Home / Extenders / Kramer PT-871/2xr-KIT 4K HDR HDMI Compact PoC Extender over Long-Reach DGKat 2.0
Kramer

Kramer PT-871/2xr-KIT 4K HDR HDMI Compact PoC Extender over Long-Reach DGKat 2.0

£391.20inc. VAT
£326.00 ex. VAT
Out of stock
1
  • Visa
  • Mastercard
  • American Express
  • PayPal

Or 3 interest-free payments of £130.40 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →
  • Sourced through UK distribution
  • UK manufacturer warranty
  • UK-based engineers
  • No import duty or customs charges
  • GBP pricing, UK VAT invoices
Return within 14 days
Installation services availablePurchase orders: education customers only
3 Years Warranty Included
Key specifications
Inputs - 1 HDMIOn an HDMI female connector (PT-871xr)
Inputs - 1 DGKatOn an RJ-45 female connector for extension line (PT-872xr)
Outputs - 1 DGKatOn an RJ-45 female connector for extension line (PT-871xr)
Outputs - 1 HDMIOn an HDMI female connector (PT-872xr)
Video - Transmitted Data BandwidthUp to 18Gbps (6Gbps per graphic channel).
Video - Max Resolution at High Compression Level3840x2160@60Hz (4:4:4) 24bpp
Video - Max Resolution at Standard Compression Level4096x2160@60Hz (4:4:4) 24bpp
Video - Standards ComplianceHDR10, HDCP 2.2.
All 25 specifications

Description

PT-871/2xr-KIT is a high-performance, long-reach DGKat™ 2.0 extender kit for 4K@60Hz (4:4:4) HDR HDMI and HDCP 2.2 signals and 2-way powering over twisted pair. The PT-871xr transmitter converts the HDMI input signal into a DGKat™ 2.0 signal. The PT-872xr receiver converts the transmitted DGKat™ 2.0 signal into an HDMI signal. PT-871/2xr-KIT extends video signals to up to 60m (200ft) at 4K@60Hz (4:4:4) resolution and up to 70m (230ft) at 4K@30Hz (4:4:4) 24bpp resolution over Kramer shielded cables. Manufacturer part number PT-871/2XR-KIT.

Full specifications Datasheet Compare alternatives

Key features

High Performance Extender - Professional DGKat™ 2.0 extender kit for

High Performance Extender - Professional DGKat™ 2.0 extender kit for providing long-reach signals and 2-way power over twisted pair copper infrastructures. PT-871/2xr-Kit extender employs low-level video compression technology that delivers visually lossless performance for 4K@60Hz (4:4:4) HDR signals with near-zero latency. PT-871xr converts the HDMI input signal into a DGKat™ 2.0 signal. PT-872xr converts the transmitted DGKat™ 2.0 signal into an HDMI signal. PT-871/2xr-KIT extends video signals to up to 60m (200ft) at 4K@60Hz (4:4:4) resolution and up to 70m (230ft) at 4K@30Hz (4:4:4) 24bpp

HDMI Signal Extension - HDR, HDCP 2.2 compliant. Supports deep color

HDMI Signal Extension - HDR, HDCP 2.2 compliant. Supports deep color, x.v.Color™, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS-HD, 2K, 4K, and 3D as specified in HDMI 2.0.

EDID Pass-through - Pass-through algorithm ensures Plug and Play

EDID Pass-through - Pass-through algorithm ensures Plug and Play operation for HDMI source and display systems.

Multi-channel Audio Extension - Up to 32 channels of digital stereo

Multi-channel Audio Extension - Up to 32 channels of digital stereo uncompressed signals for supporting studio-grade surround sound.

Cost-Effective Maintenance - Status LED indicators for HDMI and

Cost-Effective Maintenance - Status LED indicators for HDMI and DGKat™ 2.0 ports facilitate easy local maintenance and troubleshooting.

Easy Installation - Single twisted-pair cable for signal and power

Easy Installation - Single twisted-pair cable for signal and power wiring. Compact Pico TOOLS™ fan-less enclosure for device-back mounting, or side-by-side mounting of 4 units in a 1U rack space with the recommended rack adapter.

Technical specifications

Display
Video - Max Resolution at High Compression Level3840x2160@60Hz (4:4:4) 24bpp
Video - Max Resolution at Standard Compression Level4096x2160@60Hz (4:4:4) 24bpp
Connectivity
Inputs - 1 HDMIOn an HDMI female connector (PT-871xr)
Inputs - 1 DGKatOn an RJ-45 female connector for extension line (PT-872xr)
Outputs - 1 DGKatOn an RJ-45 female connector for extension line (PT-871xr)
Outputs - 1 HDMIOn an HDMI female connector (PT-872xr)
Video - HDMI SupportDeep color, x.v.Color™, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS-HD, 2K, 4K, and 3D as specified in HDMI 2.0.
Power & Physical
Video - Transmitted Data BandwidthUp to 18Gbps (6Gbps per graphic channel).
Enclosure - SizePico Tools
Certifications & Warranty
Video - Standards ComplianceHDR10, HDCP 2.2.
Extension Line - ComplianceDGKat 2.0
General
High Compression Reach Extension - Using Shielded UNIKAT CabUp to 60m (200ft) at 4K@60Hz (4:4:4), Up to 70m (230ft) at 4K@30Hz (4:4:4) or full HD (1080p @60Hz 36bpp)
High Compression Reach Extension - Using Plenum HDKat CablesUp to 40m (130ft) at 4K@60Hz (4:4:4), Up to 50m (160ft) at 4K@60Hz (4:2:0) or full HD (1080p @60Hz 36bpp)
Standard Compression Reach Extension - Using Shielded UNIKATUp to 40m (130ft) at 4K@60Hz (4:4:4), Up to 70m (230ft) at 4K@30Hz (4:4:4) or full HD (1080p @60Hz 36bpp)
Extension Line - Signal CompressionStandard or high compression level applied to >1080p signals
User Interface - IndicatorsIN, OUT, and ON LEDs.
User Interface - ControlsDip-switches to define compression level
Power - Source12V DC, 2A
Power - Consumption600mA
Environmental Conditions - Operating Temperature0° to +40°C (32° to 104°F).
Environmental Conditions - Storage Temperature-40° to +70°C (-40° to 158°F) .
Environmental Conditions - Humidity10% to 90%, RHL non-condensing.
Enclosure - TypeAluminum.
Enclosure - CoolingConvection ventilation
Accessories - Included1 power adapter with cord, 2 bracket sets.

Documents

Kramer PT-871/2xr-KIT 4K HDR HDMI Compact PoC Extender over Long-Reach DGKat 2.0 — manufacturer spec sheet
Kramer PT-871/2xr-KIT 4K HDR HDMI Compact PoC Extender over Long-Reach DGKat 2.0 — manufacturer manual
