Nexmosphere NEO640 4-Port Metered Power Controller for Digital Signage

Name: Nexmosphere NEO640 4-Port Metered Power Controller for Digital Signage
Brand: Nexmosphere
SKU: NEO640
Price: 452.40 GBP
Availability: InStock

£452.40inc. VAT

£377.00 ex. VAT

In stock, dispatched within 2 working days

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £150.80 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

In UK stock, ships from the UK
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

2 Years Warranty Included

Key specifications

X-talk channels4 (addresses 001–004)

Power input1x C14, 110-240 VAC

Operating voltage100-240 VAC 50/60Hz

Power input current10A max

Power outputs current10A max

Power measurementOn each individual output (voltage, current, power and usage)

Power controlOn each individual output (On, Off, Toggle, Cycle-on, Cycle-off; zero-voltage switching)

API interfaceUSB-C (device appears as a USB-to-Serial converter)

All 22 specifications

Description

Nexmosphere NEO is a power controller for digital signage and interactive installations. Nexmosphere states it 'gives you full control and visibility over the energy usage and operational health of your setup.'

Also in this range:NEO620 Full specifications Datasheet Compare alternatives

Instead of relying on 'typical power usage' specifications, it measures the actual power consumption of each connected device under real conditions, including variations caused by settings such as display brightness or content type.

Intelligent start-up and shut-down control ensures equipment powers up in the right order — for example switching on the player before the display — while system health monitoring lets you check remotely whether devices are functioning as expected, and remote power cycling reduces field visits.

Smart scheduling and routine management cut energy costs, either with daily on/off cycles for stand-alone installations or by activating displays only when a person is present.

The NEO 600 series offers power measurement and control over all individual power outputs, a USB connection for API communication, and network connectivity with complimentary online dashboards plus the option of server-to-server communication.

The NEO640 is Nexmosphere's four-output model: 'Power controller, 4x 110-230V output, 4x X-talk'.

It provides one C14 110-240 VAC power input and four C13 110-230 VAC power outputs, with power measurement and power control on each individual output; power outputs 3 and 4 are fitted on the NEO640 model only.

Net weight is 330 g.

Key features

Power measurement

Gather highly accurate data on power parameters for each individual output — voltage, current, power and usage — with auto-send data at interval or data-on-request.

Power control

Control all power outputs individually and create start-up and shut-down sequences: On, Off, Toggle, Cycle-on, Cycle-off, start-up, shut-down and power-on sequences, with zero-voltage switching.

Scheduling

Create and store up to 16 schedules for stand-alone power control applications.

Monitoring

Actively monitor the installation with settable min and max power warnings per output, an adjustable soft-fuse, an individual watchdog timer per output, and diagnostic logs such as hours of operation and switch cycles.

X-talk interface

Connect Nexmosphere sensors — presence, RFID, ambient light, temperature, touch buttons or Lidar — to create interactive applications or smart power routines.

USB interface

The NEO controller manifests itself as a USB-to-Serial converter and is compatible with all mainstream operating systems and digital signage players, integrating via Nexmosphere's serial API.

Technical specifications

Connectivity

Power input1x C14, 110-240 VAC

Power input current10A max

Power outputs current10A max

Network connectorRJ-45, for Sensmi dashboard and server-to-server API

Serial communication (USB)115200 baud, 8 data bits, no parity, 1 stop bit, no flow control, ASCII protocol, CR+LF EOL

Power outputs4x C13, 110-230 VAC (outputs 3 and 4 are NEO640-only)

Power & Physical

Operating voltage100-240 VAC 50/60Hz

Dimensions (L x W x H)150 x 117 x 38 mm

MountingBoth horizontal and vertical mounting allowed

Net weight330 g

Certifications & Warranty

Standards and certificationsUL 62368-1 / CSA 22.2 No. 62368-1 compliant (UL listing pending), RoHS compliant

Warranty2-year (optional 3-year extended warranty)

General

X-talk channels4 (addresses 001–004)

Power measurementOn each individual output (voltage, current, power and usage)

Power controlOn each individual output (On, Off, Toggle, Cycle-on, Cycle-off; zero-voltage switching)

API interfaceUSB-C (device appears as a USB-to-Serial converter)

SchedulingUp to 16 stored schedules

Operating temperature+10°C to +40°C (+50°F to +104°F)

Storage temperature-20°C to +50°C (-4°F to +122°F)

CoolingPassive cooling (no moving parts)

Screw fixation4mm holes, 138 mm spacing

Items per carton1 or 10 pcs

Documents

Nexmosphere NEO640 4-Port Metered Power Controller for Digital Signage — manufacturer datasheet (PDF)
