Home / Hubs & Converters / Kramer FC-46H2 4K HDR HDMI Audio De-embedder
Kramer

Kramer FC-46H2 4K HDR HDMI Audio De-embedder

£434.40inc. VAT
£362.00 ex. VAT
Out of stock
1
  • Visa
  • Mastercard
  • American Express
  • PayPal

Or 3 interest-free payments of £144.80 with PayPal Pay in 3.

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →
  • Sourced through UK distribution
  • UK manufacturer warranty
  • UK-based engineers
  • No import duty or customs charges
  • GBP pricing, UK VAT invoices
Return within 14 days
Installation services availablePurchase orders: education customers only
3 Years Warranty Included
Key specifications
Inputs - HDMIOn a female HDMI connector
Outputs - HDMIOn a female HDMI connector
Outputs - S/PDIF Digital AudioOn an RCA connector
Outputs - Balanced Stereo Analog AudioOn a 5-pin terminal block connector
Video - BandwidthUp to 18Gbps (6Gbps per graphic channel)
Video - Color DepthUp to 12-bit
Video - Max. ResolutionUp to 4K@60 (4:4:4)
Video - HDMI Support4K@60Hz and ARC as specified in HDMI 2.0.
All 24 specifications

Description

The FC-46H2 is a professional HDMI audio de-embedder for HDMI signals up to 4K@60Hz (4:4:4) resolution. The unit de-embeds the audio signal from the HDMI input or from the HDMI output ARC (Audio Return Channel) and simultaneously outputs it to the S/PDIF® and 5-pin balanced audio outputs. Manufacturer part number FC-46H2.

Full specifications Datasheet Compare alternatives

Key features

Professional HDMI Audio De-embedder - De-embeds the audio from HDMI

Professional HDMI Audio De-embedder - De-embeds the audio from HDMI signals with resolution up to 4K@60Hz (4:4:4) and data rate up to 18Gbps (6Gbps per graphic channel), deep color up to 12-bit, supporting HDR and HDCP 2.2/1.4.

Flexible De-embedding - De-embed the audio from the HDMI input or

Flexible De-embedding - De-embed the audio from the HDMI input or from the HDMI output ARC (Audio Return Channel).

Varied Output Options - De-embedded audio is simultaneously output to

Varied Output Options - De-embedded audio is simultaneously output to an S/PDIF® and 5-pin balanced audio outputs.

Smart EDID Management - Select one of the EDID management modes using

Smart EDID Management - Select one of the EDID management modes using the DIP-switches: pass-through, lock or force 2 channel LPCM.

Kramer re-Klocking™ and Equalization Technology - Rebuilds the

Kramer re-Klocking™ and Equalization Technology - Rebuilds the digital signal to travel longer distances.

Convenient Control and Maintenance - Audio Source front panel button

Convenient Control and Maintenance - Audio Source front panel button enables local switching to either the HDMI input audio or the HDMI output ARC. Audio source, audio output, and power LED indicators enable easy local maintenance and troubleshooting. Local firmware upgrade via the mini USB port ensures lasting, field-proven deployment.

Easy Installation - Compact DigTOOLS® fan-less enclosure for surface

Easy Installation - Compact DigTOOLS® fan-less enclosure for surface mounting or side-by-side mounting of 3 units in a 1U rack space with the recommended rack adapter.

Technical specifications

Choose a section to view its specifications.

Display (1)
Video - Max. Resolution
Up to 4K@60 (4:4:4)
Connectivity (5)
Inputs - HDMI
On a female HDMI connector
Outputs - HDMI
On a female HDMI connector
Outputs - S/PDIF Digital Audio
On an RCA connector
Outputs - Balanced Stereo Analog Audio
On a 5-pin terminal block connector
Video - HDMI Support
4K@60Hz and ARC as specified in HDMI 2.0.
Audio (3)
Audio - Frequency Response
20Hz to 20kHz @ +/-0.1dB
Audio - S/N Ratio
>90dB
Audio - THD+N
0.004%
Power & Physical (3)
Video - Bandwidth
Up to 18Gbps (6Gbps per graphic channel)
Video - Color Depth
Up to 12-bit
Enclosure - Size
Tool
General (12)
Video - Content Protection
Supports HDCP 2.2.
User Interface - Control
Setup DIP-switches for EDID mode, audio settings, analog audio amplification. Contact closure switch for:output mute
User Interface - Indicators
Audio sources (IN and OUT), Audio output (DIG and ANALOG), and ON LEDs
Power - Consumption
5V DC, 370mA
Power - Source
5.2V DC, 4A
Environmental Conditions - Operating Temperature
0° to +40°C (32° to 104°F)
Environmental Conditions - Storage Temperature
-40° to +70°C (-40° to 158°F)
Environmental Conditions - Humidity
10% to 90%, RHL non-condensing
REGULATORY - Safety
CE,
REGULATORY - Environmental
RoHs, WEEE
Enclosure - Type
Aluminum
Enclosure - Cooling
Convection ventilation

Documents

Kramer FC-46H2 4K HDR HDMI Audio De-embedder — manufacturer spec sheet
Kramer FC-46H2 4K HDR HDMI Audio De-embedder — manufacturer manual
