iiyama · iiyama ProLite LH60 signage series
iiyama LH6560UHS-B2AG 65-inch 4K commercial display
- Visa
- Mastercard
- American Express
- PayPal
Or 3 interest-free payments of £296.70 with PayPal Pay in 3.
Independently reviewed on TrustpilotSeen it cheaper? We price-match genuine like-for-like quotes. How it works
- In UK stock, ships from the UK
- UK manufacturer warranty
- UK-based engineers
- No import duty or customs charges
- GBP pricing, UK VAT invoices
A 65-inch 4K UHD signage display on a VA panel rated 5000:1, with Android 11 and iiSignage2 built in, a metal front and a 24/7 duty rating, drawing 59W typically for an energy rating of class C.
TopAV buying advice
Is the iiyama LH6560UHS-B2AG right for your reception?
The screen for a large foyer, read from across the room and running all year.
Shortlist the LH6560UHS-B2AG where the audience is further back than a few metres: a double-height reception, a long canteen, a large waiting area, a staff communications wall or a retail floor. It is the top size of iiyama's entry Android signage line, so the memory fit stays modest and the brightness is indoor-grade, but it has the highest static contrast of the family, the best energy rating in iiyama's signage range and a continuous duty rating. At 25.3kg it is a two-person lift onto a wall specified to carry it.
Reasons to shortlist it
- A 3840 x 2160 panel at 64.5 inches holds its detail at a distance, so a multi-zone dashboard, a full departure list or a price wall stays readable from the far side of a foyer instead of being cut down to a headline.
- The VA panel is rated at 5000:1 static contrast, the highest of this family, behind anti-glare coated glass with a 3H hard coating, so blacks stay black under low foyer lighting and the surface holds up against reflections and everyday marks.
- It draws 59W typically for an energy rating of class C, the best across iiyama's signage range, which is unusual for a panel this size and matters on a screen that is meant to run continuously for years.
- Android 11 runs on the display with iiSignage2 content management, EShare wireless sharing and FailOver input recovery, plus built-in 802.11ac wireless, so scheduled content reaches an estate over the network with no media player behind each screen.
- It is rated for 24/7 non-stop operation with a 50,000 hour MTBF figure, it is fanless and it has anti image retention, and a wall mounting kit is supplied in the box, so a flat-wall install needs nothing beyond the fixings for your wall type.
Check before you choose
- It carries 2GB of memory and 16GB of storage, the same fit as the smaller models in this family and modest for a 65 inch screen. Scheduled playlists, still artwork, looped video and simple zoned layouts run well on it; a heavy web dashboard, a live page with many concurrent zones or a complex browser application does not, and should run on an external player over HDMI.
- Only the front of the housing is metal, so this is a part-plastic chassis rather than the full metal build of the tiers above it in iiyama's range. It is a wall-mounted screen out of reach in most installs, but it is worth knowing where the display will be handled or is exposed to knocks.
- It is rated at 500 cd/m2, an indoor brightness, and the same figure as the smaller models here despite the larger panel. It suits a foyer, a canteen or a retail interior away from direct sun rather than a shop window or a glazed frontage with daylight on the screen. Measure the light at the position first.
See the 65" on your wall, to scale
On a phone, point your camera at the wall and see the 65" there at its real size. On a computer, upload a photo of the wall (or scan the QR code to take one with your phone and it will appear here) and drag the display around it to scale.
Not sure 65" is the right size for the room? The screen size calculator shows how far a 65" display carries for presentations, touch work and video.
What to plan before installing the LH6560UHS-B2AG
01
Position, wall and lift
The display is 1459.2 x 837.1 x 38.9mm and weighs 25.3kg, 36.4kg in its box, so plan a two-person lift and confirm the wall construction will carry it. Landscape and portrait are both supported; decide which before the content is designed. The mounting kit in the box matches the pattern listed in the specification table on this page.
02
Content and network
Decide whether the content runs on the built-in Android 11 system with iiSignage2 or on an external player over HDMI. With 2GB of memory on board, on-screen playback suits scheduled playlists and simple layouts; anything heavier belongs on a player. Agree wired LAN or 802.11ac wireless access with your IT team for scheduling and updates. iiyama lists a 400 x 400 mm VESA pattern.
03
Sources, control and power
Three HDMI 2.0 inputs take players, PCs and cameras, and FailOver switches to a backup source on its own when the main feed drops. Wired LAN and RS-232c are both available for remote power and monitoring, and the panel draws 59W typically with 0.5W in standby. Tell us if you want the mount or the installation quoted alongside the display.
Display price is for the panel. Installation and optional equipment are quoted separately. Purchase-order terms are available to approved education customers.
Build a quote you can compare
Include these details in your project enquiry so the quote covers the room as well as the screen.
- Number of displays, site postcode and required date.
- Furthest viewing distance and available wall space.
- Wall type, fixed mount or adjustable trolley, and cable routes.
- Laptop model, teaching apps, and any camera or Windows PC needs.
Ask for separate equipment, delivery, installation and licence costs, with a total including VAT. Confirm warranty coverage and any registration requirements before placing the order.
Complete your setup
What else the LH6560UHS-B2AG needs
The price above is for the display on its own. A wall mount or trolley is a separate purchase, and installation is quoted per site. Add what you need here and it joins the same basket.
Choose a mount
Professional Installation
Want it installed by our AV experts? We offer professional on-site installation including mounting, cable management, and system configuration.
Compare your shortlist
iiyama LH6560UHS-B2AG vs LH5560UHS-B2AG: 65-inch or 55-inch?
