iiyama LH7564UHS-B1AG 75-inch 4K commercial display
- Visa
- Mastercard
- American Express
- PayPal
Or 3 interest-free payments of £433.00 with PayPal Pay in 3.
Independently reviewed on TrustpilotSeen it cheaper? We price-match genuine like-for-like quotes. How it works
- In UK stock, ships from the UK
- UK manufacturer warranty
- UK-based engineers
- No import duty or customs charges
- GBP pricing, UK VAT invoices
A 75-inch 4K UHD commercial signage display rated for 24/7 use, with a VA panel at 5000:1 contrast and Android 14 with iiSignage2 content management built in, for an atrium, concourse or large reception wall.
TopAV buying advice
Is the iiyama LH7564UHS-B1AG right for your reception?
The largest size in the range, for a room where a smaller screen disappears.
Shortlist the LH7564UHS-B1AG for an atrium, a concourse, a large reception, a showroom or a canteen wall where a 65-inch screen would be lost in the space. Four times the pixel count of a 1080p panel means a departure board, a room list or a price grid still reads cleanly at this size rather than looking soft, and the VA panel at 5000:1 static contrast keeps video and dark imagery solid across the room. The practical questions are the wall and the route: it is 27.7kg unboxed and 39.1kg in its packaging, and it draws 219W typical.
Reasons to shortlist it
- At 75 inches with 4K resolution the screen can carry dense content across a large space. A split layout with a video panel, a live feed and a text column stays legible from the far side of a concourse, where a smaller screen would force you to strip the design back to a headline.
- The VA panel is rated at 5000:1 static contrast, so video and dark photography hold their depth in a low-lit atrium or an evening showroom instead of turning grey. At this size, blacks that lift are visible from anywhere in the room.
- The whole content system is inside the display. Android 14 runs iiSignage2 for scheduling and playlists, iiControl for managing the device remotely, iiShare and EShare for casting, a browser, a PDF and media player and a file manager on a 4GB and 32GB platform, so nothing extra has to be hidden behind a screen this size once it is on the wall.
- It is rated for 24/7 non-stop operation with a 50,000 hour MTBF figure and a fanless chassis, with anti image retention for static logos and banners and FailOver to switch to a backup source on its own when the primary signal drops. Getting a screen this heavy down for service is exactly what you want to avoid.
- Two HDMI 2.0 inputs take 3840 x 2160 at 60Hz and a USB-C input carries picture over DP Alt Mode with 15W returned down the same lead, on a 1679 x 957.1 x 68.8mm chassis that mounts landscape or portrait with a wall mounting kit in the box.
Check before you choose
- This is a 27.7kg display, 39.1kg boxed, and 1679mm wide. Check the access route, the lift or stairwell and the wall construction before you order, and plan on more than two people for a high fix. A screen this size on an inadequate fixing is a genuine safety problem rather than an inconvenience.
- 500 cd/m2 is an indoor brightness. It suits an atrium, a concourse or a reception away from direct sun, but a screen behind glazing with daylight on it will look washed out no matter how large it is. Measure the light at the actual position, and ask us about the high-brightness tier if the position is bright.
- The built-in speakers are 2 x 10W, which is close-range audio on a screen meant to be seen across a large space, and the typical draw is 219W. Budget for external amplification on the 3.5mm audio output if sound matters, and confirm there is a socket where the screen will hang rather than a trailing lead.
See the 75" on your wall, to scale
On a phone, point your camera at the wall and see the 75" there at its real size. On a computer, upload a photo of the wall (or scan the QR code to take one with your phone and it will appear here) and drag the display around it to scale.
Not sure 75" is the right size for the room? The screen size calculator shows how far a 75" display carries for presentations, touch work and video.
What to plan before installing the LH7564UHS-B1AG
01
Position, light & access
Fix the viewing position and measure the daylight falling on it, because 500 cd/m2 is an indoor figure. At the same time walk the delivery route: 1679 x 957.1 x 68.8mm and 39.1kg boxed has to get through the doors, the lift and any turn on the way. Settle landscape or portrait now, since it changes both the bracket and the content template.
