Home / Extenders / ATEN CE824 USB HDMI Dual View HDBaseT™ 2.0 KVM Extender (4K@100m for Single View)

ATEN

ATEN CE824 USB HDMI Dual View HDBaseT™ 2.0 KVM Extender (4K@100m for Single View)

Name: ATEN CE824 USB HDMI Dual View HDBaseT™ 2.0 KVM Extender (4K@100m for Single View)
Brand: ATEN
SKU: CE824
Price: 1261.27 GBP
Availability: OutOfStock

£1,261.27inc. VAT

£1,051.06 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £420.43 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Call 01342 580255

Return within 14 days

Installation services available Purchase orders: education customers only

2 Years Warranty Included

Key specifications

KVM PortsLocal unit: 2 xHDMI Female (Black); 1 x USB Type B Female (White); 1 x Mini Stereo Jack Female (Green); 1 x Mini Stereo Jack Female (Pink) | Remote unit: N/A

Console PortsLocal unit: N/A | Remote unit: 2 x HDMI Female (Black); 4 x USB Type A Female (White); 1 x Mini Stereo Jack Female (Green); 1 x Mini Stereo Jack Female (Pink)

RS-232Local unit: 1 x DB-9 Female (Black) | Remote unit: 1 x DB-9 Male (Black)

Unit To Unit1 x RJ-45 Female (Black)

Power (LEDs)1 (Green)

Link (LEDs)1 (Orange)

Long Reach Mode Switch (Switches)1 x Slide Switch

Firmware Upgrade (Switches)1 x Slide Switch

All 15 specifications

Description

The ATEN CE824 is a USB HDMI Dual View HDBaseT™ 2.0 KVM Extender (4K@100m for Single View). It carries the console — keyboard, video, mouse and audio — away from the machine it is driving, so the computer can live in a rack or plant room while the operator works from a desk, a control position or a shop floor.

Also in this range:CE370 CE604 CE680 CE690 Full specifications Datasheet Compare alternatives

Video is specified at Single view: Up to 4K@100m (Cat 6/6a/ATEN 2L-29330 Cat 6A). The kit ships as a matched local and remote pair, with the connector list for each unit in the specification table below.

Housed in metal, it draws Local unit: DC12V:5.98W:28BTU/h | Remote unit: DC12V:10.32W:57BTU/h and operates from 0–40°C. The ATEN datasheet attached to this listing gives the full connector, LED and compatibility detail.

Available to order from TopAV with ATEN's standard 24-month product warranty.

Call 01342 580255

Key features

Console ports

Local unit: N/A | Remote unit: 2 x HDMI Female (Black); 4 x USB Type A Female (White); 1 x Mini Stereo Jack Female (Green); 1 x Mini Stereo Jack Female (Pink)

KVM ports

Local unit: 2 xHDMI Female (Black); 1 x USB Type B Female (White); 1 x Mini Stereo Jack Female (Green); 1 x Mini Stereo Jack Female (Pink) | Remote unit: N/A

Housing

Metal

Technical specifications

Connectivity

KVM PortsLocal unit: 2 xHDMI Female (Black); 1 x USB Type B Female (White); 1 x Mini Stereo Jack Female (Green); 1 x Mini Stereo Jack Female (Pink) | Remote unit: N/A

Console PortsLocal unit: N/A | Remote unit: 2 x HDMI Female (Black); 4 x USB Type A Female (White); 1 x Mini Stereo Jack Female (Green); 1 x Mini Stereo Jack Female (Pink)

Power & Physical

Power ConsumptionLocal unit: DC12V:5.98W:28BTU/h | Remote unit: DC12V:10.32W:57BTU/h

WeightLocal unit: 0.79 kg ( 1.74 lb ) | Remote unit: 0.82 kg ( 1.81 lb )

Dimensions (L x W x H)17.42 x 15.59 x 2.88 cm; (6.86 x 6.14 x 1.13 in.)

General

RS-232Local unit: 1 x DB-9 Female (Black) | Remote unit: 1 x DB-9 Male (Black)

Unit To Unit1 x RJ-45 Female (Black)

Power (LEDs)1 (Green)

Link (LEDs)1 (Orange)

Long Reach Mode Switch (Switches)1 x Slide Switch

Firmware Upgrade (Switches)1 x Slide Switch

VideoLocal unit: Single view: Up to 4K@100m (Cat 6/6a/ATEN 2L-29330 Cat 6A); 1080P@150m (Cat 6/6a/ATEN 2L-29330 Cat 6A) with Long Reach Mode enabled; Dual-view: Up to 1080p@100m (Cat 6/6a/ATEN 2L-29330 Cat 6A); *4K supported:; 4096 x 2160 @ 60Hz (4:2:0), 40 | Remote unit: Single view: Up to 4K@100m (Cat 6/6a/ATEN 2L-29330 Cat 6A); 1080P@150m (Cat 6/6a/ATEN 2L-29330 Cat 6A with Long Reach Mode enabled; Dual-view: Up to 1080p@100m (Cat 6/6a/ATEN 2L-29330 Cat 6A); *4K supported:; 4096 x 2160 @ 60Hz (4:2:0), 409

HousingMetal

Operating Temperature0–40°C

Storage Temperature-20–60°C

Call 01342 580255

Documents

ATEN CE824 datasheet (PDF, published by ATEN)
