Radio Design Labs RU-MX5ML 5 Channel Mic/Line Audio Mixer with Phantom Power

Name: Radio Design Labs RU-MX5ML 5 Channel Mic/Line Audio Mixer with Phantom Power
Brand: Radio Design Labs
SKU: RU-MX5ML
Price: 489.60 GBP
Availability: OutOfStock

£489.60inc. VAT

£408.00 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £163.20 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

7 Years Warranty Included

Key specifications

Inputs (6)4 selectable mic or line level; 1 line level; 1 direct MIX; detachable terminal block

Input ImpedanceMic: >1.2 kΩ balanced; Line: >10 kΩ balanced

Maximum Input LevelMic: -20 dBu; Line: +24 dBu

PhantomSwitch-selectable 24 V (IEC 61938: 2013)

GainMic: Off to 65 dB; Line: Off to 15 dB

Outputs (2)Mic: -45 dBu balanced; Line: +4 dBu balanced; detachable terminal block

Output Impedance150 Ω balanced

Frequency ResponseMic: 80 Hz to 40 kHz (±1 dB, < -6 dB at 20 Hz with integral high-pass filter); Line: 10 Hz to 35 kHz (± 0.5 dB)

All 17 specifications

Description

The RU-MX5ML is the ideal choice in many applications where a combination of balanced mic and/or balanced or unbalanced line-level signals needs to be mixed with the ability for additional expansion. All connections are made using detachable terminal blocks on the rear panel. Four of the RU-MX5ML inputs can accept either mic or line inputs. The fifth input is for line level sources.

Full specifications Datasheet Compare alternatives

24 V phantom is individually switch selectable for each mic input. The output from one RU-MX5ML may connect to the MIX input of another RU-MX5ML to expand mixing capabilities. The output section provides both a balanced line (+4 dBu) and balanced microphone level (-45 dBu) output. Both outputs may be used at the same time. Audio levels are adjustable on the front panel. The output is equipped with a front-panel dual-LED VU meter that follows standard VU ballistics.

Key features:

• Mic or Line Level Audio Mixer

• Five Channel Audio Mixer with Expansion Capability

• Inputs and Outputs on Detachable Terminal Blocks

• Switchable 24 V Phantom for Each Mic Input

• Balanced Mic and Line Outputs

• Expansion Bussing Capability

• Output Level dual-LED VU Metering

• Studio-Quality, Low-Noise Performance

Manufacturer part number RU-MX5ML.

Key features

Inputs (6)

4 selectable mic or line level; 1 line level; 1 direct MIX; detachable terminal block

Input Impedance

Mic: >1.2 kΩ balanced; Line: >10 kΩ balanced

Maximum Input Level

Mic: -20 dBu; Line: +24 dBu

Phantom

Switch-selectable 24 V (IEC 61938: 2013)

Gain

Mic: Off to 65 dB; Line: Off to 15 dB

Outputs (2)

Mic: -45 dBu balanced; Line: +4 dBu balanced; detachable terminal block

Output Impedance

150 Ω balanced

Frequency Response

Mic: 80 Hz to 40 kHz (±1 dB, < -6 dB at 20 Hz with integral high-pass filter); Line: 10 Hz to 35 kHz (± 0.5 dB)

Technical specifications

Connectivity

Inputs (6)4 selectable mic or line level; 1 line level; 1 direct MIX; detachable terminal block

Input ImpedanceMic: >1.2 kΩ balanced; Line: >10 kΩ balanced

Maximum Input LevelMic: -20 dBu; Line: +24 dBu

Outputs (2)Mic: -45 dBu balanced; Line: +4 dBu balanced; detachable terminal block

Output Impedance150 Ω balanced

Power & Physical

DimensionsHeight: 1.7 in. 4.3 cm; Width: 5.8 in. 15.0 cm; Depth: 4.8 in. 12.2 cm

Shipping Weight1.385 lbs.

General

PhantomSwitch-selectable 24 V (IEC 61938: 2013)

GainMic: Off to 65 dB; Line: Off to 15 dB

Frequency ResponseMic: 80 Hz to 40 kHz (±1 dB, < -6 dB at 20 Hz with integral high-pass filter); Line: 10 Hz to 35 kHz (± 0.5 dB)

THD+NMic: < 0.03%; Line: <0.003%

Headroom20 dB (above +4 dBu output)

Noise< -70 dB below +4 dBu output (20 Hz to 20 kHz, all mic channels at 50 dB gain; or one mic channel active at 60 dB gain); < -90 dB below +4 dBu (20 Hz to 20 kHz, all channels off)

CMRRMic: > -65 dB (10 Hz to 10 kHz); Line: > -45 dB

MeteringDual-LED VU Meter (calibrated to +4 dBu)

Ambient Operating Environment0° C to 55° C

Power RequirementGROUND-REFERENCED, 24 Vdc @ 75 mA (120 mA max. including phantom); detachable terminal block

Documents

Radio Design Labs RU-MX5ML 5 Channel Mic/Line Audio Mixer with Phantom Power — RDL Datasheet