02
Mounting & power
The display is 27.7kg without its box and a wall mounting kit is included, but the wall has to carry it and a high fix needs more than two pairs of hands. Confirm the construction and the fixings, allow for a 219W typical draw and a 0 to 40C operating range, and put a socket where the screen will hang. The mounting pattern is in the specification table. iiyama lists a 500 x 500 mm VESA pattern.
03
Content & network
Decide whether the schedule runs on the built-in Android system with iiSignage2 or on an external player over HDMI, and agree network access with your IT team early, because iiControl and remote support both need it. On a screen this hard to reach, remote management is worth setting up properly on day one. Tell us if you want the bracket, the cabling or the installation quoted alongside the display.
Display price is for the panel. Installation and optional equipment are quoted separately. Purchase-order terms are available to approved education customers.
Build a quote you can compare
Include these details in your project enquiry so the quote covers the room as well as the screen.
- Number of displays, site postcode and required date.
- Furthest viewing distance and available wall space.
- Wall type, fixed mount or adjustable trolley, and cable routes.
- Laptop model, teaching apps, and any camera or Windows PC needs.
Ask for separate equipment, delivery, installation and licence costs, with a total including VAT. Confirm warranty coverage and any registration requirements before placing the order.
Complete your setup
What else the LH7564UHS-B1AG needs
The price above is for the display on its own. A wall mount or trolley is a separate purchase, and installation is quoted per site. Add what you need here and it joins the same basket.
Choose a mount
Professional Installation
Want it installed by our AV experts? We offer professional on-site installation including mounting, cable management, and system configuration.
Compare your shortlist
iiyama LH7564UHS-B1AG vs LH6564UHS-B1AG: 75-inch or 65-inch?
Choose around the room and the content people need to read, not the model number.
| Feature | LH7564UHS-B1AG | LH6564UHS-B1AG |
|---|---|---|
| Screen Size | 75 in | 65 in |
| Resolution | 3840 x 2160 (4K UHD) | 3840 x 2160 (4K UHD) |
| Brightness | 500 cd/m² | 500 cd/m² |
| Contrast Ratio | 5000:1 | 5000:1 |
| Speakers | 2 x 10W | 2 x 10W |
| Power Consumption | 219 W | 184 W |
Specifications checked on 13 September 2026: iiyama ProLite LH7564UHS-B1AG (opens in a new tab) and iiyama VisionCare warranty table (opens in a new tab). Buying advice is based on published specifications; confirm the supplied configuration for either model.
See this 75-inch display to scaleiiyama LH7564UHS-B1AG specifications and documents
iiyama specifications (opens in a new tab)Choose a section to view its specifications.
Display (7)
- Screen Size
- 75 in
- Resolution
- 3840 x 2160 (4K UHD)
- Aspect Ratio
- 16:9
- Brightness
- 500 cd/m²
- Contrast Ratio
- 5000:1
- Panel Type
- VA, anti-glare coated glass, matte finish
- Backlight Life
- 50,000 hours MTBF (excluding backlight)
Connectivity (4)
- USB-C Power Delivery
- 15 W
- HDMI Inputs
- 2
- WiFi
- Built-in, 2.4G/5G
- USB Ports
- 2 x USB 2.0
Audio (1)
- Speakers
- 2 x 10W
Power & Physical (7)
- Size Band
- 65 - 79"
- Power Consumption
- 219 W
- VESA Mount
- 500 x 500 mm
- Weight
- 27.7 kg
- Shipping Weight
- 39.1 kg
- Product Dimensions (W x H x D)
- 1679 x 957.1 x 68.8 mm
- Housing Material
- Plastic
Certifications & Warranty (1)
- Warranty
- 3 years iiyama VisionCare (onsite exchange, mainland UK and Ireland)
General (14)
- Energy efficiency class
- G
- Operating System
- Android 14
- Orientation
- Landscape / Portrait
- RAM
- 4GB
- Storage
- 32GB
- Glass
- Anti-glare coated, matte finish, 25% haze
- Max Non-stop Operating Time
- 24/7
- Response Time (GTG)
- 6.5 ms
- Integrated Software
- iiSignage², iiControl, iiShare, EShare, FailOver, TeamViewer, PDF & Media Player, iiBrowser, File manager
- Fanless Design
- Yes
- Operating Temperature Range
- 0 to 40 °C
- Processor / Memory
- CPU A73x4, GPU G52 MC1, 4GB RAM / 32GB storage
- Manufacturer part number
- LH7564UHS-B1AG
- GTIN
- 4948570125333
Specifications are iiyama's published figures. Checked on 13 September 2026. The buying advice is our own, from specifying and installing equipment like this in UK classrooms and meeting rooms.
iiyama LH7564UHS-B1AG questions answered
Who is the iiyama ProLite LH7564UHS-B1AG best suited to?
