Home / Extenders / Kramer EXT3-U3-T USB 3.2 Gen 1 Transmitter unit (host side)
Kramer

Kramer EXT3-U3-T USB 3.2 Gen 1 Transmitter unit (host side)

£374.40inc. VAT
£312.00 ex. VAT
Out of stock
1
  • Visa
  • Mastercard
  • American Express
  • PayPal

Or 3 interest-free payments of £124.80 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →
  • Sourced through UK distribution
  • UK manufacturer warranty
  • UK-based engineers
  • No import duty or customs charges
  • GBP pricing, UK VAT invoices
Return within 14 days
Installation services availablePurchase orders: education customers only
3 Years Warranty Included
Key specifications
Inputs - 1 CATOn an RJ-45 female connector for extension line (EXT3-U-R)
Outputs - 1 CATOn an RJ-45 female connector for extension line (EXT3-U-T)
Ports - 1 USBOn a USB-B female connector for USB host extension (EXT3-U-T)
Ports - 3 USBOn USB-A female connectors for USB devices extension (EXT3-U-R)
Ports - 1 RS-232On a 3-pin terminal block connector for serial link extension
USB Features - Integrated USB HubsRx: 1
Traffic Rate5 GBps
Extension LinkHDBaseT USB over CATx
All 24 specifications

Description

EXT3-U3-KIT is a comprehensive, extended-reach CAT extender solution for USB 3.2 Gen1 (5 GBps) communication. The extender supports both USB3.2 Gen1 devices and legacy USB2.0/1.1 devices. In addition to USB3, RS232 signals and FSYNC video signal (for camera frame synchronization) are extended. The EXT3-U3-T transmitter unit converts the USB3 host side signal into a CATx signal format based on HDBaseT USB. The EXT3-U3-R receiver unit converts the CATx signal back into a USB3 device side signal and functions as a USB hub for up to 3 devices. The extender operates seamlessly as a plug&play device with no need for any prior configuration. It supports a wide Variety of USB peripheral devices supporting all USB transaction modes including interrupt, bulk and isochronous and is especially suitable for high throughput video streaming USB devices such as cameras and capture devices. EXT3-U3-KIT uses power delivery over the CATx cable requiring only one side to facilitate a power source. These devices may be sold together as an extender bundle or separately (paired with other HDBaseT USB3 (VS6320 based) products). Kramer publishes EXT3-U3-T as a configuration of the EXT3-U3-KIT USB 3.2 Gen 1 Extender; the specifications below are the manufacturer's for that extender set. Manufacturer part number EXT3-U3-T.

Full specifications Datasheet Compare alternatives

Key features

Comprehensive USB Extender - Plug & play USB extender kit fo

Comprehensive USB Extender - Plug & play USB extender kit for providing extended-reach CAT signals and 2-way power over twisted pair copper infrastructures. A local USB host is auto-connected to remote-connected USB devices employing either interrupt, bulk or isochronous USB 2.0 standard data transfer communication.

Flexible USB Connectivity - Wide Variety of USB peripheral d

Flexible USB Connectivity - Wide Variety of USB peripheral devices can be extended including cameras, touch screens, smart boards, hard drives, game controllers, audio devices, printers, scanners, or HID (Human Interface Devices) devices such as a mouse or keyboard. Dual role and OTG (On The Go ) devices such as smart phones and tablets, connected either to a transmitter-side USB host port or receiver-side USB device port, can communicate with a remote host or peripheral pairing device.

Remote USB Charging - Fast USB charging of peripheral device

Remote USB Charging - Fast USB charging of peripheral devices when the receiver is powered by a power supply, and standard USB charging when the receiver is powered by the transmitter via CAT.

Bidirectional RS-232 Extension - Serial interface data flows

Bidirectional RS-232 Extension - Serial interface data flows in both directions, allowing data transmission and device control.

Cost-Effective Maintenance - Status LED indicators facilitat

Cost-Effective Maintenance - Status LED indicators facilitate easy local maintenance and troubleshooting.

Technical specifications

Connectivity
Inputs - 1 CATOn an RJ-45 female connector for extension line (EXT3-U-R)
Outputs - 1 CATOn an RJ-45 female connector for extension line (EXT3-U-T)
Ports - 1 USBOn a USB-B female connector for USB host extension (EXT3-U-T)
Ports - 3 USBOn USB-A female connectors for USB devices extension (EXT3-U-R)
Ports - 1 RS-232On a 3-pin terminal block connector for serial link extension
USB Features - Integrated USB HubsRx: 1
Extension Line - Integrated USB HubsRx: 1
EXT3-U-R USB CHARGINGPoE+ as PSE or PD
EXT3-U-T USB CHARGINGPoE+ (PSE or PD)
BALANCED LINE LEVEL INPUT - Operating Temperature0° to +40°C (32° to 104°F)
Power & Physical
Enclosure - SizeDemi Tools
General
Traffic Rate5 GBps
Extension LinkHDBaseT USB over CATx
Reach Distance100 meters
Power - Source12V DC, 2A
Power - IndicatorsLINK and ON LEDs
Power - EXT3-U-T Consumption1.1A
Enclosure - EXT3-U-R Consumption1.85A
Enclosure - TypeAluminum
EnclosurePassive (EXT3-U-R)
Storage Temperature-40° to +70°C (-40° to 158°F)
Humidity10% to 90%, RHL non-condensing
REGULATORY - SafetyCE, FCC, UL
REGULATORY - EnvironmentalRoHs, WEEE

Documents

Kramer EXT3-U3-T USB 3.2 Gen 1 Transmitter unit (host side) — manufacturer spec sheet (EXT3-U3-KIT)
Kramer EXT3-U3-T USB 3.2 Gen 1 Transmitter unit (host side) — manufacturer manual
