Home / Visualisers / Lumens DC172B 4K HDMI Document Camera (Visualiser, Black)
Lumens

Lumens DC172B 4K HDMI Document Camera (Visualiser, Black)

£589.20inc. VAT
£491.00 ex. VAT
In stock, dispatched within 2 working days
1
  • Visa
  • Mastercard
  • American Express
  • PayPal

Or 3 interest-free payments of £196.40 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →
  • In UK stock, ships from the UK
  • UK manufacturer warranty
  • UK-based engineers
  • No import duty or customs charges
  • GBP pricing, UK VAT invoices
Return within 14 days
Installation services availablePurchase orders: education customers only
Key specifications
Image sensor1/3" 13MP CMOS colour image sensor
Output resolutionXGA / 720p / 1080p / 4K (2160p)
Frame rateXGA / 720p / 1080p: 60/50 fps; 2160p: 30/25 fps
Close-up5 cm
Zoom2x for 1080p; 3x for 720p; 2.8x for XGA
Digital zoom30x
Mechanical zoom6.8x
Shooting area (max.)420 x 316 mm (16.5" x 12.4")
All 25 specifications

Description

The Lumens DC172 Ladibug is a 4K UHD document camera that outputs 2160p at 30 frames per second over HDMI and USB, with a 1/3" 13MP CMOS sensor. Lumens states it demonstrates remarkably detailed images of any object in real time without delays.

Full specifications Datasheet Compare alternatives

The joint-free gooseneck arm gives a 360-degree viewing angle. Images can be rotated 90 / 180 / 270 degrees and flipped or mirrored, and the shooting area is 420 x 316 mm.

HDMI pass-through is active up to 2160p 60 Hz, so a PC image can be passed straight to the display. With Lumens' PC-free solution, annotation and menu settings can be driven directly with a USB mouse, and one button captures, records and plays back the lecture material. External storage is a USB flash drive up to 256 GB.

Lumens publishes the DC172 in two colours: red and black. The black unit is order code DC172B and the red unit is order code DC172.

Key features

4K UHD at 30 fps

Outputs XGA / 720p / 1080p / 4K (2160p); 60/50 fps up to 1080p and 30/25 fps at 2160p.

Active HDMI pass-through

HDMI pass-through active up to 2160p 60 Hz, so a connected PC can drive the same display.

PC-free annotation

Onboard annotation and menu control with a USB mouse; no PC or software needed.

Joint-free gooseneck

The joint-free gooseneck arm allows a 360-degree viewing angle.

Technical specifications

Display
Output resolutionXGA / 720p / 1080p / 4K (2160p)
Connectivity
InputHDMI x1
OutputHDMI x1 / USB 2.0
HDMI pass-throughActive pass-through, up to 2160p 60 Hz
Audio
Built-in microphoneYes
Power & Physical
VESA mountYes, 75 x 75 mm
Power consumption8 W (maximum)
Dimensions (LxWxH)Folded 236 x 106 x 280 mm; Open 350 x 106 x 380 mm
General
Image sensor1/3" 13MP CMOS colour image sensor
Frame rateXGA / 720p / 1080p: 60/50 fps; 2160p: 30/25 fps
Close-up5 cm
Zoom2x for 1080p; 3x for 720p; 2.8x for XGA
Digital zoom30x
Mechanical zoom6.8x
Shooting area (max.)420 x 316 mm (16.5" x 12.4")
LampLED lamp
ArmJoint-free gooseneck
ControlUSB
Memory slotUSB flash drive (up to 256GB)
Built-in memory100 pictures
Onboard annotationYes
Image rotation0° / 90° / 180° / 270° / flip / mirror
Focus modeAuto / Manual
Image modePhoto / Text / Film / Slide / Microscope
DriverUVC / UAC

Documents

Lumens DC172 datasheet (PDF) — covers the red and black variants
