Kramer DTAxr-OUT2-F16 2-Channel 4K60 4:2:0 HDMI over Extended Reach HDBaseT Output Card

Name: Kramer DTAxr-OUT2-F16 2-Channel 4K60 4:2:0 HDMI over Extended Reach HDBaseT Output Card
Brand: Kramer
SKU: DTAXR-OUT2-F16/STANDALONE
Price: 1411.20 GBP
Availability: OutOfStock

£1,411.20inc. VAT

£1,176.00 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £470.40 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Call 01342 580255

Return within 14 days

Installation services available Purchase orders: education customers only

3 Years Warranty Included

Key specifications

Outputs2 HDBaseT TP on RJ-45 connectors

Ports2 RS-232 and 2 IR on a 10 pin terminal block for bidirectional RS-232 and IR extension

BANDWIDTH PER CHANNELVideo: 3.4Gbps

TOTAL BANDWIDTHVideo: 10.2Gbps

MAXIMUM RANGEUp to 100m at normal mode (4K), up to 130m (430ft) at normal mode (2K), up to 180m (590ft) ultra mode (1080p @60Hz @24bpp)

3D PASS THROUGHSupported.

Extended EthernetUp to 100Mbps extended line rate bandwidth.

Extended RS-232300 to 115200 baud rate

All 14 specifications

Description

DTAxr-OUT2-F16 is a two-channel HDMI, analog audio, bidirectional RS-232, Ethernet, & IR over HDBaseT twisted pair transmitter card for the VS-1616 Series Modular Multi-Format Digital Matrix Switchers. The DTAxr-OUT2-F16 outputs two extended reach HDBaseT signals with selectable embedded/de-embedded analog audio, bidirectional RS-232, IR, and Ethernet from the chassis to the line. Manufacturer part number DTAXR-OUT2-F16/STANDALONE.

Full specifications Datasheet Compare alternatives

Call 01342 580255

Key features

Max. Data Rate - 10.2Gbps (3.4Gbps per graphic channel).

Max. Resolution - 4K@60Hz (4:2:0).

Analog Audio Embedding/De-embedding - On the same jack

HDBaseT Technology - HDTV compatible, HDCP compliant.

System Range - Up to 100m at normal mode (4K), up to 130m (430ft) at

System Range - Up to 100m at normal mode (4K), up to 130m (430ft) at normal mode (2K), up to 180m (590ft) ultra mode (1080p @60Hz @24bpp). Note: When using Kramer HDBaseT cables.

Ethernet Extension - Ethernet interface data flows in both

Ethernet Extension - Ethernet interface data flows in both directions, allowing extension of up to 100Mbps Ethernet connectivity for LAN communication and device control.

Bidirectional RS-232 Extension - Serial interface data flows in both

Bidirectional RS-232 Extension - Serial interface data flows in both directions, allowing data transmission and device control.

Bidirectional Infrared Extension - IR interface data flows in both

Bidirectional Infrared Extension - IR interface data flows in both directions, allowing remote control of peripheral devices located at either end of the extended line.

3D Pass-Through.

Technical specifications

Connectivity

Outputs2 HDBaseT TP on RJ-45 connectors

Ports2 RS-232 and 2 IR on a 10 pin terminal block for bidirectional RS-232 and IR extension

Extended EthernetUp to 100Mbps extended line rate bandwidth.

Power & Physical

BANDWIDTH PER CHANNELVideo: 3.4Gbps

TOTAL BANDWIDTHVideo: 10.2Gbps

POWER CONSUMPTION13W.

Certifications & Warranty

STANDARD COMPLIANCEHDCP 1.4, HDMI 1.3a, HDBaseT.

SAFETY REGULATORY COMPLIANCECE.

General

MAXIMUM RANGEUp to 100m at normal mode (4K), up to 130m (430ft) at normal mode (2K), up to 180m (590ft) ultra mode (1080p @60Hz @24bpp)

3D PASS THROUGHSupported.

Extended RS-232300 to 115200 baud rate

OPERATING TEMPERATURE0° to +40°C (32° to 104°F).

STORAGE TEMPERATURE-40° to +70°C (-40° to 158°F) .

HUMIDITY10% to 90%, RHL non-condensing.

Call 01342 580255

Documents

Kramer DTAxr-OUT2-F16 2-Channel 4K60 4:2:0 HDMI over Extended Reach HDBaseT Output Card — manufacturer spec sheet

Kramer DTAxr-OUT2-F16 2-Channel 4K60 4:2:0 HDMI over Extended Reach HDBaseT Output Card — manufacturer manual
