Home / Floor-to-Wall Stands / Chief LBM1X3U Fusion 1x3 Micro-Adjustable Large Bolt-Down Freestanding Video Wall - Landscape, 3 Displays
Chief

Chief LBM1X3U Fusion 1x3 Micro-Adjustable Large Bolt-Down Freestanding Video Wall - Landscape, 3 Displays

£3,423.60inc. VAT
£2,853.00 ex. VAT
Out of stock
1

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →
  • Sourced through UK distribution
  • UK manufacturer warranty
  • UK-based engineers
  • No import duty or customs charges
  • GBP pricing, UK VAT invoices
Call 01342 580255
Return within 14 days
Installation services availablePurchase orders: education customers only
10 Years Warranty Included
Key specifications
Display centre height range (bottom to top row)416 - 2093 mm
Depth19.1 cm
Height214.5 cm
Lateral shiftYes
Manual height adjustmentMicro-adjustment up to 0.75" (19 mm) per screen
Overall dimensions (H x W x D)2145 x 914 x 191 mm
Plumb adjustmentMicro-adjustment up to 0.75" (19 mm)
Shipping weight90.7 kg
All 20 specifications

Description

Chief's Fusion large bolt-down freestanding stand builds a permanent video wall on the floor rather than the wall, which suits glazed frontages, retail floors and lobbies where fixing into the structure behind is not an option. The 1x3 landscape array carries three displays of 42" to 65", each supported to 56.7 kg.

Also in this range:LBM1X2U LBM3X3U LBM3X2U LBM2X2U Full specifications Datasheet Compare alternatives

Alignment is the point of the Fusion system. Every display position offers independent height, plumb and lateral shift adjustment, with micro-adjustment of up to 19 mm per screen, so a fitter can close the seams across the whole array without dismounting anything. Cable management is integrated into the columns.

A one-column stack of three landscape screens gives a tall, slim signage face for lobbies and corridors. Assembled the structure measures 2145 mm high by 914 mm wide by 191 mm deep, bolting down through its column base plates, with display centres between 416 mm and 2093 mm from floor level.

Supplied by TopAV. Manufacturer part number LBM1X3U.

Call 01342 580255

Key features

1x3 landscape array

Holds three displays stacked in a single column, in landscape orientation.

Weight capacity

56.7 kg per display position.

VESA compatibility

Takes patterns from 100 x 100 mm up to 900 x 400 mm.

Micro-adjustment

Independent height, plumb and lateral shift, with up to 19 mm of micro-adjustment per screen.

Bolt-down structure

Floor-fixed columns with bolt-down base plates; 2145 x 914 x 191 mm assembled.

Certification

TAA compliant.

Technical specifications

Display
Display centre height range (bottom to top row)416 - 2093 mm
Typical screen size1067 - 1651 mm
Weight capacity per display56.7 kg
Number of displays3
Power & Physical
Depth19.1 cm
Height214.5 cm
Manual height adjustmentMicro-adjustment up to 0.75" (19 mm) per screen
Overall dimensions (H x W x D)2145 x 914 x 191 mm
Shipping weight90.7 kg
Width91.4 cm
ColourBlack
VESA mounting pattern100 x 100mm - 900 x 400mm
Certifications & Warranty
CertificationsTAA
General
Lateral shiftYes
Plumb adjustmentMicro-adjustment up to 0.75" (19 mm)
AdjustabilityMicro-Adjustable
ApplicationBolt-Down
Array configuration1x3
OrientationLandscape
TAA compliantYes
Call 01342 580255

Documents

LBM Series Installation Manual (PDF) from Legrand AV - the installation manual covering the Chief LBM1X3U. Legrand does not publish a cutsheet for this SKU.
