Home / Extenders / Kramer KDS-DEC7 High-performance, highly-scalable, AVoIP Decoder for 4K over 1G network (KDS-7)

Kramer

Kramer KDS-DEC7 High-performance, highly-scalable, AVoIP Decoder for 4K over 1G network (KDS-7)

Name: Kramer KDS-DEC7 High-performance, highly-scalable, AVoIP Decoder for 4K over 1G network (KDS-7)
Brand: Kramer
SKU: KDS-DEC7
Price: 760.80 GBP
Availability: LimitedAvailability

£760.80inc. VAT

£634.00 ex. VAT

Low stock (1 left), order soon

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £253.60 with PayPal Pay in 3.

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

In UK stock, ships from the UK
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

3 Years Warranty Included

Key specifications

Inputs - 1 HDMIOn a female HDMI connector

Outputs - 1 HDMIOn a female HDMI connector

Ports - 2 EthernetsOn R-J45 connectors

Ports - 1 Balanced AudioOn a 5-pin terminal block connector

Ports - 1 RS-232On a 3-pin terminal block connector

Ports - 1 IROn a 3.5mm TRS connector

Ports - 2 USBOn USB-A connectors

USB Features - Integrated USB Hubs1-layer when connecting to KDS-EN7

All 25 specifications

Description

KDS-DEC7 decoder is an advanced receiver for streaming 4K video signals via Ethernet over copper cable. It decodes streams over an IP network to HDMI output, and transmit the USB, IR, RS-232, or CEC signal over IP network. Manufacturer part number KDS-DEC7.

Full specifications Datasheet Compare alternatives

Key features

Outstanding end-user experience

Rich set of inputs and interfaces

Easy-to-use KM/KVM - Searchable OSD Menu for KM and fully

Easy-to-use KM/KVM - Searchable OSD Menu for KM and fully configurable KVM roaming

Large scale video wall - up to 16x16

Instantaneous switching time - 1 second

Ideal for large-scale deployments

Highly scalable - 999 channels build in support

State of the art management device

Rich set of management capabilities - Standard P3K Open API , LCD

Rich set of management capabilities - Standard P3K Open API , LCD screen for configuration

Robust security

Enterprise IT-grade security - 802.1x and HTTPS/TLS

Security certification - OWASP Top 10 certificate

Separate ETH ports for optimal security and experience

Technical specifications

Choose a section to view its specifications.

Display (5)

Video - Max Resolution: 4K@30Hz 4:4:4
Video Streaming - Max Input Resolution: 4K@30Hz 4:4:4
Video Streaming - Max Output Resolution: 4K@30hz (4:4:4)
Video Streaming - Max End-to-End Resolution: 4K@30hz (4:4:4)
Resolution: 4096x2160@30Hz, 1600x1200@60Hz, 1280x960@60Hz, 848x480@60Hz,

Connectivity (12)

Inputs - 1 HDMI: On a female HDMI connector
Outputs - 1 HDMI: On a female HDMI connector
Ports - 2 Ethernets: On R-J45 connectors
Ports - 1 Balanced Audio: On a 5-pin terminal block connector
Ports - 1 RS-232: On a 3-pin terminal block connector
Ports - 1 IR: On a 3.5mm TRS connector
Ports - 2 USB: On USB-A connectors
USB Features - Integrated USB Hubs: 1-layer when connecting to KDS-EN7
Network - Multicast: UDP, IGMP snooping non-blocking, Layer 2
Network - Unicast: UDP
Network - Bitrate: Peak: 850Mbps, 4K average: 350Mbps, 1080p average: 250Mbps
Audio - Supported Formats: LPCM, Dolby and DTS

Audio (3)

Audio - LPCM: LPCM upto 7.1/24-bit/192kHz
Audio - Dolby: Dolby AtmosTM, Dolby TrueHD, Dolby Digital PlusTM, Dolby Digital EX, Dolby Digital 5.1, Dolby Digital 2/0 Surround, Dolby Digital 2/0
Audio - DTS: DTS-HD Master AudioTM, DTS-HD, DTS-ES Discrete 6.1, DTS-ES Matrix 6.1, DTS Digital Surround 5.1

General (5)

Video - Compression: Visually Lossless, proprietary codec
Video Streaming - Compression Standard: JPEG2K based, proprietary stream
Video Streaming - Scaler: Yes
Video Streaming - End-to-End Latency: 33msec
Video Streaming - Switching Time: 1sec

Documents

Kramer KDS-DEC7 High-performance, highly-scalable, AVoIP Decoder for 4K over 1G network (KDS-7) — manufacturer spec sheet

Kramer KDS-DEC7 High-performance, highly-scalable, AVoIP Decoder for 4K over 1G network (KDS-7) — manufacturer manual
