Chief LSD1U Large Fusion Dynamic Height-Adjustable Wall Mount

Name: Chief LSD1U Large Fusion Dynamic Height-Adjustable Wall Mount
Brand: Chief
SKU: LSD1U
Price: 1507.91 GBP
Availability: OutOfStock

£1,507.91inc. VAT

£1,256.59 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £502.64 with PayPal Pay in 3.

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Call 020 3815 8642

Return within 14 days

Installation services available Purchase orders: education customers only

10 Years Warranty Included

Key specifications

Weight Capacity55.4 - 79.4 kg

VESA Mounting Pattern100 x 100mm - 800 x 500mm

Wall Stud Compatibility406 mm

AdjustabilityHeight Adjustable, Micro-Adjustable

Dynamic Height Adjustment400 mm

ApplicationWall

OrientationLandscape

Number of Displays1

All 20 specifications

Description

The Chief LSD1U is a large Fusion wall mount with dynamic height adjustment: a spring-counterbalanced box gives 400 mm (15.75 in) of vertical travel that is set simply by moving the display up or down by hand. It is aimed at interactive displays in classrooms and boardrooms, where the same screen has to work for users of different heights and for seated access.

Full specifications Datasheet Compare alternatives

The mount is rated for displays weighing 55.4 to 79.4 kg. Because the counterbalance is tuned to that band, the display weight matters as much as its size. VESA patterns from 100 x 100 mm to 800 x 500 mm are supported, and the mount fits 16 in (406 mm) stud centres. Overall dimensions are 635 x 884 x 130 mm.

It ships fully assembled with the LSM1U mount head. Set screws lock the assembly rigid once positioned, a built-in cable stand keeps connections reachable under the screen, and an integrated security flag is provided. Chief states the spring system is tested to 60,000 cycles. The mount is TAA compliant and UL Listed.

Supplied by TopAV. Manufacturer part number LSD1U.

Call 020 3815 8642

Key features

400 mm of hand-operated travel

Counterbalanced box gives 15.75 in (400 mm) of vertical adjustment with no tools or power.

55.4-79.4 kg capacity band

Rated for displays of 122-175 lbs; the counterbalance is matched to this weight range.

VESA 100 x 100 to 800 x 500 mm

Covers most large commercial and interactive panels.

16 in stud compatible

Fits 16 in (406 mm) wall stud centres.

Ships assembled with LSM1U head

Supplied as a complete unit rather than as separate components.

TAA compliant and UL Listed

Meets TAA procurement requirements and carries UL Listing.

Technical specifications

Choose a section to view its specifications.

Display (1)

Number of Displays: 1

Audio (1)

Dynamic Height Adjustment: 400 mm

Power & Physical (8)

Weight Capacity: 55.4 - 79.4 kg
VESA Mounting Pattern: 100 x 100mm - 800 x 500mm
Colour: Black
Overall Dimensions: 25" x 34.8" x 5.1" (635 x 884 x 130 mm)
Depth: 13 cm
Height: 63.5 cm
Width: 88.4 cm
Shipping Weight: 36.7 kg

Certifications & Warranty (1)

Certifications: TAA, UL Listed

General (9)

Wall Stud Compatibility: 406 mm
Adjustability: Height Adjustable, Micro-Adjustable
Application: Wall
Orientation: Landscape
Solution Type: Universal
Special Features: Height Assist
TAA Compliant: Yes
Spring System Rating: Tested to 60,000 cycles
Supplied Mount Head: LSM1U, ships fully assembled

Call 020 3815 8642

Documents

Chief MSD1U / LSD1U installation manual (PDF). Chief generates its cutsheet in the browser and publishes no downloadable version.
