Home / Meeting Room Solutions / Logitech Rally Camera Extension Kit

Logitech

Logitech Rally Camera Extension Kit

Name: Logitech Rally Camera Extension Kit
Brand: Logitech
SKU: 952-000217
Price: 657.60 GBP
Availability: LimitedAvailability

£657.60inc. VAT

£548.00 ex. VAT

Low stock (4 left), order soon

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

In UK stock, ships from the UK
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

2 Years Warranty Included

Key specifications

Maximum extension distanceUp to 100 m

Category cable supportCat5e or better, cable diameter up to 7.4 mm; performance and length vary by cable

Camera side base diameter153.3 mm

Camera side base height31.5 mm

Camera side base weight255.8 g

Control side box dimensions (L x W x H)134.7 x 117.2 x 22.8 mm

Control side box weight137.5 g

Twist-to-lock mount plate137.6 mm diameter, 18.6 mm high, 42.1 g

All 20 specifications

Description

The Rally Camera Extension Kit separates a Logitech Rally Camera from the device driving it. A camera side base sits under the camera and links back over a single category cable to a control side box at the PC, which presents the camera over USB-C. That takes the camera up to 100 m from the room system on Cat5e or better with a cable diameter up to 7.4 mm, with actual reach depending on the cable used.

Full specifications Datasheet Compare alternatives

The camera side base is a 153.3 mm disc with an integrated USB-C lead to the Rally Camera, an RJ45 to the control side and an LED status indicator. It mounts on VESA 75 x 75 mm, on 5/8-27 or 1/4-20 tripod threads, or directly onto the supplied twist-to-lock plate. The control side box carries a reboot button and status LED on the front, and USB-C, RJ45, DC power, cable retention and two mounting slots on the rear so it can be fixed to a wall, table or shelf.

Everything needed to install is in the box: both units, the twist-to-lock mounting plate, a power adapter with regional plugs, a 2 m USB-C to USB-C cable with a USB-C to USB-A adapter, and a 5/8-27 to 1/4-20 threaded adapter. The kit requires a Rally Camera and a host running Windows 10 or later, or one of the two most recent macOS releases. Note that this product is listed by some distributors as an Expansion Kit; Logitech's own name for part number 952-000217 is the Rally Camera Extension Kit.

Supplied by TopAV. Manufacturer part number 952-000217.

Key features

Extends a Rally Camera

Moves a Logitech Rally Camera away from the host PC over a single category cable

Reach

Cat5e or better with cable diameter up to 7.4 mm, up to 100 m; performance varies by cable

Camera side base

153.3 mm base with integrated USB-C lead to the camera, RJ45 to the control side and a status LED

Control side box

USB-C to the host device, RJ45 to the camera, DC power, reboot button, cable retention and wall or shelf mounting slots

Mounting options

VESA 75 x 75 mm, 5/8-27 and 1/4-20 tripod threads, and the supplied twist-to-lock plate

Requirement

Requires a Logitech Rally Camera; Windows 10 or higher, or the two most recent macOS versions

Technical specifications

Connectivity

Category cable supportCat5e or better, cable diameter up to 7.4 mm; performance and length vary by cable

Camera side portsIntegrated USB-C cable to Rally Camera, RJ45 to control side box, LED status indicator

Control side portsFront: reboot button and LED status indicator. Rear: USB-C to user device, RJ45 to camera side base, DC power, cable retention, mounting slots

USB-C to USB-C cable length2 m

USB-C to USB-A adapter2.1, 37 mm

Power & Physical

Camera side base height31.5 mm

Camera side base weight255.8 g

Control side box dimensions (L x W x H)134.7 x 117.2 x 22.8 mm

Control side box weight137.5 g

Power supply dimensions68.9 x 33.9 x 71.3 mm

Certifications & Warranty

Warranty2-year limited hardware warranty

General

Maximum extension distanceUp to 100 m

Camera side base diameter153.3 mm

Twist-to-lock mount plate137.6 mm diameter, 18.6 mm high, 42.1 g

MountsVESA 75 x 75 mm; tripod 5/8-27 and 1/4-20; twist-to-lock plate; 2 through-slots on the control side box

System requirementsRequires a Logitech Rally Camera; Windows 10 and higher; macOS two most recent versions; USB 2.0 compatible devices

Power supply100-240 V, 48 V, 1.0 A

DC cable length1.5 m

Part number (worldwide)952-000217

In the boxCamera side base, control side box, twist-to-lock mounting plate, power adapter with regional plugs, 2 m USB-C to USB-C cable with USB-C to USB-A adapter, 5/8-27 to 1/4-20 threaded adapter

Documents

Logitech Rally Camera Extension Kit datasheet (PDF)
