Home / BYOD Rooms / Kramer K-Bar 12MP camera, 120˚ FOV, 5x digital zoom, 6 array MEMS microphone, 8w speaker
Kramer

Kramer K-Bar 12MP camera, 120˚ FOV, 5x digital zoom, 6 array MEMS microphone, 8w speaker

£678.00inc. VAT
£565.00 ex. VAT
Out of stock
1
  • Visa
  • Mastercard
  • American Express
  • PayPal

Or 3 interest-free payments of £226.00 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →
  • Sourced through UK distribution
  • UK manufacturer warranty
  • UK-based engineers
  • No import duty or customs charges
  • GBP pricing, UK VAT invoices
Return within 14 days
Installation services availablePurchase orders: education customers only
3 Years Warranty Included
Key specifications
Ports - 1 USB-C 2.0On a USB-C connector
Ports - AUX OUTOn a 3.5mm mini jack
Camera - Pixel12M
Camera - Max. Field of View (FOV)120° (D)
Camera - Adjustable Angle (Manual)±15° (Up/Down)
Camera - Focus ModeFixed focus
Camera - Focus Distance2m
Camera - Resolution and Frame RateH.264/MJPG: 3840x2160; 2560x1440; 1920x1080; 1280x720; 1024x576; 960x540; 800x600; 640x480; 640x360; 480x270; 352x288; 320x240
All 24 specifications

Description

Compact, all-in-one video and audio communication bar Quickly start collaborating, with simplified, professional audio and video. With the optimum blend of microphones, speakers and video camera, all in a small and sleek device, the K-Bar delivers everything needed for hybrid interaction in small meeting spaces. Manufacturer part number K-BAR.

Full specifications Datasheet Compare alternatives

Key features

A perfect fit for small rooms

Compact collaboration bar and flexible mounting options allow optimized use of limited space - Ideal for huddle rooms and small rooms with space for up to six people

All-in-one format and multiple connection options enable fast

All-in-one format and multiple connection options enable fast, space-saving installations, with just a single cable

Optimized video and audio

12 MP camera with 120° viewing angle and 5x digital zoom covers most areas of a small room

Auto-framing dynamically adjusts the field of view to optimally

Auto-framing dynamically adjusts the field of view to optimally capture all participants

Ability to pre-set two camera positions saves time in meetings and

Ability to pre-set two camera positions saves time in meetings and helps ensure the best view of participants

Integrated 6-element microphone and 8-way speakerphone, with

Integrated 6-element microphone and 8-way speakerphone, with automatic noise reduction and gain control, ensure all participants can hear and be heard clearly

All functions are easily controlled via the handy remote control

All functions are easily controlled via the handy remote control, including zoom in/out, camera position selection, audio volume

Optional

K-BAR-5YW comes with a 5-year warranty at a price of $1,157.

Technical specifications

Display
Camera - Resolution and Frame RateH.264/MJPG: 3840x2160; 2560x1440; 1920x1080; 1280x720; 1024x576; 960x540; 800x600; 640x480; 640x360; 480x270; 352x288; 320x240
Connectivity
Ports - 1 USB-C 2.0On a USB-C connector
Ports - AUX OUTOn a 3.5mm mini jack
Camera - Output FormatMJPG/YUY2/H.264
Sound Reinforcement - Output Power 1x8WOutput Power 1x8W
Audio
Sound Reinforcement - Sound Channel 1.0Sound Channel 1.0
Microphone - Quantity6
Microphone - Voice Pickup DistanceUp to 8 meters
Certifications & Warranty
Regulatory Compliance (Standards Compliance) - SafetyCE, FCC
Regulatory Compliance (Standards Compliance) - EnvironmentalRoHs, WEEE
General
Camera - Pixel12M
Camera - Max. Field of View (FOV)120° (D)
Camera - Adjustable Angle (Manual)±15° (Up/Down)
Camera - Focus ModeFixed focus
Camera - Focus Distance2m
ControlsRemote control
Power - Consumption12V DC, 1A max.
Power - Source12V DC, 2A
Power - Standby Power≤0.5W
Environmental Conditions - Operating Temperature0° to +40°C (32° to 104°F)
Environmental Conditions - Storage Temperature-20° to +60°C (-4° to 140°F)
Environmental Conditions - Humidity10% to 90%, RHL non-condensing
Environmental Conditions - AltitudeBelow 5000 meters
Enclosure - TypeAluminum

Documents

Kramer K-Bar 12MP camera, 120˚ FOV, 5x digital zoom, 6 array MEMS microphone, 8w speaker — manufacturer spec sheet
Kramer K-Bar 12MP camera, 120˚ FOV, 5x digital zoom, 6 array MEMS microphone, 8w speaker — manufacturer manual
