 x 86mm)
Depth: 8.6 cm
Height: 55.9 cm
Width: 100.3 cm
Shipping Weight: 36.2 kg

Certifications & Warranty (1)

Certifications: UL Listed

General (10)

Wall Stud Compatibility: 406 mm
Adjustability: Extension, Height Adjustable, Lateral Shift, Micro-Adjustable, Swivel, Tilt
Tilt: +5° / -16°
Post-Installation Leveling Roll: Yes
Application: Wall
Orientation: Landscape, Portrait
Solution Type: Universal
TAA Compliant: No
Maximum Extension: 940 mm
Cable Management: CableTrac routing inside the arms

Documents

Chief PDR series installation manual (PDF) covering the PDRUB. Chief generates its cutsheet in the browser and publishes no downloadable version.
