Home / Matrix Switchers & Splitters / ATEN VanCryst VM0808HB 8 x 8 True 4K HDMI Matrix Switch

ATEN

ATEN VanCryst VM0808HB 8 x 8 True 4K HDMI Matrix Switch

Name: ATEN VanCryst VM0808HB 8 x 8 True 4K HDMI Matrix Switch
Brand: ATEN
SKU: VM0808HB
Price: 1785.73 GBP
Availability: OutOfStock

£1,785.73inc. VAT

£1,488.11 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £595.25 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Call 01342 580255

Return within 14 days

Installation services available Purchase orders: education customers only

2 Years Warranty Included

Key specifications

Video Inputs8 x HDMI Type A female

Video Outputs8 x HDMI Type A female

Maximum ResolutionUp to 4096 x 2160 / 3840 x 2160 at 60 Hz (4:4:4)

Maximum Data Rate18 Gbps (6 Gbps per lane)

Maximum Pixel Clock600 MHz

HDCPHDCP 2.2 compatible

HDRHDR10+ supported

Control Ports1 x RS-232 DB-9 female, 1 x IR mini stereo jack, 1 x RJ-45 Ethernet

All 14 specifications

Description

The VM0808HB routes any of eight True 4K HDMI sources to any of eight HDMI displays without scaling or re-encoding, holding 4096 x 2160 at 60 Hz with 4:4:4 chroma and HDR10+ at signalling rates up to 18 Gbps. Dolby TrueHD and DTS-HD Master Audio pass through intact.

Also in this range:VM6404HB VM0404HB Full specifications Datasheet Compare alternatives

Power-on detection switches an output to the next powered-on source when the current one is turned off, which keeps a signage or meeting-room display showing something useful without operator intervention. EDID Expert manages resolution negotiation across the estate, and LockPro HDMI cable locking holds connectors in place.

The matrix is controlled from front-panel pushbuttons, an IR remote, RS-232 or Ethernet with web GUI and Telnet, and appears in the ATEN Video Matrix Control app. Firmware is field-upgradeable and the chassis occupies one rack unit.

Call 01342 580255

Key features

True 4K, eight by eight

Eight inputs to eight outputs at up to 4096 x 2160 at 60 Hz 4:4:4 with HDR10+ and HDCP 2.2.

Power-on detection

When a source is powered off the switch moves the output to the next available powered-on source.

Lossless audio formats

Dolby TrueHD and DTS-HD Master Audio pass through the matrix unaltered.

LockPro cable locking

Secures HDMI connectors against accidental disconnection in busy racks.

Technical specifications

Display

Maximum ResolutionUp to 4096 x 2160 / 3840 x 2160 at 60 Hz (4:4:4)

HDRHDR10+ supported

Connectivity

Video Inputs8 x HDMI Type A female

Video Outputs8 x HDMI Type A female

Control Ports1 x RS-232 DB-9 female, 1 x IR mini stereo jack, 1 x RJ-45 Ethernet

Power & Physical

Power Consumption37.8 W at 230 VAC

Dimensions43.24 x 26.23 x 4.40 cm

Weight3.99 kg

General

Maximum Data Rate18 Gbps (6 Gbps per lane)

Maximum Pixel Clock600 MHz

HDCPHDCP 2.2 compatible

EDID ModesDefault / Port 1 / Remix / Customized

HousingMetal

Operating Temperature0-40 degrees C

Call 01342 580255

Documents

ATEN VM0808HB 8 x 8 True 4K HDMI Matrix Switch datasheet (PDF) - series datasheet covering VM0404HB and VM0808HB
