Sharp A175U Large-Venue Laser Projector - White - Lens Not Included

Name: Sharp A175U Large-Venue Laser Projector - White - Lens Not Included
Brand: Sharp
SKU: XPA175U-W
Price: 17945.28 GBP
Availability: InStock

Return within 14 days

3-year manufacturer warranty

Installation services available

£17,945.28inc. VAT

£14,954.40 ex. VAT

In stock, dispatched within 2 working days

Visa
Mastercard
American Express
PayPal

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

In UK stock, ships from the UK
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

3-year manufacturer warranty

Installation services available

Call 01342 580255

Key specifications

BrandSharp

ModelA175U-W

Cabinet ColourWhite

Projection Technology3LCD

Native Resolution1920 x 1200 (WUXGA)

Aspect Ratio16:10

Brightness (Normal)16000 lm

Brightness (Centre)17000 lm

All 30 specifications

Talk to an Expert

Description

The Sharp A175U-W is a high-brightness WUXGA 3LCD installation laser projector built for large venues such as auditoriums, houses of worship, museums and corporate atriums. It produces 16,000 lumens in normal mode (17,000 lumens centre) at native 1920x1200 resolution with a 3,000,000:1 contrast ratio and 12-bit colour processing, plus HDR10 support over HDMI.

Also in this range:A824U A201U Full specifications Datasheet Compare alternatives

A sealed, filter-free laser light engine rated for up to 20,000 hours of maintenance-free running is paired with a choice of six motorized bayonet lenses (throw ratios from 0.53:1 to 7.5:1), wide motorized lens shift and geometric/edge-blending correction for multi-projector arrays. The lens is sold separately and must be selected and fitted to match the throw distance.

Installation connectivity includes 3G-SDI, HDBaseT in/out and dual HDMI, with RS-232 and RJ45 LAN for centralised control and monitoring in professional AV deployments.

Call 01342 580255

Key features

Lens

Sold separately - 6 motorized lens options

Brightness

16,000 lm Normal / 17,000 lm Centre

Light Source

Laser, up to 20,000 hours maintenance-free

Multi-Projector Support

Edge blending and stacking correction

Technical specifications

Choose a section to view its specifications.

Display (8)

Native Resolution: 1920 x 1200 (WUXGA)
Aspect Ratio: 16:10
Brightness (Normal): 16000 lm
Brightness (Centre): 17000 lm
Contrast Ratio: 3,000,000:1
HDR Support: HDR10 via HDMI
Resolution: 1920 x 1200 (WUXGA)
Screen Size Range: 60 - 500 inches

Connectivity (3)

Video Inputs: 1x 3G-SDI, 1x HDBaseT, 2x HDMI
Control Ports: RS-232, RJ45 LAN
White Light Output: 16,000 lumens (ISO 21118-2020)

Power & Physical (4)

Cabinet Colour: White
Weight: 28.7 kg
Dimensions (WxHxD): 599 x 238 x 490 mm (without lens)
Power Consumption: 990W Normal / 890W Silent

Certifications & Warranty (2)

Warranty (Unit): 3 years pan-European service
Warranty (Light Source): 3 years or 10,000 hours

General (13)

Brand: Sharp
Model: A175U-W
Projection Technology: 3LCD
Light Source Life: 20,000 hours
Lens: Sold separately
Lens Options: 6 motorized (0.53:1 to 7.5:1 throw)
Standard Throw Ratio (NP54ZL): 1.25-2.01:1
Noise Level: 43 dB(A) Normal / 37 dB(A) Silent
Projection Distance: 0.68 - 80.77 m
Keystone Correction: +/-40 deg horizontal, +/-30 deg vertical (manual)
Zoom: Motorised
Lens Shift: Up to H: +/-25%, V: +65%/-65%
Light Source: Laser

Call 01342 580255

Throw distance guide

With its 1.25 to 2.01:1 throw ratio, here's how far the projector needs to sit from the screen for common 16:10 image sizes. Try our throw distance calculator for your exact room.

Supported image: 60″ to 500″ diagonalLens distance: 0.68 to 80.77 m

Try a size

100"

16:10 diagonal image


2.15 m × 1.35 m

Lens position

2.7 m to 4.3 m

Side view: drag the projector to try its available lens positions

Position fits

Manufacturer lens-distance limit: 0.7 m to 81 m. The dotted lines show the usable zoom positions for this picture size.

Image size	Image dimensions	Lens distance range
60"	1.29 m × 0.81 m	1.6 m to 2.6 m
80"	1.72 m × 1.08 m	2.2 m to 3.5 m
100"	2.15 m × 1.35 m	2.7 m to 4.3 m
120"	2.58 m × 1.62 m	3.2 m to 5.2 m
150"	3.23 m × 2.02 m	4.0 m to 6.5 m
200"	4.31 m × 2.69 m	5.4 m to 8.7 m
250"	5.38 m × 3.37 m	6.7 m to 11 m
300"	6.46 m × 4.04 m	8.1 m to 13 m
400"	8.62 m × 5.38 m	11 m to 17 m
500"	10.77 m × 6.73 m	13 m to 22 m

Planning from a real wall? Use the projector screen size calculator to upload a photo, preview the image to scale and find projectors that fit within your maximum available space. Replacing an existing projector? The projector replacement calculator checks whether this lens covers the ratio your current mount needs.

Distances are lens-to-screen, calculated from the manufacturer's stated throw ratio; allow for lens shift and mounting hardware. Always confirm against the manufacturer's installation guide before fixing mounts.

See it on your wall, to scale

Choose a picture size, then upload a wall photo, or scan the QR code and take it on your phone. We'll show the projected picture at its real size.

Picture size

100" 16:10 · 2.15 m × 1.35 m

On a computer, the QR code sends your phone photo straight back to this page.

Loading the wall preview…

Complete your setup

Optional extras that fit this product. Tick anything you need and it joins the same basket — or add this product on its own from the buy box above.

Choose a Mount

Open

Choose a Screen

Video Conferencing

No video conferencing options found in our catalogue.

Professional Installation

Want it installed by our AV experts? We offer professional on-site installation including mounting, cable management, and system configuration.

Add installation enquiryWe'll contact you to arrange a site surveyPOA

Your Configuration

Sharp A175U Large-Venue Laser Projector - White - Lens Not Included × 1£17,945.28

Total£17,945.28

inc. VAT

Documents

Sharp A175U datasheet — Sharp published specifications (PDF)
