Home / Matrix Switchers & Splitters / StarTech.com 4K7014IC-EXTEND-HDMI 4-Port HDMI Extender and Splitter over CAT6

StarTech.com

StarTech.com 4K7014IC-EXTEND-HDMI 4-Port HDMI Extender and Splitter over CAT6

Name: StarTech.com 4K7014IC-EXTEND-HDMI 4-Port HDMI Extender and Splitter over CAT6
Brand: StarTech.com
SKU: 4K7014IC-EXTEND-HDMI
Price: 545.99 GBP
Availability: OutOfStock

£545.99inc. VAT

£454.99 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £182.00 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

2 Years Warranty Included

Key specifications

Kit Contents1 x HDMI transmitter, 4 x HDMI receivers, 1 x IR blaster, 4 x IR receivers, 5 x mounting kits, universal power adapter

Maximum Distance70 m

CablingCat 6 UTP

Number of Remote Ports4

AudioHDMI 2-channel

Transmitter Connectors1 x HDMI in, 1 x HDMI out, 4 x RJ-45, 1 x 3.5 mm

Receiver Connectors1 x RJ-45, 1 x HDMI, 1 x 3.5 mm each

ChipsetGSV5100

All 15 specifications

Description

This kit is a transmitter and four receivers that between them take one HDMI source out to four remote displays over ordinary CAT6 or CAT6a cabling, at distances up to 70 m. Video is carried losslessly at 4K 60Hz with two-channel audio, so the far displays see the same picture as a directly connected screen.

Full specifications Datasheet Compare alternatives

All four receivers draw their power from the transmitter over the same network cable, so only one mains outlet is needed at the head end. That is often the deciding factor in ceiling and lectern installations where there is no spare socket at the display. IR blaster and receivers are supplied so the source can still be controlled from the far end.

The kit needs no drivers, software or IP configuration and works with any operating system and hardware platform. Mounting brackets are supplied for all five units for wall, ceiling or under-table fixing. Note that the extender must be connected directly and cannot pass through network switching equipment. StarTech.com provides a two-year warranty.

Key features

One source to four remote displays

A single transmitter feeds four receivers over CAT6 or CAT6a at up to 70 m each.

Power over the network cable

All four receivers are powered from the transmitter, so only one mains outlet is required.

IR return path

An IR blaster and four IR receivers are included so the source can be controlled from the display end.

No drivers or IP setup

Works with Windows, macOS and ChromeOS on Intel, AMD and Apple Silicon with no configuration.

Technical specifications

Connectivity

Number of Remote Ports4

Transmitter Connectors1 x HDMI in, 1 x HDMI out, 4 x RJ-45, 1 x 3.5 mm

Receiver Connectors1 x RJ-45, 1 x HDMI, 1 x 3.5 mm each

Audio

AudioHDMI 2-channel

Power & Physical

Product Dimensions18 x 10.3 x 2.3 cm

Weight375 g

ColourBlack

Certifications & Warranty

Warranty2 years

General

Kit Contents1 x HDMI transmitter, 4 x HDMI receivers, 1 x IR blaster, 4 x IR receivers, 5 x mounting kits, universal power adapter

Maximum Distance70 m

CablingCat 6 UTP

ChipsetGSV5100

Power SupplyAC adapter included, 100-240 V AC in, 12 V DC 2 A out, 24 W

Operating Temperature0 to 50 degrees C

NoteMust be connected directly; cannot transmit through network equipment

Documents

StarTech.com 4K7014IC-EXTEND-HDMI 4-Port HDMI Extender and Splitter over CAT6 datasheet (PDF)
