Home / HDMI Cables / Kramer CRS-PlugNView-H-328 Active Optical Armored 4K HDMI Cable

Kramer

Kramer CRS-PlugNView-H-328 Active Optical Armored 4K HDMI Cable

Name: Kramer CRS-PlugNView-H-328 Active Optical Armored 4K HDMI Cable
Brand: Kramer
SKU: CRS-PLUGNVIEW-H-328
Price: 464.40 GBP
Availability: OutOfStock

£464.40inc. VAT

£387.00 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £154.80 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

1 Year Warranty Included

Key specifications

Cable Length328 ft

Video - Video ResolutionUp to 4K 60Hz 4:4:4 (3840x2160 & 4096x2160)

Video - Data RateUp to 18 Gbps

Video - Supported color spacesRGB, YCbCr, xvYCC, Adobe sRGB, sYCC601, BT.2020

Video - HDMI SupportHDCP 2.2, HDR-10, HLG, Dolby Vision™, EDID and CEC

Audio - Supported audio formatsDolby® Digital Plus, Dolby® TrueHD, DTS-HD Master Audio®, DVD Audio, SA-CD.

PHYSICAL - Connector-1 (source end)Male HDMI Type A, 24K gold-plated

PHYSICAL - Connector-1 (display end)Male HDMI Type A, 24K gold-plated

All 24 specifications

Description

CRS-PLUGNVIEW-H cable is a high-speed HDMI active optical cable (AOC) designed with heavy-duty durability perfectly suited for the harshest use and abuse expected from rental and road applications. CRS-PlugNView-H supports resolutions up to 4K@60 (4:4:4) 18 Gbps over long cable runs up to 100 meters without the need for an external power supply or additional extenders. Manufacturer configuration CRS-PlugNView-H-328: Active Optical Armored 4K HDMI Cable Manufacturer part number CRS-PLUGNVIEW-H-328.

Also in this range:CRS-PlugNView-H-262 Full specifications Datasheet Compare alternatives

Key features

High Resolution over Long Range - Active cable supports resolutions

High Resolution over Long Range - Active cable supports resolutions up to 4K@60 (4:4:4) over long cable runs up to 100 meters.

High Data Transfer Rate - Up to 18 Gbps.

No External Power Needed - Powers the active units via the HDMI

No External Power Needed - Powers the active units via the HDMI connector with a power consumption of only 0.25W:50mA @5V.

Comprehensive HDMI Support - HDCP 2.2, HDR-10, HLG, Dolby Vision™

Comprehensive HDMI Support - HDCP 2.2, HDR-10, HLG, Dolby Vision™, deep color, x.v.Color™, 5.1/7.1 lossless Dolby® TrueHD, DTS-HD Master Audio®, EDID and CEC.

Extremely Durable - integrated. stainless steel, corrugated tube with

Extremely Durable - integrated. stainless steel, corrugated tube with Kevlar reinforcement protects the internal optical fibers. A TPU jacket, heavy duty connectors and robust waterproof & impact resistant connector covers ensure high pulling strength and compression load. Dispensed from a solid, mobile plastic spool.

Varied Selection of Lengths - Available in versions from 10 to 100m

Varied Selection of Lengths - Available in versions from 10 to 100m (33 to 328ft).

Technical specifications

Display

Video - Video ResolutionUp to 4K 60Hz 4:4:4 (3840x2160 & 4096x2160)

PHYSICAL - Connector-1 (display end)Male HDMI Type A, 24K gold-plated

Connectivity

Video - Supported color spacesRGB, YCbCr, xvYCC, Adobe sRGB, sYCC601, BT.2020

Video - HDMI SupportHDCP 2.2, HDR-10, HLG, Dolby Vision™, EDID and CEC

Audio - Supported audio formatsDolby® Digital Plus, Dolby® TrueHD, DTS-HD Master Audio®, DVD Audio, SA-CD.

PHYSICAL - Connector-1 (source end)Male HDMI Type A, 24K gold-plated

PHYSICAL - HDMI Connector Dimensions27.8″x 0.78″x 0.38″ (70.7mm x 20mm x 9.8mm)

Power & Physical

PHYSICAL - Armor MaterialKevlar® and stainless steel

JACKET - MaterialTPU (thermoplastic polyurethane) - LSHF

JACKET - ColorBlack

General

Cable Length328 ft

Video - Data RateUp to 18 Gbps

PHYSICAL - Cable StructureHybrid Optical Fiber Cable

PHYSICAL - Fiber Optic50/125u OM3 fiber

PHYSICAL - Long term crush resistance1000N (100 kg, 225lbs)

PHYSICAL - Short term crush resistance2000N (204 kg, 450lbs)

PHYSICAL - Bending radius10 D (Dynamic) / 20 D (Static)

PHYSICAL - Long term tensile strength test400N (41 kg, 90lbs)

PHYSICAL - Short term tensile strength test800N (81 kg, 180lbs)

JACKET - Diameter5.8mm

Power - SourceNo external power supply is needed (draws current from the video source)

Environmental Conditions - Operating Temperature+32~+122˚F (0~+50˚C)

Environmental Conditions - Storage Temperature-40~+158˚F (-40~+70˚C)

Environmental Conditions - Operating Humidity10 ~ 80%

Documents

Kramer CRS-PlugNView-H-328 Active Optical Armored 4K HDMI Cable — manufacturer spec sheet

Kramer CRS-PlugNView-H-328 Active Optical Armored 4K HDMI Cable — manufacturer manual
