Radio Design Labs RU-SQ6A Sequencing Controller - Power up, power down

Name: Radio Design Labs RU-SQ6A Sequencing Controller - Power up, power down
Brand: Radio Design Labs
SKU: RU-SQ6A
Price: 477.60 GBP
Availability: OutOfStock

£477.60inc. VAT

£398.00 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £159.20 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

7 Years Warranty Included

Key specifications

Control InputExternal closure < 2.5 mA @ 24 Vdc

Interval Between Outputs1 to 10 seconds nominal, front-panel adjustable

Indicators (10)Red LEDs indicating channel 'on' condition (6) Green LED indicating UP REQUEST Green LED indicating sequence COMPLETE Red / Green LEDs indicating Remote or Front-Panel Activation

24 Vdc Output1.1 A maximum, 100 mA less than power supply current

Open Collector (6)200 mA surge; 50 mA continuous; 200 mA maximum

Relay Outputs (6)SPST (closed when active)

Maximum Switching Power60 W (220 Vdc, 125 Vac, 2A)

Maximum Switching Voltage220 Vdc, 250 Vac

All 14 specifications

Description

The RU-SQ6A is the ideal choice in installations where sequential ON and sequential OFF functions are desired. Control and output connections are made on the rear panel through clearly identified detachable terminal blocks.

Full specifications Datasheet Compare alternatives

Two types of outputs are provided for each of the 6 sequential steps. One type is an open collector capable of switching loads of 50mA. The other type is an SPST dry contact closure which may be used to control a variety of equipment. A single-turn front-panel TIMING INTERVAL control adjusts the time delay between channels from 1 to 10 seconds. Front-panel LEDs show when each output channel turns on and off. An internal microcontroller insures reliable, accurate timing.

The up or down sequence is user-controlled by a front-panel pushbutton switch unless the module is set for remote operation. A rear-panel switch set by the installer selects either front-panel or remote control activation. LEDs indicate whether the front-panel SEQUENCE CONTROL switch or the remote terminals are active. Grounding the rear-panel ACTIVATE terminals or turning on the front-panel SEQUENCE CONTROL switch causes an UP REQUEST that starts the RU SQ6A outputs to turn on sequentially. The outputs remain active until the UP REQUEST is cancelled by turning off the front-panel or remote control switch, causing the outputs to turn off in reverse sequence. If the ACTIVATE terminal is permanently grounded with the module set for remote control, the RU-SQ6A outputs will turn on sequentially when power is applied to the module; all outputs will turn off simultaneously when power is removed from the RU-SQ6A. The UP REQUEST LED is illuminated when an UP sequence is requested. When the sequence is complete, the COMPLETE LED indicates the Sure-Lok™ supervisory circuit is actively latching the outputs active until the user de-activates the sequence.

Key features:

• Control of Sequential Power-Up or Events

• Adjustable Up/Down Time Interval

• Open-collector Outputs

• Relay Contact Closures

• Up to Six Sequential Events

• Sure-Lok™ Output Supervision

Manufacturer part number RU-SQ6A.

Key features

Control Input

External closure < 2.5 mA @ 24 Vdc

Interval Between Outputs

1 to 10 seconds nominal, front-panel adjustable

Indicators (10)

Red LEDs indicating channel 'on' condition (6) Green LED indicating UP REQUEST Green LED indicating sequence COMPLETE Red / Green LEDs indicating Remote or Front-Panel Activation

24 Vdc Output

1.1 A maximum, 100 mA less than power supply current

Open Collector (6)

200 mA surge; 50 mA continuous; 200 mA maximum

Relay Outputs (6)

SPST (closed when active)

Maximum Switching Power

60 W (220 Vdc, 125 Vac, 2A)

Maximum Switching Voltage

220 Vdc, 250 Vac

Technical specifications

Connectivity

Control InputExternal closure < 2.5 mA @ 24 Vdc

Interval Between Outputs1 to 10 seconds nominal, front-panel adjustable

24 Vdc Output1.1 A maximum, 100 mA less than power supply current

Relay Outputs (6)SPST (closed when active)

Power & Physical

Maximum Switching Voltage220 Vdc, 250 Vac

DimensionsHeight: 1.7 in. 4.3 cm; Length: 5.8 in. 15.0 cm; Depth: 3.45 in. 8.8 cm

Shipping Weight1.11 lbs.

General

Indicators (10)Red LEDs indicating channel 'on' condition (6) Green LED indicating UP REQUEST Green LED indicating sequence COMPLETE Red / Green LEDs indicating Remote or Front-Panel Activation

Open Collector (6)200 mA surge; 50 mA continuous; 200 mA maximum

Maximum Switching Power60 W (220 Vdc, 125 Vac, 2A)

Maximum Switching Current2 A

Maximum Carrying Current3 A

Ambient Operating Environment0° C to 50° C

Power Requirement24 Vdc @ 100 mA (plus total load current connected to 24 Vdc output)

Documents

Radio Design Labs RU-SQ6A Sequencing Controller - Power up, power down — RDL Datasheet
