Home / Extenders / INOGENI U-BRIDGE 3 WP USB 3.2 Gen 1 Extender with Wall Plate

INOGENI

INOGENI U-BRIDGE 3 WP USB 3.2 Gen 1 Extender with Wall Plate

Name: INOGENI U-BRIDGE 3 WP USB 3.2 Gen 1 Extender with Wall Plate
Brand: INOGENI
SKU: U-BRIDGE-3-WP
Price: 1052.40 GBP
Availability: OutOfStock

£1,052.40inc. VAT

£877.00 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £350.80 with PayPal Pay in 3.

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Call 020 3815 8642

Return within 14 days

Installation services available Purchase orders: education customers only

5 Years Warranty Included

Key specifications

In the box1x PC HOST extender module; 1x DEVICE wall plate extender module; 1x USB 3.0 Type-C to Type-C cable; 1x USB 3.0 Type-C to Type-A cable; 1x USB-mini to USB-A cable; 1x installation guide; 2x mounting brackets for the power supply; 1x mounting clip for the PC HOST module; 2x 4-pos terminal blocks; 1x 2-pos terminal block; 8x black wood screws; 1x 1-gang drywall clip; 1x Decora plate (1-gang standard

Link TechnologyHDBaseT-USB3 over CAT6A U/FTP

RangeDirect connect up to 100 m (330 ft) over CAT6A U/FTP

USB SpeedsUSB 3.2 Gen 1 / USB 3.1 Gen 1 / USB 3.0 up to 5 Gbps; USB 2.0 up to 480 Mbps. USB-C DisplayPort Alternate Mode is not supported

PC Host Connectors1x USB Type-C receptacle with mounting screw hole, 1x RJ45, RS-232 passthrough

Device Wall Plate Connectors1x USB-A receptacle, 1x USB-C receptacle with mounting screw hole, 1x RJ45, RS-232 passthrough

Available CurrentUp to 1.8 A shared between ports

PC Host Dimensions7.0 cm x 9.7 cm x 2.3 cm (2.76" x 3.82" x 0.90"), 170 g (0.37 lb)

All 18 specifications

Description

The INOGENI U-BRIDGE 3 WP is a multi-device USB extender whose DEVICE module is built into a 1-gang wall plate, for permanent installation at the table or wall. It enables SuperSpeed USB 3.0 connections up to 100 m / 330 ft over a single CAT6A U/FTP cable using HDBaseT-USB3. The wall plate offers one USB-A and one USB-C port with up to 1.8 A shared, and the PC HOST module uses a lockable USB-C connector. RS-232 is passed through for VISCA or control.

Full specifications Datasheet Compare alternatives

In the box: 1x PC HOST extender module; 1x DEVICE wall plate extender module; 1x USB 3.0 Type-C to Type-C cable; 1x USB 3.0 Type-C to Type-A cable; 1x USB-mini to USB-A cable; 1x installation guide; 2x mounting brackets for the power supply; 1x mounting clip for the PC HOST module; 2x 4-pos terminal blocks; 1x 2-pos terminal block; 8x black wood screws; 1x 1-gang drywall clip; 1x Decora plate (1-gang standard format); 1x power supply 100-240 V AC input, 24 V 1.5 A DC output; international power adapter with country-specific cord

Call 020 3815 8642

Key features

Wall-plate device module

DEVICE module mounts in a 1-gang wall plate with a metal enclosure; a Decora-style plate (North American 1-gang format) is included and is replaceable for custom installations.

100 m SuperSpeed extension

HDBaseT-USB3 over a single CAT6A U/FTP cable up to 100 m (330 ft); USB 3.2 Gen 1 up to 5 Gbps, backward compatible with USB 3.1 Gen 1, 3.0 and 2.0.

Wall-plate ports

1x USB-A receptacle and 1x USB-C receptacle with mounting screw hole, up to 1.8 A shared between ports.

RS-232 passthrough

Passthrough serial connection for VISCA or control from either the PC HOST or the DEVICE wall plate.

Cable management

Integrated cable tie slot to secure the CAT6A cable to the device.

Technical specifications

Choose a section to view its specifications.

Connectivity (4)

USB Speeds: USB 3.2 Gen 1 / USB 3.1 Gen 1 / USB 3.0 up to 5 Gbps; USB 2.0 up to 480 Mbps. USB-C DisplayPort Alternate Mode is not supported
PC Host Connectors: 1x USB Type-C receptacle with mounting screw hole, 1x RJ45, RS-232 passthrough
Device Wall Plate Connectors: 1x USB-A receptacle, 1x USB-C receptacle with mounting screw hole, 1x RJ45, RS-232 passthrough
Consumed USB Tiers: Up to 2 tiers

Power & Physical (5)

PC Host Dimensions: 7.0 cm x 9.7 cm x 2.3 cm (2.76" x 3.82" x 0.90"), 170 g (0.37 lb)
Device Wall Plate Dimensions: 6.95 cm x 11.69 cm x 6.59 cm (2.74" x 4.60" x 2.59"), 190 g (0.42 lb)
Enclosure Material: PC Host: black anodised aluminium. Device wall plate: metal enclosure
Package Dimensions: 24.5 cm x 25 cm x 7.9 cm (9.65" x 9.84" x 3.11")
Package Weight: 1490 g (3.28 lb)

Certifications & Warranty (1)

Certifications: Device: FCC, CE, UKCA, RoHS, IEC62368, SoV, RCM, NOM. Power supply 36 W: FCC, CE, UKCA, CB, UL, TUV, EMC

General (8)

In the box: 1x PC HOST extender module; 1x DEVICE wall plate extender module; 1x USB 3.0 Type-C to Type-C cable; 1x USB 3.0 Type-C to Type-A cable; 1x USB-mini to USB-A cable; 1x installation guide; 2x mounting brackets for the power supply; 1x mounting clip for the PC HOST module; 2x 4-pos terminal blocks; 1x 2-pos terminal block; 8x black wood screws; 1x 1-gang drywall clip; 1x Decora plate (1-gang standard
Link Technology: HDBaseT-USB3 over CAT6A U/FTP
Range: Direct connect up to 100 m (330 ft) over CAT6A U/FTP
Available Current: Up to 1.8 A shared between ports
Power Supply: 100-240 V AC input, 24 V 1.5 A DC output; applied at either PC HOST or DEVICE module
Operating Temperature: 0 C to 50 C (32 F to 122 F)
TAA Compliant: Yes
Origin: Canada