Consider it for an atrium, a concourse, a large reception, a showroom or a canteen wall where a smaller screen would be lost in the space. It is a commercial signage display built to play managed content all day in a public place, not a meeting-room screen and not a television.
Does it need a separate media player?
No. Android 14 runs on the display itself with 4GB of memory and 32GB of storage, iiSignage2 for scheduling and playlists, iiControl for remote device management, iiShare and EShare for casting and a built-in browser, media player and file manager. Two HDMI 2.0 inputs and a USB-C input are there if you would rather drive it from a player or a PC you already own.
How heavy is it and what does installation involve?
It is 27.7kg without its box and 39.1kg boxed, measuring 1679 x 957.1 x 68.8mm, and a wall mounting kit is supplied. Walk the delivery route before you order, because the boxed dimensions decide whether it gets through the doors and the lift, and plan a high fix with more than two people. The wall has to carry the bracket, so confirm the construction and the fixings first.
Is it bright enough for a glazed frontage?
No, not where daylight falls on the glass. The panel is 500 cd/m2, which is the indoor signage tier and is right for an atrium, a concourse or a reception away from the sun. A glazed frontage needs the high-brightness tier instead, so measure the light at the position and ask us before committing to it.
Will video and dark photography look good on it?
Yes. The VA panel is rated at 5000:1 static contrast, so blacks stay dark rather than lifting to grey, which is what makes video and photography hold up in a dim atrium or an evening showroom. The larger the screen, the more obvious weak contrast becomes from across the room.
Can it be mounted in portrait?
Yes. iiyama lists landscape and portrait orientation for this model, so it works as a wide information wall or as a tall vertical panel beside an entrance. Decide which before you order the bracket and build the content template to match, because rotating a landscape playlist after installation usually means reauthoring it, and this is not a screen you want to take down twice.
Can it be left on all the time?
Yes. It is rated for 24/7 non-stop operation with a 50,000 hour MTBF figure and no cooling fan, which is what separates a commercial signage display from a consumer television pressed into the same job. Anti image retention also makes a static logo or a fixed banner less likely to leave a ghost on the panel.
What can I plug into it?
Two HDMI 2.0 inputs, each taking 3840 x 2160 at 60Hz, and one USB-C input carrying picture over DP Alt Mode with 15W of power returned down the same cable. There are also two USB 2.0 ports, a 3.5mm audio output, built-in 2.4G and 5G WiFi and wired LAN, plus RS-232C and IR control inputs for a room control system.
How do I manage it once it is on the wall?
iiSignage2 schedules the content remotely and iiControl manages the hardware, so power states and settings can be changed without a ladder, with TeamViewer installed for remote support. On a display this size and this hard to reach, getting the network access agreed with your IT team before installation is worth more than it sounds.
Should I choose the 75-inch LH7564UHS-B1AG or the 65-inch LH6564UHS-B1AG?
Both use the same VA panel at 5000:1 contrast, the same 500 cd/m2 brightness, the same Android 14 platform, the same mounting pattern and the same 2 x 10W speakers, so the choice is about the space and the install. This 75-inch is 27.7kg against 17.7kg and draws 219W against 184W, and it is 1679mm wide against 1457.7mm, which can decide whether it fits the wall or the lift at all. Take the 75 where the room is large and the audience is far back, and the 65 where the access route, the wall or the budget sets the limit.
Trusted by thousands of customers
Explore recent installations
See recent installations supplied by StriveAV, TopAV’s parent company. Customer names are masked for privacy.
Alternative products
Closest matches in this category on price and capability. Not sure which way to go? Our technical team will talk it through.

Sony FW-75BZ30L 75" 4K Signage Display

Sony FW-75EZ20L 75" 4K Signage Display
