Home / Matrix Switchers & Splitters / ATEN VanCryst VM5404H 4 x 4 HDMI Matrix Switch with Scaler

ATEN

ATEN VanCryst VM5404H 4 x 4 HDMI Matrix Switch with Scaler

Name: ATEN VanCryst VM5404H 4 x 4 HDMI Matrix Switch with Scaler
Brand: ATEN
SKU: VM5404H
Price: 2422.50 GBP
Availability: OutOfStock

£2,422.50inc. VAT

£2,018.75 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Call 01342 580255

Return within 14 days

Installation services available Purchase orders: education customers only

2 Years Warranty Included

Key specifications

Video Inputs4 x HDMI Type A female

Video Outputs4 x HDMI Type A female

Maximum ResolutionUp to 1080p

Maximum Data Rate6.75 Gbps (2.25 Gbps per lane)

Maximum Pixel Clock225 MHz

HDCPHDCP 1.4 compatible

Maximum Output DistanceUp to 15 m

Control Ports1 x RS-232 DB-9 female, 1 x IR mini stereo jack, 1 x RJ-45 Ethernet

All 14 specifications

Description

The VanCryst VM5404H sends any of four HDMI sources to any of four HDMI displays, with ATEN's Seamless Switch FPGA design keeping the video stream continuous through a change of source instead of dropping to black while the sink re-syncs.

Also in this range:VM5808H VM6809H Full specifications Datasheet Compare alternatives

The scaler converts each input to the resolution the display works best at, and video wall layouts are built through the web GUI. EDID Expert picks appropriate EDID settings so sources negotiate the right mode at power-up, and output runs of up to 15 m are supported with 24 AWG cable.

Control options cover front-panel pushbuttons, IR, a bi-directional RS-232 port for third-party control systems, and Ethernet using Telnet or the web GUI. The metal chassis sits on a desk or in a rack and is rated to 50 degrees C.

Call 01342 580255

Key features

Seamless Switch

ATEN's FPGA design unifies video formats so switching between the four sources is continuous and free of re-sync delay.

Scaler on board

Converts input resolutions to the optimum resolution for each connected display.

Video wall layouts

Custom video wall arrangements can be created and stored from the built-in web GUI.

Multiple control methods

Front-panel pushbuttons, IR, RS-232 and Ethernet (Telnet or web GUI).

Technical specifications

Display

Maximum ResolutionUp to 1080p

Connectivity

Video Inputs4 x HDMI Type A female

Video Outputs4 x HDMI Type A female

Maximum Output DistanceUp to 15 m

Control Ports1 x RS-232 DB-9 female, 1 x IR mini stereo jack, 1 x RJ-45 Ethernet

Power & Physical

Power Consumption34.4 W at 230 VAC

Dimensions43.24 x 26.23 x 4.40 cm

Weight4.05 kg

General

Maximum Data Rate6.75 Gbps (2.25 Gbps per lane)

Maximum Pixel Clock225 MHz

HDCPHDCP 1.4 compatible

EDID ModesDefault / Port 1 / Remix / Customized

HousingMetal

Operating Temperature0-50 degrees C

Call 01342 580255

Documents

ATEN VM5404H 4 x 4 HDMI Matrix Switch with Scaler datasheet (PDF) - series datasheet covering VM5404H and VM5808H

Delivery & returns

Estimated delivery 8 Sept - 12 Sept. UK mainland delivery only. Some large or made-to-order items carry longer lead times, shown on the product page.

Unused items in original packaging can be returned within 14 days of delivery — see the returns policy for how business and consumer returns differ. Faulty items are covered under manufacturer warranty and by your statutory rights.

Full delivery & returns policy

Bought in the UK, backed in the UK

This item is sourced through UK distribution and ships to you from within the UK, so the order never crosses a customs border.
The manufacturer warranty is honoured here in the UK. If something fails, you deal with us, not with an overseas seller in another time zone.
Our own UK-based engineers install, commission and support what we sell, and can attend site when a system needs hands on it.
Delivered within the UK mainland, so there is no import duty, customs charge or courier handling fee waiting for you on delivery.
Prices are in pounds sterling with proper UK VAT invoices, and purchase orders are accepted from approved education accounts: no currency conversion and no surprises at the door.

What to check before buying AV online →

Payment & security

Pay securely by card. Education customers can apply for a 30-day purchase order account.

Schools, colleges, sixth forms, universities and multi-academy trusts can order on invoice, with no card payment required. Purchase orders and credit terms are for education customers only.

All transactions are processed over an encrypted, secure checkout.

Purchase order & invoice terms
