Chief PNRUB Large Flat Panel Swing Arm Wall Mount, 635 mm Extension - Black

The PNRUB is Chief's large swing arm wall mount with a 635 mm reach, so a big display can be pulled clear of the wall and turned towards wherever people are sitting. It suits boardrooms, waiting areas, bars and any room with more than one viewing position.

Centris fingertip tilt lets the installer dial in tension to suit the screen's centre of gravity, giving plus 5 to minus 15 degrees of tilt that stays put. There is 229 mm of lateral shift, up to 25 mm of post-installation height adjustment and post-installation levelling roll, so the screen can be squared up after it is on the wall. The Q-Latch system holds the panel with a latching flag and releases without tools, and the CableTrac channels run cables along the arm.

The mount handles 42 to 86 inch displays up to 90.7 kg on VESA patterns from 200 x 200 mm to 862 x 517 mm, fits 406 mm stud centres, and sits 84 mm deep when folded. The screen can be fitted in landscape or portrait. It is UL Listed. Note that the quoted depth and extension exclude the interface bracket, which adds 13 to 38 mm. Supplied by TopAV. Manufacturer part number PNRUB.
