Epson ELPLX01S Ultra Short-Throw Projector Lens

Name: Epson ELPLX01S Ultra Short-Throw Projector Lens
Brand: Epson
SKU: V12H004X04
Price: 10385.74 GBP
Availability: OutOfStock

£10,385.74inc. VAT

£8,654.78 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Call 01342 580255

Return within 14 days

Installation services available Purchase orders: education customers only

Key specifications

TypeUltra short-throw projector lens

Lens ModelELPLX01S

Throw Ratio0.35:1

OffsetZero offset

Screen Size Range100 to 300 inches

F-number1.9

Focal Length5.8 mm

ColourBlack

All 10 specifications

Description

The ELPLX01S is Epson's ultra short-throw lens for its large-venue and installation projectors. At a 0.35 throw ratio with a zero-offset design, it puts a 100 to 300-inch image on the wall from almost directly beneath or above it — which is what makes projection viable in a low-ceilinged room, a rear-projection void or a stealth install where the projector must not be visible or in anyone's path.

Full specifications Compare alternatives

Zero offset is the part that matters practically: the lens projects square from its own centre line rather than requiring the projector to be offset above or below the screen, so mounting geometry gets much simpler. Wide lens shift gives the remaining adjustment.

The lens carries an integrated mount point for Epson's optional ELPEC01 external camera, which unlocks the automated setup tools on compatible projectors: colour calibration, screen matching across multiple units, tiling assist for edge blends and stacking assist. Epson lists it against Pro L Series, Pro G7000 and EB-PU Series projectors up to 8,500 lumens. Projector sold separately.

Call 01342 580255

Key features

0.35:1 throw with zero offset

A 100 to 300-inch image from almost directly beneath or above the screen, projecting square from the lens centre line.

Built for constrained rooms

Low ceilings, rear-projection voids and stealth installs where a standard lens would need an impossible throw distance.

ELPEC01 camera mount point

Fitting Epson's external camera unlocks auto colour calibration, screen matching, tiling assist and stacking assist.

Wide lens shift

Keeps the remaining alignment adjustment in the lens rather than forcing it into the mount.

Technical specifications

Display

Screen Size Range100 to 300 inches

Power & Physical

ColourBlack

General

TypeUltra short-throw projector lens

Lens ModelELPLX01S

Throw Ratio0.35:1

OffsetZero offset

F-number1.9

Focal Length5.8 mm

Camera MountIntegrated mount point for Epson ELPEC01 external camera

Compatible ProjectorsEpson Pro L Series, Pro G7000 Series and EB-PU Series up to 8,500 lumens

Call 01342 580255

Throw distance guide

With its 0.35:1 throw ratio, here's how far the projector needs to sit from the screen for common 16:10 image sizes. Try our throw distance calculator for your exact room.

Supported image: 100″ to 300″ diagonal

Try a size

100"

16:10 diagonal image


2.15 m × 1.35 m

Lens position

0.8 m

Side view: drag the projector to try its available lens positions

Position fits

Image size	Image dimensions	Lens distance
100"	2.15 m × 1.35 m	0.8 m
120"	2.58 m × 1.62 m	0.9 m
150"	3.23 m × 2.02 m	1.1 m
200"	4.31 m × 2.69 m	1.5 m
250"	5.38 m × 3.37 m	1.9 m
300"	6.46 m × 4.04 m	2.3 m

Planning from a real wall? Use the projector room planner to upload a photo, preview the image to scale and find projectors that fit within your maximum available space.

Distances are lens-to-screen, calculated from the manufacturer's stated throw ratio; allow for lens shift and mounting hardware. Always confirm against the manufacturer's installation guide before fixing mounts.
