Home / Speakers / Kramer AW-6D All weather, 6.5", 2-way wall mounted PoE powered Dante speaker

Kramer

Kramer AW-6D All weather, 6.5", 2-way wall mounted PoE powered Dante speaker

Name: Kramer AW-6D All weather, 6.5", 2-way wall mounted PoE powered Dante speaker
Brand: Kramer
SKU: 60-000104
Price: 430.80 GBP
Availability: OutOfStock

£430.80inc. VAT

£359.00 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £143.60 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

1 Year Warranty Included

Key specifications

DESCRIPTIONAll weather, 6.5", 2-way wall mounted PoE powered Dante speaker.

Audio - Driver: LF Driver165 mm (6.5") driver with polypropylene cone and rubber surround

Audio - HF Driver25mm (1") soft dome with dampening, ferrofluid - cooled

Audio - Frequency characteristics Frequency Range (-10dB)60Hz-20kHz

Audio - Frequency Response (±3dB)84Hz-20kHz

Audio - Dispersion angle136deg. (1 kHz to 4 kHz)

Audio - Power handling: PoE++10W continuous / 30W peak

Audio - PoE+10W continuous / 20W peak

All 25 specifications

Description

Note: Download the Kramer Speaker Manager (.exe) and installation instructions from the Resources tab. Kramer AW-6D is a compact, high-performance 6.5" all-weather PoE-powered Dante speaker, engineered to deliver outstanding sound quality in both indoor and outdoor environments. Built to withstand harsh weather conditions while meeting indoor installation requirements, the AW-6D is the ideal choice for mixed-use installations where consistency in performance and design is key. Designed with the system integrator in mind, the AW-6D features a built-in amplifier, DSP, and mixer, enabling two-channel mixing and advanced audio tuning. Users can easily configure parametric EQ, high-pass/low-pass filters, input compression, output limiting, power management, as well as a "find me" tone trigger and firmware updates - all via Kramer's intuitive Speaker Utility software. The AW-6D includes a robust API for Kramer Control and third-party control systems, allowing remote control of volume, mute, and additional functions. The AW-6D is available in black or white, ensuring it fits seamlessly into any professional installation. Kramer lists this model in the following configurations: AW-6D-(W)-(SINGLE), AW-6D-(B)-(SINGLE). The distributor order code does not identify which configuration is supplied - please confirm when ordering. Manufacturer part number 60-000104.

Full specifications Datasheet Compare alternatives

Key features

Exceptional sound performance

IP66 rated for outdoor installations

Made from V-0 flame retardant materials. designed to comply with

Made from V-0 flame retardant materials. designed to comply with UL1480A for indoor installations

Supports PoE++/PoE+/PoE (auto-negotiate)

Built-in mixer, DSP, and amplifier for two-channel mixing, parametric

Built-in mixer, DSP, and amplifier for two-channel mixing, parametric EQ, High pass and low pass filters, input compressor, output limiter and advanced power settings

Features a built-in "Find Me" tone, making it easy to identify and

Features a built-in "Find Me" tone, making it easy to identify and locate individual speakers during installation or maintenance.

Power handling: 10W continuous / 30W peak

Sound Pressure Level (SPL): - Sensitivity (1W@1m, free field): 90dB

Sound Pressure Level (SPL): - Sensitivity (1W@1m, free field): 90dB SPL Maximum SPL: Continuous: 100dB SPL / Peak: 105dB SPL

Regulatory compliance: - IEC62368(CB) / CE LVD, UL62368 FCC+IC, BIS

Regulatory compliance: - IEC62368(CB) / CE LVD, UL62368 FCC+IC, BIS, RCM RoHS, REACH, WEEE

Industrial design: - wall-mounted, tool-less installation, available

Industrial design: - wall-mounted, tool-less installation, available in black & white colors, removable logo

Technical specifications

Connectivity

Audio - OSP (Output Shortcut Protection)Shuts down and restarts the amplifier if a shortcut is detected.

MECHANICAL - ConnectorsRJ-45, factory reset button

Audio

Audio - Driver: LF Driver165 mm (6.5") driver with polypropylene cone and rubber surround

Audio - HF Driver25mm (1") soft dome with dampening, ferrofluid - cooled

Audio - Frequency characteristics Frequency Range (-10dB)60Hz-20kHz

Audio - Frequency Response (±3dB)84Hz-20kHz

Audio - Dispersion angle136deg. (1 kHz to 4 kHz)

Audio - Power handling: PoE++10W continuous / 30W peak

Audio - PoE+10W continuous / 20W peak

Audio - PoE10W continuous / 10W peak

Audio - OCM (Over-Current Protection)Monitors input current and reduces gain to prevent damage

Audio - Sound Pressure Level (SPL): Sensitivity (1W@1m, free90dB SPL

Audio - Maximum SPLPoE++: Continuous: 100dB / Peak: 105dB

Power & Physical

MECHANICAL - MountingToolless mounting bracket

MECHANICAL - Dimensions Dimensions without Bracket201mm x 168mm x 320mm / 7.91" x 6.63" / 12.6"

MECHANICAL - Dimensions with Bracket201mm x 205mm x 320mm / 7.91" x 8.06" / 12.6"

MECHANICAL - Shipping dimensions (single unit)287mm x 235mm x 385mm / 11.3" x 9.3" x 15.2"

MECHANICAL - Shipping dimensions (2 units in a Master box)477mm x 296mm x 403mm / 18.8" x 11.7" x 15.9"

MECHANICAL - Shipping weight (single unit)3.5Kg / 7.7lbs

MECHANICAL - Shipping weight (Master box)7.4Kg / 16.3lbs

MECHANICAL - Material GrillAluminum, removable logo

General

DESCRIPTIONAll weather, 6.5", 2-way wall mounted PoE powered Dante speaker.

Built-in Protection OTM (Over-Temperature Protection)Automatically lowers volume if overheating is detected, restoring it once temperature normalizes.

MECHANICAL - Installation TypeSurface mounted vertical or horizontal

MECHANICAL - Baffle & back enclosureV-0 Flame Retardant

Documents

Kramer AW-6D All weather, 6.5", 2-way wall mounted PoE powered Dante speaker — manufacturer spec sheet

Kramer AW-6D All weather, 6.5", 2-way wall mounted PoE powered Dante speaker — manufacturer manual
