iiyama · iiyama ProLite LH75 SDM signage series

iiyama LH5075UHS-B2AG 50-inch 4K commercial display

MPN: LH5075UHS-B2AG
£804.23inc. VAT
£670.19 ex. VAT
In stock, dispatched within 2 working days
1
  • Visa
  • Mastercard
  • American Express
  • PayPal

Or 3 interest-free payments of £268.08 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →
  • In UK stock, ships from the UK
  • UK manufacturer warranty
  • UK-based engineers
  • No import duty or customs charges
  • GBP pricing, UK VAT invoices
Return within 14 days
Installation services availablePurchase orders: education customers only
Free standard UK mainland delivery3-year manufacturer warranty

A 50-inch 4K UHD signage display on a VA panel rated 5000:1 for deep blacks, with an Intel SDM-L slot for an optional compute module, three HDMI 2.0 inputs and DisplayPort, and Android 11 with iiSignage2 on board for 24/7 operation.

TopAV buying advice

Is the iiyama LH5075UHS-B2AG right for your reception?

The deep-black screen of this range, for a dim foyer or an evening retail space.

Shortlist the LH5075UHS-B2AG for a reception, a foyer, a hotel lobby, a bar or a retail space where the lighting is low and the content leans on dark backgrounds, video or photography. It is the only size in this range built on a VA panel, and at 5000:1 static contrast it holds blacks in a way the IPS models here do not. Behind the panel is the feature that defines the range: an Intel SDM slot that takes a standards-based compute module inside the chassis, so the player can be yours rather than the display's. At 11.8kg it is a straightforward two-person wall install.

Reasons to shortlist it

  • The VA panel is rated at 5000:1 static contrast, more than four times the figure quoted for the IPS models in this range. On a dark background, a photograph or video content in a dim lobby, that is the difference between black and grey, and it is the single reason to pick this size over its neighbours on picture alone.
  • The Intel SDM-L slot takes a standards-based compute module inside the chassis, powered and cooled by the display. A site that will not run vendor Android on its network can put its own Windows or Linux player behind the glass, with no box on the bracket, no second mains socket and no exposed lead. The module is a separate purchase and does not come with the screen.
  • Three HDMI 2.0 inputs at up to 3840 x 2160 at 60Hz, with audio return channel on the third, plus a DisplayPort 1.2 input. Three HDMI is one more than most signage panels carry, so a lectern laptop, a room PC and a player can stay connected at once without a switcher.
  • Android 11 runs on the display with iiSignage2 content management, iiControl device management, iiShare and EShare wireless sharing and FailOver input recovery, on an A311D2 system on chip with a G52 MP8 graphics core, 4GB of memory and 32GB of storage, plus a micro SD card slot for local media. A schedule runs with no player box at all.
  • It is rated for 24/7 non-stop operation, is fanless and has anti image retention built in, in a metal housing with a 50,000 hour MTBF figure. That is the specification a screen needs when it is left on every hour of the year rather than switched on for meetings, and the fanless design keeps a quiet lobby quiet.

Check before you choose

  • The VA panel that gives this model its contrast also gives it a narrower usable viewing angle than the IPS models in the range, and a 9.5ms response time against their 8ms. If people will read the screen while walking past it at a sharp angle, the 55-inch IPS model may be the better choice even though its contrast figure is far lower.
  • The panel is 500 cd/m2, an indoor signage level. It is right for a foyer, a lobby, a canteen or a retail interior away from direct sun, and it is not the high-brightness tier meant for a shop window or a glazed frontage. In a dim space the deep blacks are an advantage, but in a sunlit one the brightness, not the contrast, is the limit.
  • The compute module for the SDM slot is bought separately, and this size takes the larger SDM-L format rather than the SDM-S used by the 43-inch model, so the two are not interchangeable. There is also no USB-C input, so a laptop with USB-C video output needs an adapter, and the two USB Type A ports are USB 2.0.

See the 50" on your wall, to scale

On a phone, point your camera at the wall and see the 50" there at its real size. On a computer, upload a photo of the wall (or scan the QR code to take one with your phone and it will appear here) and drag the display around it to scale.

