Home / Switches / Kramer SWT3-41-H 4x1 4K60 HDMI Switcher
Kramer

Kramer SWT3-41-H 4x1 4K60 HDMI Switcher

£464.40inc. VAT
£387.00 ex. VAT
Out of stock
1
  • Visa
  • Mastercard
  • American Express
  • PayPal

Or 3 interest-free payments of £154.80 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →
  • Sourced through UK distribution
  • UK manufacturer warranty
  • UK-based engineers
  • No import duty or customs charges
  • GBP pricing, UK VAT invoices
Return within 14 days
Installation services availablePurchase orders: education customers only
3 Years Warranty Included
Key specifications
Inputs - 4 HDMIOn a female HDMI connector
Outputs - 1 HDMIOn a female HDMI connector
Outputs - 1 Balanced Stereo AudioOn 5-pin terminal block connector
Ports - 1 RS-232On a 3-pin terminal block connector
Ports - 6 GPIOOn an 8-pin terminal block connector
Ports - 1 PoE-accepting EthernetOn an RJ-45 connector
Video - Max Data Rate18Gbps bandwidth (6Gbps per graphic channel)
Video - Max Resolution4K@60Hz (4:4:4) resolution
All 20 specifications

Description

SWT3-41-H is an intelligent 4x1 automatic switcher for 4K60 4:4:4 HDMI video signals, with plug and play user experience such as priority or last-connected auto-switching based on active video signal detection, and easy remote IP-driven management and control. Manufacturer part number SWT3-41-H.

Also in this range:SWT3-21-H Full specifications Datasheet Compare alternatives

Key features

Auto Switcher Ease of Use - Automatically plays the switched source

Auto Switcher Ease of Use - Automatically plays the switched source signal on the connected display according to user-configured preferences, such as priority or last-connected input. When the user manually switches, by pressing a button, the auto switching is overridden.

HDMI Signal Switching - HDCP 2.2 compliant, supporting deep color

HDMI Signal Switching - HDCP 2.2 compliant, supporting deep color, x.v.Color™, CEC, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS-HD, 2K, 4K, and 3D as specified in HDMI 2.0.

I-EDIDPro™ Kramer Intelligent EDID Processing™ - Intelligent EDID

I-EDIDPro™ Kramer Intelligent EDID Processing™ - Intelligent EDID handling, processing, locking and pass-through algorithm ensures plug & play operation for HDMI source and display systems

Multi-channel Audio Switching - Up to 32 channels of digital stereo

Multi-channel Audio Switching - Up to 32 channels of digital stereo uncompressed signals for supporting studio-grade surround sound.

Audio De-embedding - The digital audio signal passing-through to the

Audio De-embedding - The digital audio signal passing-through to the HDMI output, is de-embedded, converted to an analog signal and sent to the stereo balanced analog audio output. This enables playing the audio on a locally connected professional audio system (such as DSP) and speakers, in parallel to playing it on the speakers connected to the AV acceptor device (such as TVs with speakers).

Display On/Off Operation - Meeting presentation is simplified by

Display On/Off Operation - Meeting presentation is simplified by manually or automatically turning ON/OFF a CEC-enabled or serially-controlled display when the presentation source is plugged in / unplugged with user-defined shut-down delay.

Simple and Flexible Control - Remote IP-controller connection

Simple and Flexible Control - Remote IP-controller connection, browser operation webpage, local panel buttons, and remotely connected contact-closure buttons triggering configurable operation functions, for easy and fully flexible user ports selection, signals routing, and switcher control.

Built-in Intelligent Control Gateway - Remote IP-driven intelligent

Built-in Intelligent Control Gateway - Remote IP-driven intelligent control of connected HDMI and sensor devices via RS-232 or I/O. Eliminating the need for an external control gateway, this feature reduces installation complexity and costs, to enable easy integration with control systems, such as Kramer Control.

Secured Operation - Standard IT-grade 802.1x authentication for

Secured Operation - Standard IT-grade 802.1x authentication for secured IT LAN connectivity operation.

Comprehensive and Cost-effective Management - Local control via

Comprehensive and Cost-effective Management - Local control via volume and mute panel buttons, and volume and mute contact closure switches. Distance control via user-friendly embedded web pages via the Ethernet, Protocol 3000 API commands via RS-232 serial communication transmitted by a PC, touch screen system or other serial controller.

Technical specifications

Display
Video - Max Resolution4K@60Hz (4:4:4) resolution
Connectivity
Inputs - 4 HDMIOn a female HDMI connector
Outputs - 1 HDMIOn a female HDMI connector
Outputs - 1 Balanced Stereo AudioOn 5-pin terminal block connector
Ports - 1 RS-232On a 3-pin terminal block connector
Ports - 6 GPIOOn an 8-pin terminal block connector
Ports - 1 PoE-accepting EthernetOn an RJ-45 connector
Video - HDMI SupportDeep Color, 3D, HDR as specified in HDMI 2.0b
Power & Physical
Enclosure - SizeDemiTOOLS®
General
Video - Max Data Rate18Gbps bandwidth (6Gbps per graphic channel)
Video - Content ProtectionHDCP 2.2
Power - Power Adapter: Source5V DC, 4A
Power - Consumption0.82A
Power - PoE Consumption120mA
Power - Max. Power5.76W
Enclosure - TypeAluminum
Enclosure - CoolingConvection ventilation
Environmental Conditions - Operating Temperature0° to +40°C (32° to 104°F)
Environmental Conditions - Storage Temperature-40° to +70°C (-40° to 158°F)
Environmental Conditions - Humidity10% to 90%, RHL non-condensing

Documents

Kramer SWT3-41-H 4x1 4K60 HDMI Switcher — manufacturer spec sheet
Kramer SWT3-41-H 4x1 4K60 HDMI Switcher — manufacturer manual
