Kramer KDS-100EN Open-Standard 4K AVoIP Encoder with Ultra-Low Latency & Dual Streaming

Name: Kramer KDS-100EN Open-Standard 4K AVoIP Encoder with Ultra-Low Latency & Dual Streaming
Brand: Kramer
SKU: KDS-100EN
Price: 1212.00 GBP
Availability: OutOfStock

£1,212.00inc. VAT

£1,010.00 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £404.00 with PayPal Pay in 3.

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Call 020 3815 8642

Return within 14 days

Installation services available Purchase orders: education customers only

3 Years Warranty Included

Key specifications

Inputs - 1 HDMIOn a female HDMI connector

Inputs - 1 Balanced AudioOn a 5-pin terminal block connector

Outputs - 1 HDMIOn a female HDMI connector

Outputs - 1 Balanced AudioOn a 5-pin terminal block connector

Ports - 1 Media / Control LAN PoEOn an RJ-45 female connector

Ports - 1 Fiber on an LC ConnectorStandard: 1000BASE-SX, 1000BASE-LX

Ports - 1 RS-232On a 3-pin terminal block connector for control

Ports - 1 USB-B HostConnecting PC/Laptop

All 25 specifications

Description

The KDS-100EN is a professional-grade AVoIP encoder for high-quality 4K video distribution over standard 1GbE networks. Using open-standard H.264/H.265 compression, it delivers excellent visual fidelity while ensuring seamless interoperability across mixed-vendor environments. Manufacturer part number KDS-100EN.

Full specifications Datasheet Compare alternatives

Call 020 3815 8642

Key features

Dual Streaming

ideal for monitoring, recording, overflow rooms, and collaboration workflows.

KVM over IP

Built-in KVM over IP - enables secure keyboard/mouse control of remote hosts from any decoder location. With ~40 ms latency, operators get real-time responsiveness.

Predefined deployment profiles

make system setup easy and adaptable to both high-capacity and constrained networks

Channel-based routing

model - lets users switch sources by channel name/number-no IP addressing expertise required.

Auxiliary Data transmission

RS-232 control commands are delivered to/from peripheral devices, providing seamless AV and control integration.

Kramer AVoIP Manager integration

enables automatic device discovery, centralized configuration, and real-time monitoring across the entire AVoIP deployment.

IT-grade Security

HTTPS/TLS, 802.1x, and OWASP-10 aligned practices.

Technical specifications

Choose a section to view its specifications.

Display (5)

Video - Max Input/Output Resolution: 3840x2160@60Hz 4:4:4
Video Streaming - Max Streaming Resolution: 3840x2160@60Hz 4:2:2
Video Streaming - Secondary Streaming Resolution: 1920x1080@60Hz 4:2:2
Resolution: 3840x2160@60Hz
User Interface - Rear Panel: Recessed factory reset button

Connectivity (11)

Inputs - 1 HDMI: On a female HDMI connector
Inputs - 1 Balanced Audio: On a 5-pin terminal block connector
Outputs - 1 HDMI: On a female HDMI connector
Outputs - 1 Balanced Audio: On a 5-pin terminal block connector
Ports - 1 Media / Control LAN PoE: On an RJ-45 female connector
Ports - 1 Fiber on an LC Connector: Standard: 1000BASE-SX, 1000BASE-LX
Ports - 1 RS-232: On a 3-pin terminal block connector for control
Ports - 1 USB-B Host: Connecting PC/Laptop
Network - Multicast: IGMPv2
Network: RTP/RTSP/SRT/RTMP/MPEG-TS
Video Streaming - Dual Streaming support: Primary: Up to 3840x2160@30Hz 4:2:2

General (9)

Video Streaming - Open Standard: H.264 and H.265
Video Streaming - Latency: Low latency: About 40msec
Video Streaming - Bit Rate Range: 1-60Mbps
Security: HTTPS, 802.1x, OWASP-10
User Interface - Indicators: LINK, NET and ON LEDs, front panel channel number display
User Interface - Controls: Embedded web pages, P3K API commands via Ethernet, front panel channel selection buttons
Power - PoE+: IEEE 802.3at
Power - Source (Optional): 12V DC/5A. Unit has to be supplied by a power supply specified as a Limited Power Source (LPS) or PS2 source of supply
Power - Consumption: 13.6W

Call 020 3815 8642

Documents

Kramer KDS-100EN Open-Standard 4K AVoIP Encoder with Ultra-Low Latency & Dual Streaming — manufacturer spec sheet

Kramer KDS-100EN Open-Standard 4K AVoIP Encoder with Ultra-Low Latency & Dual Streaming — manufacturer manual
