Home / Extenders / INOGENI U-BRIDGE USB 2.0 Camera and Device Extender over CAT5e/6/7

INOGENI

INOGENI U-BRIDGE USB 2.0 Camera and Device Extender over CAT5e/6/7

Name: INOGENI U-BRIDGE USB 2.0 Camera and Device Extender over CAT5e/6/7
Brand: INOGENI
SKU: U-BRIDGE
Price: 408.00 GBP
Availability: OutOfStock

£408.00inc. VAT

£340.00 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £136.00 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

5 Years Warranty Included

Key specifications

Enclosure MaterialBlack ABS with rubberised coating

MountingSlots for cable ties

Consumed USB Tiers1 tier

Package Dimensions24.5 cm x 25 cm x 7.9 cm (9.65" x 9.84" x 3.11")

Package Weight1190 g (2.62 lb)

Power Supply100-240 V AC input, 24 V 1 A DC output; applied at either the PC Host or Device module

Operating Temperature0 to 50 C (32 to 122 F)

Operating Humidity20% to 80% relative humidity, non-condensing

All 18 specifications

Description

The INOGENI U-BRIDGE is a two-module USB 2.0 extender that enables high-speed USB 2.0 connections up to 100 m / 330 ft over a single CAT5e/6/7 cable. It supports all USB 2.0/1.1 devices and is designed for USB cameras, whiteboards, microphones, audio devices and other peripherals. Either the PC HOST or the DEVICE module can be powered, it is plug and play with no software drivers required, and it works with Windows, macOS and Linux.

Full specifications Datasheet Compare alternatives

In the box: 1x PC HOST extender module; 1x DEVICE extender module; 1x USB 2.0 cable; 1x Quick Start Guide; 1x power supply 100-240 V AC input, 24 V 1 A DC output; international power adapter with country-specific cord (North America, EU, UK, Australia/NZ or Japan)

Key features

100 m USB 2.0 extension

Direct connection up to 100 m / 330 ft over CAT5e/6/7; USB 2.0 up to 480 Mbps and USB 1.1 up to 12 Mbps.

Two modules

PC Host extender with 1x USB Type-B receptacle and 1x RJ45; Device extender with 1x USB Type-A receptacle, 1x RJ45 and up to 1 A available to the USB port.

Flexible powering

The supplied 24 V 1 A power supply can be applied at either the PC HOST or the DEVICE module.

Broad camera compatibility

INOGENI state it is compatible with all USB cameras including Huddly, HuddleCamHD, AVer, Jabra, Logitech and Marshall cameras, as well as webcams.

No drivers

Plug-and-play with no software drivers required; works with Windows, macOS and Linux.

Technical specifications

Connectivity

Consumed USB Tiers1 tier

USB SpeedsUSB 2.0 up to 480 Mbps; USB 1.1 up to 12 Mbps

PC Host Module Connectors1x USB Type-B receptacle, 1x RJ45

Device Module Connectors1x USB Type-A receptacle, 1x RJ45

Power & Physical

Enclosure MaterialBlack ABS with rubberised coating

MountingSlots for cable ties

Package Dimensions24.5 cm x 25 cm x 7.9 cm (9.65" x 9.84" x 3.11")

Package Weight1190 g (2.62 lb)

Module Dimensions (W x L x H)6.4 cm x 8.75 cm x 3.0 cm (2.52" x 3.44" x 1.18") each

Module WeightsPC Host 80 g (0.18 lb); Device 90 g (0.20 lb)

Certifications & Warranty

CertificationsEMC: FCC (Class A), CE (Class A); Environmental: RoHS2, REACH, Conflict Minerals; Safety: Flammability V-0, IEC62368-1, RCM

General

Power Supply100-240 V AC input, 24 V 1 A DC output; applied at either the PC Host or Device module

Operating Temperature0 to 50 C (32 to 122 F)

Operating Humidity20% to 80% relative humidity, non-condensing

OriginDesigned in Canada and made in China

In the box1x PC HOST extender module; 1x DEVICE extender module; 1x USB 2.0 cable; 1x Quick Start Guide; 1x power supply 100-240 V AC input, 24 V 1 A DC output; international power adapter with country-specific cord (North America, EU, UK, Australia/NZ or Japan)

RangeDirect connect up to 100 m / 330 ft over CAT5e/6/7

Available Current (Device module)Up to 1 A to the USB port

Documents

INOGENI U-BRIDGE USB 2.0 Camera and Device Extender over CAT5e/6/7 datasheet
