Home / Floor-to-Wall Stands / Chief LBM1X2U Fusion 1x2 Micro-Adjustable Large Bolt-Down Freestanding Video Wall Stand - Landscape
Chief

Chief LBM1X2U Fusion 1x2 Micro-Adjustable Large Bolt-Down Freestanding Video Wall Stand - Landscape

£3,080.40inc. VAT
£2,567.00 ex. VAT
Out of stock
1

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →
  • Sourced through UK distribution
  • UK manufacturer warranty
  • UK-based engineers
  • No import duty or customs charges
  • GBP pricing, UK VAT invoices
Call 01342 580255
Return within 14 days
Installation services availablePurchase orders: education customers only
10 Years Warranty Included
Key specifications
Array configuration1x2
Number of displays2
OrientationLandscape
ApplicationBolt-down freestanding
ColourBlack
Solution typeUniversal
Typical screen size42-80 in
Weight capacity56.7 kg
All 20 specifications

Description

The Chief LBM1X2U is a bolt-down freestanding stand that carries two large displays stacked one above the other in landscape. Twin uprights are fixed to the floor through base plates, so the array stands clear of any wall - useful in showrooms, transport concourses and exhibition spaces where a structural wall is either unavailable or unsuitable.

Also in this range:LBM3X3U LBM3X2U LBM2X2U LBM1X3U Full specifications Datasheet Compare alternatives

Two horizontal rails carry universal interface brackets covering a VESA range of 100 x 100 mm up to 900 x 400 mm, and a typical screen size range of 42 to 80 in. Each display position is rated to 125 lb (56.7 kg). Height micro-adjusts by up to 19 mm per screen, plumb by up to 19 mm, and lateral shift is supported, so the two panels can be squared to each other after installation.

Overall dimensions are 1689 x 914 x 191 mm and the lower display centre sits between 416 mm and 1635 mm from the floor depending on set-up. The stand is TAA compliant and finished in black.

Supplied by TopAV. Manufacturer part number LBM1X2U.

Call 01342 580255

Key features

Two stacked landscape displays

1 wide by 2 high array on a pair of floor-fixed uprights, no wall required.

56.7 kg per display position

Rated weight capacity of 125 lb (56.7 kg) per display.

42-80 in screens

Typical screen size range 42 in to 80 in (1067 mm to 2032 mm).

Wide VESA range

Accepts VESA patterns from 100 x 100 mm up to 900 x 400 mm.

Micro-adjustment and lateral shift

Height micro-adjusts up to 19 mm per screen, plumb up to 19 mm, with lateral shift for squaring the array.

Overall footprint

1689 mm high x 914 mm wide x 191 mm deep, finished in black; TAA compliant.

Technical specifications

Display
Number of displays2
Typical screen size42-80 in
Display centre height range416 mm (lowest) - 1635 mm (highest)
Power & Physical
ColourBlack
Weight capacity56.7 kg
VESA mounting pattern100 x 100 mm - 900 x 400 mm
Overall dimensions1689 x 914 x 191 mm
Height168.9 cm
Width91.4 cm
Depth19.1 cm
Manual height adjustmentMicro-adjustment up to 19 mm per screen
Shipping weight86.2 kg
General
Array configuration1x2
OrientationLandscape
ApplicationBolt-down freestanding
Solution typeUniversal
Plumb adjustmentMicro-adjustment up to 19 mm
Lateral shiftYes
AdjustabilityMicro-adjustable
TAA compliantYes
Call 01342 580255

Documents

Chief LBM1X2U installation manual (PDF) published by Legrand AV - LBM Series Installation Manual.
