Radio Design Labs SF-TPR24A Line-Level Receiver

Name: Radio Design Labs SF-TPR24A Line-Level Receiver
Brand: Radio Design Labs
SKU: SF-TPR24A
Price: 882.00 GBP
Availability: OutOfStock

£882.00inc. VAT

£735.00 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £294.00 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

7 Years Warranty Included

Key specifications

Inputs (8)RDL Format-A

Input ConnectionsRJ45

Format-A Signal Pairs Used (3)A, B, C (per section)

Outputs (24)150 Ω Balanced

Output ConnectionDetachable Terminal Block (Balanced)

Output Level+4 dBu Bal. nominal, +22 dBu Max

Frequency Response10 Hz to 50 kHz (± 0.1 dB)

THD+N< 0.005%

All 18 specifications

Description

The SF-TPR24A is an eight-section audio receiving chassis compatible with RDL Format-A twisted pair products. Each section receives up to three audio sources and provides three outputs corresponding to signal pairs A, B and C. A studio-quality buffer amplifier feeds +4 dBu balanced outputs through a detachable terminal block.

Full specifications Datasheet Compare alternatives

The SF-TPR24A features bridging inputs, allowing it to be connected to the LOOP OUT jack of other receivers. The bridging input circuits used in all FORMAT-A twisted pair receivers allow connection of up to 10 receiver outputs for each cable pair. The possibility of multiple receiver locations adds enormous flexibility in the design of audio routing systems using RDL FORMAT-A products.

The SF-TPR24A may be powered directly from a 24 Vdc power supply using either the power jack or the detachable terminal block. Local power connected to the module is also fed to all modules connected to the eight INPUT RJ45 jacks. Power for each RJ45 connector is protected against wiring faults by an automatically resetting fuse. Front-Panel green LEDs indicate valid module power on each RJ45.

Key features:

• Eight Separate Three-Pair Format-A Receiver Sections

• Receives up to 24 Audio Channels

• Three +4 dBu Balanced Outputs per Section

• Detachable Terminal Block Outputs

• Audio Outputs for All Three Pairs (A, B and C) per Section

• Local Power Feeds all Modules Connected to INPUTs

• Wiring Fault Protection by Automatic Resetting Fuse

• Local Power Input on Terminal Block or dc Power Jack

• Green LED per Section Indicates Validity of Module Remote Power

• Studio-Quality Precision Active Balanced Circuitry

Manufacturer part number SF-TPR24A.

Key features

Inputs (8)

RDL Format-A

Input Connections

RJ45

Format-A Signal Pairs Used (3)

A, B, C (per section)

Outputs (24)

150 Ω Balanced

Output Connection

Detachable Terminal Block (Balanced)

Output Level

+4 dBu Bal. nominal, +22 dBu Max

Frequency Response

10 Hz to 50 kHz (± 0.1 dB)

THD+N

< 0.005%

Technical specifications

Connectivity

Inputs (8)RDL Format-A

Input ConnectionsRJ45

Outputs (24)150 Ω Balanced

Output ConnectionDetachable Terminal Block (Balanced)

Output Level+4 dBu Bal. nominal, +22 dBu Max

Power Connections (2)Power Jack; Detachable Terminal Block

Power & Physical

Dimensions8.74" (22.2 cm) W; 1.68" (4.27 cm) H; 5.78" (14.68 cm) D

Shipping Weight2.66 lbs.

General

Format-A Signal Pairs Used (3)A, B, C (per section)

Frequency Response10 Hz to 50 kHz (± 0.1 dB)

THD+N< 0.005%

Noise below +4 dBu< 90 dB

CrosstalkBelow noise floor (20 Hz to 20 kHz, +4 dBu input)

Headroom above +4 dBu> 18 dB

CMRR> 80 dB (50 Hz to 150 Hz)

Indicators (8)Power (1 per RJ45)

Ambient Operating Environment0° C to 55° C

Power Requirement24 Vdc @ 360 mA plus connected loads (1.6 A max)