Not sure 50" is the right size for the room? The screen size calculator shows how far a 50" display carries for presentations, touch work and video.

Loading the wall preview…

What to plan before installing the LH5075UHS-B2AG

01

Position, orientation and light

Decide landscape or portrait, since both are supported, and measure the daylight falling on the position against a 500 cd/m2 panel. Think about the viewing angle as well as the distance, because the VA panel rewards a straight-on sightline. The mounting pattern is in the specification table; the screen is 1122.7 x 643.6 x 55mm and weighs 11.8kg, which is a comfortable two-person lift.

02

Decide where the content runs

There are three routes: the built-in Android 11 system with iiSignage2, an Intel SDM-L compute module fitted inside the chassis, or an external source over HDMI or DisplayPort. Settle this with your IT team early, since it decides what has to sit on the network and who owns the player. Tell us if you want a compute module quoted with the display. iiyama lists a 400 x 400 mm VESA pattern.

03

Power, control and cabling

Allow a socket behind the mount for a 112W typical draw. Wired LAN, RS-232c on a 2.5mm sub-mini jack and an IR input are all available for control, and 802.11ac wireless is built in. Keep the rear connections reachable, and tell us if you want the mount or the installation quoted alongside the display.

Display price is for the panel. Installation and optional equipment are quoted separately. Purchase-order terms are available to approved education customers.

Build a quote you can compare

Include these details in your project enquiry so the quote covers the room as well as the screen.

  • Number of displays, site postcode and required date.
  • Furthest viewing distance and available wall space.
  • Wall type, fixed mount or adjustable trolley, and cable routes.
  • Laptop model, teaching apps, and any camera or Windows PC needs.

Ask for separate equipment, delivery, installation and licence costs, with a total including VAT. Confirm warranty coverage and any registration requirements before placing the order.

Complete your setup

What else the LH5075UHS-B2AG needs

The price above is for the display on its own. A wall mount or trolley is a separate purchase, and installation is quoted per site. Add what you need here and it joins the same basket.

Choose a mount

Professional Installation

Want it installed by our AV experts? We offer professional on-site installation including mounting, cable management, and system configuration.

Compare your shortlist

iiyama LH5075UHS-B2AG vs LH5575UHS-B2AG: 50-inch or 55-inch?

Choose around the room and the content people need to read, not the model number.

Published specifications for the LH5075UHS-B2AG and the LH5575UHS-B2AG
FeatureLH5075UHS-B2AGLH5575UHS-B2AG
Screen Size50 in55 in
Resolution3840 x 2160 @60Hz (8.3 megapixel 4K UHD)3840 x 2160 @60Hz (8.3 megapixel 4K UHD)
Brightness500 cd/m²500 cd/m²
Contrast Ratio5000:11200:1
Speakers2 x 10W2 x 10W
Power Consumption112W typical127W typical

Specifications checked on 13 September 2026: iiyama ProLite LH5075UHS-B2AG (opens in a new tab) and iiyama VisionCare warranty table (opens in a new tab). Buying advice is based on published specifications; confirm the supplied configuration for either model.

See this 50-inch display to scale

iiyama LH5075UHS-B2AG specifications and documents

iiyama specifications (opens in a new tab)

Choose a section to view its specifications.

Display (6)
Screen Size
50 in
Resolution
3840 x 2160 @60Hz (8.3 megapixel 4K UHD)
Brightness
500 cd/m²
Contrast Ratio
5000:1
Aspect Ratio
16:9
Backlight Life
50,000 hours
Connectivity (1)
HDMI Inputs
3 (HDMI 2.0, max 3840 x 2160 @60Hz, ARC on HDMI 3)
Audio (1)
Speakers
2 x 10W
Power & Physical (5)
Power Consumption
112W typical
VESA Mount
400 x 400 mm
Weight
11.8 kg
Shipping Weight
16.2 kg
Size Band
50 - 64"
Certifications & Warranty (1)
Warranty
3 years iiyama VisionCare (onsite exchange, mainland UK and Ireland)
General (10)
Energy efficiency class
G
Operating System
Android 11
Orientation
Landscape / Portrait
RAM
4GB
Storage
32GB
OPS Slot
No (Intel SDM slot for an optional compute module, module not included)
Glass
AG coated, matte finish, haze 25%
Duty Cycle
24/7
Manufacturer part number
LH5075UHS-B2AG
GTIN
4948570125241

Specifications are iiyama's published figures. Checked on 13 September 2026. The buying advice is our own, from specifying and installing equipment like this in UK classrooms and meeting rooms.

iiyama LH5075UHS-B2AG questions answered

Who is the iiyama ProLite LH5075UHS-B2AG best suited to?

