Home / Matrix Switchers & Splitters / ATEN VanCryst VM6404HB 4 x 4 True 4K HDMI Matrix Switch with Scaler

ATEN

ATEN VanCryst VM6404HB 4 x 4 True 4K HDMI Matrix Switch with Scaler

Name: ATEN VanCryst VM6404HB 4 x 4 True 4K HDMI Matrix Switch with Scaler
Brand: ATEN
SKU: VM6404HB
Price: 3030.50 GBP
Availability: OutOfStock

£3,030.50inc. VAT

£2,525.42 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Call 020 3815 8642

Return within 14 days

Installation services available Purchase orders: education customers only

2 Years Warranty Included

Key specifications

Video Inputs4 x HDMI Type A female

Video Outputs4 x HDMI Type A female

Maximum ResolutionUp to 4096 x 2160 / 3840 x 2160 at 60 Hz (4:4:4)

Maximum Data Rate18.0 Gbps (6.0 Gbps per lane)

Maximum Pixel Clock600 MHz

HDCPHDCP 2.2 compatible

Audio Output1 x mini stereo jack female

Control Ports1 x RS-232 DB-9 female, 1 x IR mini stereo jack, 1 x RJ-45 Ethernet

All 14 specifications

Description

The VM6404HB carries uncompressed video at up to 4096 x 2160 or 3840 x 2160 at 60 Hz with full 4:4:4 chroma across four inputs and four outputs, at a data rate of 18 Gbps. That is enough headroom for detailed source material such as CAD, medical imaging or fine text to survive the trip through the matrix intact.

Also in this range:VM0404HB VM0808HB Full specifications Datasheet Compare alternatives

A 4K scaler converts every input to the resolution its destination display prefers, while Seamless Switch keeps the stream continuous across a source change. Video wall layouts are configured from the web GUI, and the True 4K EDID Expert manages what each source is told about the displays downstream.

Management is available from the front panel, an IR remote, RS-232, or over Ethernet by Telnet and web GUI, and the unit is visible to the ATEN Video Matrix Control app. The chassis is metal and rack-mountable.

Call 020 3815 8642

Key features

True 4K throughout

Handles uncompressed 4096 x 2160 and 3840 x 2160 at 60 Hz with 4:4:4 chroma at up to 18 Gbps.

4K scaler

Converts each input to the optimum resolution for the display connected to that output.

Seamless Switch

Close-to-zero switching time for continuous video streams and stable signal transmission.

Video walls from the browser

Custom video wall layouts are created and recalled through the built-in web GUI.

Technical specifications

Choose a section to view its specifications.

Display (1)

Maximum Resolution: Up to 4096 x 2160 / 3840 x 2160 at 60 Hz (4:4:4)

Connectivity (4)

Video Inputs: 4 x HDMI Type A female
Video Outputs: 4 x HDMI Type A female
Audio Output: 1 x mini stereo jack female
Control Ports: 1 x RS-232 DB-9 female, 1 x IR mini stereo jack, 1 x RJ-45 Ethernet

Power & Physical (3)

Power Consumption: 43.1 W at 230 VAC
Dimensions: 43.24 x 26.23 x 4.40 cm
Weight: 3.52 kg

General (6)

Maximum Data Rate: 18.0 Gbps (6.0 Gbps per lane)
Maximum Pixel Clock: 600 MHz
HDCP: HDCP 2.2 compatible
EDID Modes: Default / Port 1 / Remix / Customized
Housing: Metal
Operating Temperature: 0-40 degrees C

Call 020 3815 8642

Documents

ATEN VM6404HB 4 x 4 True 4K HDMI Matrix Switch with Scaler datasheet (PDF)