Choose around the room and the content people need to read, not the model number.
| Feature | LH6560UHS-B2AG | LH5560UHS-B2AG |
|---|---|---|
| Screen Size | 65 in | 55 in |
| Resolution | 3840 x 2160 (4K UHD) | 3840 x 2160 (4K UHD) |
| Brightness | 500 cd/m² | 500 cd/m² |
| Contrast Ratio | 5000:1 | 4000:1 |
| RAM | 2GB | 2GB |
| Power Consumption | 59W typical, 0.5W standby | 55W typical, 0.5W standby |
Specifications checked on 13 September 2026: iiyama ProLite LH6560UHS-B2AG (opens in a new tab) and iiyama VisionCare warranty table (opens in a new tab). Buying advice is based on published specifications; confirm the supplied configuration for either model.
See this 65-inch display to scaleiiyama LH6560UHS-B2AG specifications and documents
iiyama specifications (opens in a new tab)Choose a section to view its specifications.
Display (6)
- Screen Size
- 65 in
- Resolution
- 3840 x 2160 (4K UHD)
- Brightness
- 500 cd/m²
- Contrast Ratio
- 5000:1
- Aspect Ratio
- 16:9
- Backlight Life
- 50,000 hours (MTBF)
Connectivity (1)
- HDMI Inputs
- 3 (HDMI 2.0)
Audio (1)
- Speakers
- 2 x 10W
Power & Physical (5)
- Size Band
- 65 - 79"
- Power Consumption
- 59W typical, 0.5W standby
- VESA Mount
- 400 x 400 mm
- Weight
- 25.3 kg
- Shipping Weight
- 36.4 kg
Certifications & Warranty (1)
- Warranty
- 3 years iiyama VisionCare (onsite exchange, mainland UK and Ireland)
General (8)
- Orientation
- Landscape, portrait
- Operating System
- Android 11 (iiSignage2, EShare, FailOver)
- RAM
- 2GB
- Storage
- 16GB
- Glass
- Anti-glare coated, hard coating (3H), haze 25%
- Energy efficiency class
- C
- Manufacturer part number
- LH6560UHS-B2AG
- GTIN
- 4948570124459
Specifications are iiyama's published figures. Checked on 13 September 2026. The buying advice is our own, from specifying and installing equipment like this in UK classrooms and meeting rooms.
iiyama LH6560UHS-B2AG questions answered
Who is the iiyama ProLite LH6560UHS-B2AG best suited to?
It fits a large foyer, a long canteen, a busy waiting area, a staff communications wall or a retail floor, where people read the screen from well back. It is a commercial signage display rated for continuous operation with content management on board, not a television repurposed for the job.
Does it need a separate media player?
No. Android 11 is built in with iiSignage2 content management, EShare wireless sharing and FailOver input recovery, and 802.11ac wireless is on board, so a playlist can be scheduled and updated across sites over the network. Three HDMI 2.0 inputs are there if you would rather drive it from an external player or a PC, which is the better route for demanding content.
Is 2GB of memory enough on a screen this size?
It depends entirely on the content, not on the size of the panel. Scheduled playlists, still artwork, looped video and simple zoned layouts run comfortably on 2GB of memory and 16GB of storage. A live web dashboard, a page with many concurrent data zones or a complex browser application will not, and that content should be driven from an external player over HDMI.
How does its contrast compare with the smaller models?
This is the best of the family on that measure. The VA panel is rated at 5000:1 static contrast, against 4000:1 on the 43 and 55 inch models and 1200:1 on the 32 inch IPS model in the wider range. In a dimly lit foyer that shows as deeper blacks and more separation in dark artwork or video.
How much power does it use?
Around 59W in typical use, 0.5W in standby and 0.3W switched off, for an energy rating of class C. That is the best energy rating across iiyama's signage range and it is unusual on a panel this size: the 55 inch model in the same family draws 55W and is rated class E. On a screen that runs continuously, that difference is worth multiplying out.
Can it run all day, every day?
Yes. iiyama rates it for 24/7 non-stop operation with a 50,000 hour MTBF figure, it is fanless so it makes no noise in a quiet reception, and anti image retention protects the panel against fixed elements such as a logo or a header bar. That continuous duty rating is the practical difference between this and a consumer television.
Is it bright enough for a window?
No. At 500 cd/m2 this is an indoor panel, and it carries the same brightness figure as the smaller models in the family despite the bigger screen. It belongs in a foyer, a canteen or a retail interior away from direct sun. A window or a glazed frontage with daylight on the screen needs the high-brightness tier at around 800 cd/m2.
How heavy is it and what does the install involve?
The display weighs 25.3kg and measures 1459.2 x 837.1 x 38.9mm, and 36.4kg boxed. Plan a two-person lift and confirm the wall will carry it. A wall mounting kit is supplied, matching the pattern in the specification table, and at under 40mm deep the screen sits close to the wall once it is up. Keep the rear connections reachable for service.
Can it be mounted in portrait?
Yes. Both landscape and portrait orientation are listed for this model, so it works as a tall directory or wayfinding panel as well as a wide dashboard or menu wall. Set the orientation in the display settings and design the content to match before it goes on the wall, and check the mount you choose supports the rotated load.
Should I choose the 65 inch LH6560UHS-B2AG or the 55 inch LH5560UHS-B2AG?
Start with viewing distance: 65 inches keeps the same content readable from further back, which is the point in a large foyer or a long room. The 65 inch also has the higher static contrast, at 5000:1 against 4000:1, and the better energy rating, class C against class E, at 59W typical against 55W. The 55 inch is easier to handle at 17.6kg against 25.3kg and asks less of the wall. Everything else matches: 4K UHD, 500 cd/m2, 24/7 rated, fanless, Android 11 with iiSignage2 on 2GB of memory and 16GB of storage, metal front and a wall mounting kit in the box.