It suits a reception, a foyer, a hotel or leisure lobby, a bar, a showroom or a retail interior where the lighting is low and the content is video, photography or dark-background design. It is a commercial display rated for continuous operation rather than a television, and it is the deep-black option in this range.

Why does this model have a different panel from its siblings?

iiyama specifies a VA panel here, where the 43, 55, 65, 75 and 86 inch models in the same range use IPS. VA gives much deeper blacks, quoted at 5000:1 static contrast against 1200:1 on the IPS models, while IPS holds colour better when you look at the screen from an angle. Neither is better in the abstract; it depends on whether your audience stands in front of the screen or walks past it.

What does the Intel SDM slot actually give me?

It is a standard slot for a plug-in compute module that sits inside the display and is powered by it. Fit one and the screen runs whatever that module runs, typically Windows, so the content platform is yours rather than the display maker's. In practice it removes the player box, its power supply and its cable from behind the screen, which matters on a flush wall mount in a public space. The module is bought separately.

Does it need a separate media player?

No. Android 11 is built in with iiSignage2 content management, iiControl, iiShare, EShare wireless sharing and FailOver input recovery, running on 4GB of memory and 32GB of storage with a micro SD card slot for local media. Three HDMI 2.0 inputs and a DisplayPort 1.2 input are there if you would rather drive it from a player, a PC or a compute module.

Why three HDMI inputs?

Because a signage screen often ends up as the only display in the space. Three HDMI 2.0 inputs plus DisplayPort 1.2 let a lectern laptop, a room PC and a player stay connected without a switcher, and FailOver moves to the next live input on its own when a source drops. Audio return channel sits on the third HDMI for feeding sound back to a soundbar.

Is it bright enough for a shop window?

No. At 500 cd/m2 this is the standard indoor signage level. It is right for a lobby, a corridor, a canteen or a retail interior, and a glazed shop front or any position with sun on the glass needs the high-brightness tier, which starts around 800 cd/m2. The deep blacks of this panel are most visible in a dim room, which is the opposite of a window position.

Can it run all day, every day?

Yes. iiyama rates it for 24/7 non-stop operation, it is fanless so it stays silent in a quiet lobby, and anti image retention is built in for content with fixed elements such as a logo or a header bar. The quoted MTBF figure is 50,000 hours excluding the backlight, and the operating temperature range is 0 to 40 degrees C.

Can it be mounted in portrait?

Yes. iiyama lists landscape and portrait orientation for this model, so it works as a tall directory or a poster-style panel as well as a wide screen. Set the orientation in the display settings and lay the content out to match before it goes on the wall, and check the bracket supports the rotated position.

How heavy is it and how is it mounted?

It measures 1122.7 x 643.6 x 55mm and weighs 11.8kg, 16.2kg in its box, so it is a comfortable two-person lift onto a flat wall mount. The mounting pattern is listed in the specification table on this page. Leave the rear connections reachable, and allow for the module bay if compute is going inside the chassis.

Should I choose the 50-inch LH5075UHS-B2AG or the 55-inch LH5575UHS-B2AG?

Choose by sightline as much as size. The 50-inch is the VA model, rated 5000:1, so blacks are far deeper for video and dark layouts viewed straight on. The 55-inch is IPS, rated 1200:1, and keeps colour usable from an angle, which suits a corridor or a screen mounted high. Both are 4K at 500 cd/m2 with 2 x 10W speakers, three HDMI inputs, Android 11, an SDM-L slot and 24/7 operation; the 55-inch weighs 15.2kg against 11.8kg and draws 127W against 112W.
