Sony RM-IP500 PTZ Camera Remote Controller

Name: Sony RM-IP500 PTZ Camera Remote Controller
Brand: Sony
SKU: RM-IP500
Price: 3484.32 GBP
Availability: OutOfStock

£3,484.32inc. VAT

£2,903.60 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Call 01342 580255

Return within 14 days

Installation services available Purchase orders: education customers only

Key specifications

TypePTZ camera remote controller

Maximum IP Connections100

Maximum Serial Connections7

Control ProtocolVISCA over IP / VISCA RS-422, switchable

Control Input/OutputVISCA RS-422 RJ-45 x 1, LAN RJ-45 x 1 (10/100BASE-TX), GPI I/O 15-pin D-sub

Control Signal Format9,600 / 38,400 bps (RS-422), VISCA over IP

DisplayYes

Speed Control3 dials (pan/tilt, zoom, focus)

All 16 specifications

Description

The RM-IP500 is Sony's full-function control panel for its remote and PTZ cameras. It addresses up to 100 cameras over VISCA over IP or seven over VISCA RS-422, and puts the exposure, colour and detail controls that normally live in a menu onto physical buttons and knobs.

Full specifications Datasheet Compare alternatives

That is the practical difference from a simple joystick panel. Iris, gain, shutter, master black, detail level, knee point, AE level and R/B gain and black are all directly adjustable with the values shown on the panel display, so a camera can be matched to the others in the middle of a show rather than between them. Three separate dials handle pan/tilt, zoom and focus speed, and zoom can be driven from either the seesaw lever or the joystick ring.

There are six assignable buttons, GPI tally input and contact output on a 15-pin D-sub, and RJ-45 for both LAN and VISCA RS-422. It runs on 12 V DC at up to 7.2 W, measures 306 x 159.3 x 224.1 mm and weighs about 2.4 kg, with a Kensington lock slot. Available functions depend on the camera being controlled.

Call 01342 580255

Key features

Controls up to 100 cameras

Up to 100 connections over VISCA over IP, or seven over VISCA RS-422.

Direct picture controls

Iris, gain, shutter, master black, detail, knee and white/black balance on dedicated controls with on-panel readout.

Three speed dials

Separate pan/tilt, zoom and focus speed dials, with zoom on either the seesaw lever or the joystick ring.

Tally and GPI

GPI tally input and contact output on a 15-pin D-sub for integration with a production system.

Technical specifications

Display

DisplayYes

Connectivity

Maximum IP Connections100

Maximum Serial Connections7

Control Input/OutputVISCA RS-422 RJ-45 x 1, LAN RJ-45 x 1 (10/100BASE-TX), GPI I/O 15-pin D-sub

Input Voltage12 V DC (10.8-13.2 V)

Power & Physical

Dimensions (W x H x D)306 x 159.3 x 224.1 mm

WeightApprox. 2,400 g

General

TypePTZ camera remote controller

Control ProtocolVISCA over IP / VISCA RS-422, switchable

Control Signal Format9,600 / 38,400 bps (RS-422), VISCA over IP

Speed Control3 dials (pan/tilt, zoom, focus)

Zoom ControlSeesaw lever or joystick ring, selectable

Assignable Buttons6

Kensington LockYes

Current Consumption0.6 A max (7.2 W at 12 V DC)

Operating Temperature0 to 40 degrees C

Call 01342 580255

Documents

Sony RM-IP500 product datasheet (PDF) — full specifications, published by Sony at pro.sony.
