Home / Mixers / Radio Design Labs RU-MX4L Professional 4 Channel Line Level Mixer - Microphone and line Output

Radio Design Labs

Radio Design Labs RU-MX4L Professional 4 Channel Line Level Mixer - Microphone and line Output

Name: Radio Design Labs RU-MX4L Professional 4 Channel Line Level Mixer - Microphone and line Output
Brand: Radio Design Labs
SKU: RU-MX4L
Price: 502.80 GBP
Availability: OutOfStock

£502.80inc. VAT

£419.00 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £167.60 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

7 Years Warranty Included

Key specifications

Balanced Line Inputs(4)20 kΩ balanced bridging

Balanced Line Input Level-13 to +22 dBu for +4 dBu output

Unbalanced Line Inputs (4)2 kΩ unbalanced

Unbalanced Line Input Level-25 dBV to +20 dBV for +4 dBu output; -10 dBV nominal

Gain Adjustments (4)Balanced Line: Off to 17 dB gain Unbalanced Line: Off to 27 dB gain

Output Attenuator0 dB to infinity

Frequency Response20 Hz to 30 kHz (± 0.25 dB)

THD+N< 0.01%

All 14 specifications

Description

The RU-MX4L is the ideal choice in many applications where a combination of balanced and/or unbalanced line-level signals needs to be mixed. Balanced connections use XLR connectors. Unbalanced signals are coupled through phono jacks. Each of the four RU-MX4L inputs can accept either a balanced XLR line-level input or an unbalanced line-level phono jack input. The unbalanced phono jack LINE OUTPUT from one RU-MX4L may connect to the unbalanced input of other equipment, or may be connected to the DIRECT input of another RU-MX4L or an RU-MX4 to expand mixing capabilities. The RU-MX4L provides one balanced output, switchable for mic or line level. Audio levels are adjustable on the front panel. Each input channel is equipped with a front-panel dual-LED VU meter that follows standard VU ballistics. The final mix is displayed on an LED string VU meter featuring a visually comfortable arc motion. A factory installed output isolation transformer is available by ordering the RU-MX4LT.

Full specifications Datasheet Compare alternatives

Key features:

• Four Channel Line-Level Audio Mixer

• XLR Balanced, Phono Jack Unbalanced Inputs

• Mic or Line XLR Output, Switchable

• Unbalanced Line Output and Direct Input

• Studio Quality, Low-Noise Performance

• Expansion Bussing Capability

• Additional Line Inputs Bussed to an RU-MX4

• Output Isolation Transformer (RU-MX4LT)

Manufacturer part number RU-MX4L.

Key features

Balanced Line Inputs(4)

20 kΩ balanced bridging

Balanced Line Input Level

-13 to +22 dBu for +4 dBu output

Unbalanced Line Inputs (4)

2 kΩ unbalanced

Unbalanced Line Input Level

-25 dBV to +20 dBV for +4 dBu output; -10 dBV nominal

Gain Adjustments (4)

Balanced Line: Off to 17 dB gain Unbalanced Line: Off to 27 dB gain

Output Attenuator

0 dB to infinity

Frequency Response

20 Hz to 30 kHz (± 0.25 dB)

THD+N

< 0.01%

Technical specifications

Connectivity

Balanced Line Inputs(4)20 kΩ balanced bridging

Balanced Line Input Level-13 to +22 dBu for +4 dBu output

Unbalanced Line Inputs (4)2 kΩ unbalanced

Unbalanced Line Input Level-25 dBV to +20 dBV for +4 dBu output; -10 dBV nominal

Output Attenuator0 dB to infinity

Residual Noise (below +4dBu output)4 line level sources (unity gain): < -82 dB (wideband)

Outputs (2)+4 dBu 150 ohm balanced (switchable to MIC level -45 dBu); -10 dBV unbalanced

Power & Physical

Shipping Weight1.625 lbs.

General

Gain Adjustments (4)Balanced Line: Off to 17 dB gain Unbalanced Line: Off to 27 dB gain

Frequency Response20 Hz to 30 kHz (± 0.25 dB)

THD+N< 0.01%

Indicators (17)Dual-LED VU meter for each input; POWER LED; LED audio mix level meter, 0 dB = +4 dBu VU ballistic: -20 dB, -10 dB, -6 dB, -2 dB, 0 dB, +3 dB; Peak reading: +8 dB,+12 dB

Ambient Operating Environment0° C to 50° C

Power RequirementGROUND-REFERENCED, 24 Vdc @ 150 mA,

Documents

Radio Design Labs RU-MX4L Professional 4 Channel Line Level Mixer - Microphone and line Output — RDL Datasheet
