Home / Fixed Wall Mounts / Chief AS3LD Tempo Flat Panel Wall Mount System
Chief

Chief AS3LD Tempo Flat Panel Wall Mount System

£463.20inc. VAT
£386.00 ex. VAT
In stock, dispatched within 0 working days
1

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →
  • In UK stock, ships from the UK
  • UK manufacturer warranty
  • UK-based engineers
  • No import duty or customs charges
  • GBP pricing, UK VAT invoices
Return within 14 days
Installation services availablePurchase orders: education customers only
10 Years Warranty Included
Key specifications
Weight Capacity90.7 kg
Typical Screen Size49 - 86 in
VESA Mounting Patternup to 970 x 450mm
Wall Stud Compatibility16" O.C., 24" O.C.
AdjustabilityExtension, Lateral Shift, Micro-Adjustable, Tilt
Tilt-10° / +0° in 2.5° increments
Lateral ShiftYes
Post-Installation Leveling Roll25 mm
All 24 specifications

Description

The Chief AS3LD is a complete Tempo wall mounting system rather than a bare bracket: display mount, wall plate, device storage and cable management arrive in one box under one part number. It is built for volume rollouts, where the saving comes from fewer part numbers to order and fewer missing components on site.

Full specifications Datasheet Compare alternatives

It carries displays of 49 to 86 in weighing up to 90.7 kg, on VESA patterns up to 970 x 450 mm, and fits both 16 in and 24 in stud centres. Minimum depth is 50 mm, tilt is adjustable through 10 degrees in 2.5-degree increments, and up to 25 mm of levelling roll and lateral shift are available after installation for centring the display.

Two 15 x 10 in Lever Lock storage plates ship with the mount and can be repositioned along the mounting rail; between two and six small devices can be stored behind the display with 44 mm (1RU) of clearance at zero tilt. Servicing uses 320 mm of service depth and 271 mm of extension. Six cable management clips and a home latch lockout clip are included. The system is UL, cULus and OSHPD certified.

Supplied by TopAV. Manufacturer part number AS3LD.

Key features

One part number, one box

Mount, wall plate, storage plates and cable management ship as a single SKU for rollout efficiency.

90.7 kg weight capacity

Rated to 200 lbs (90.7 kg) for displays of 49-86 in.

Integrated Lever Lock device storage

Two 15 x 10 in storage plates included, repositionable along the rail, with 44 mm of clearance at zero tilt.

271 mm service extension

320 mm of service depth and 271 mm of extension for access behind the display.

VESA up to 970 x 450 mm

Fits 16 in and 24 in stud centres with up to 25 mm of post-install levelling and lateral shift.

UL, cULus and OSHPD certified

Carries OSHPD approval for healthcare installations.

Technical specifications

Display
Typical Screen Size49 - 86 in
Power & Physical
Weight Capacity90.7 kg
VESA Mounting Patternup to 970 x 450mm
ColourBlack
Overall Dimensions42.03" x 19.75" x 1.96" (1068 x 502 x 50 mm)
Minimum Depth5 cm
Product Weight13.4 kg
Shipping Dimensions47.64" x 22" x 2.76" (121 x 55.9 x 7 cm)
Shipping Weight16.4 kg
Service Depth320 mm
Certifications & Warranty
CertificationscULus, OSHPD, UL
General
Wall Stud Compatibility16" O.C., 24" O.C.
AdjustabilityExtension, Lateral Shift, Micro-Adjustable, Tilt
Tilt-10° / +0° in 2.5° increments
Lateral ShiftYes
Post-Installation Leveling Roll25 mm
ApplicationWall
OrientationLandscape
Solution TypeUniversal
Includes PDUNo
Special FeaturesADA Compliant
TAA CompliantNo
Service Extension271 mm
Included Storage PlatesTwo 15 x 10 in Lever Lock plates, 1RU (44 mm) clearance at 0 degree tilt

Documents

Chief AS3LD installation manual (PDF). Chief generates its cutsheet in the browser and publishes no downloadable version.
