Home / Projector Lenses / Epson ELPLX01WS Ultra Short-Throw Projector Lens (0.35:1, White)

Epson

Epson ELPLX01WS Ultra Short-Throw Projector Lens (0.35:1, White)

Name: Epson ELPLX01WS Ultra Short-Throw Projector Lens (0.35:1, White)
Brand: Epson
SKU: V12H004Y0A
Price: 7876.45 GBP
Availability: LimitedAvailability

£7,876.45inc. VAT

£6,563.71 ex. VAT

Low stock (1 left), order soon

Visa
Mastercard
American Express
PayPal

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

In UK stock, ships from the UK
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Call 020 3815 8642

Return within 14 days

Installation services available Purchase orders: education customers only

Key specifications

Marketing nameELPLX01WS

Epson part numberV12H004Y0A

Lens typeUltra short-throw, zero offset (white)

Zoom / focusPowered: focus / distortion

F-Number1.9

Focal length5.8 mm (0.23")

Connector24-Pin

Throw ratio0.35 (WUXGA / WXGA); 0.36 (XGA)

All 16 specifications

Description

The Epson ELPLX01WS is a powered ultra short-throw lens with a 0.35:1 throw ratio (0.36:1 at XGA) and a zero-offset design, finished in white. Epson sells it under the marketing name ELPLX01WS and the order part number V12H004Y0A.

Full specifications Datasheet Compare alternatives

Epson states the lens fits Epson Pro L Series, Pro G 7000 and EB-P Series projectors up to 8,500 lumens. Confirm the lens against your exact projector model before ordering.

Epson describes it as making it easy to display larger-than-life images while minimising shadows and light-path obstructions, and as ideal for narrow spaces and rear-projection applications, where the zero-offset design maximises display size in areas with low ceilings. It can be mounted in the ceiling with just the lens protruding.

Powered focus and distortion correction; F-number 1.9; focal length 5.8 mm; 24-pin connector. Lens shift is vertical +50% to +67% (horizontal centre) and horizontal -10% to +10% (at vertical +50%). It carries a mount point for the optional ELPEC01 external camera.

Note: Epson's own specification sheet is internally inconsistent on maximum image size — the feature bullets say 100" to 300" while the specification table says 100" to 1000". The table value is used above.

Call 020 3815 8642

Key features

0.35:1 ultra short throw

Throw ratio 0.35 at WUXGA/WXGA and 0.36 at XGA, with a zero-offset design.

Powered focus and distortion correction

Powered focus/distortion with powered lens shift, vertical +50% to +67% and horizontal -10% to +10%.

Stealth installation

Epson states the lens can be mounted in the ceiling with just the lens protruding, and pairs with a white projector.

ELPEC01 camera mount

Mount point for the optional ELPEC01 external camera, used for auto colour calibration, screen matching, tiling assist and stacking assist.

Technical specifications

Choose a section to view its specifications.

Display (1)

Screen size (projected distance): 100" to 1000"

Connectivity (1)

Connector: 24-Pin

Power & Physical (2)

Dimensions (W x D x H): 8.74" x 12.64" x 6.46"
Weight: 7.7 lb

Certifications & Warranty (1)

RoHS: Compliant

General (11)

Marketing name: ELPLX01WS
Epson part number: V12H004Y0A
Lens type: Ultra short-throw, zero offset (white)
Zoom / focus: Powered: focus / distortion
F-Number: 1.9
Focal length: 5.8 mm (0.23")
Throw ratio: 0.35 (WUXGA / WXGA); 0.36 (XGA)
Lens shift — vertical: +50% to +67% (H centre), powered
Lens shift — horizontal: -10% to +10% (vertical +50%), powered
Operating temperature: 0 to 45 °C (32 to 113 °F)
Compatible projectors: Epson Pro L Series, Pro G 7000 and EB-P Series projectors up to 8,500 lumens

Call 020 3815 8642

Throw distance guide

With its 0.35:1 throw ratio, here's how far the projector needs to sit from the screen for common 16:10 image sizes. Try our throw distance calculator for your exact room.

Try a size

100"

16:10 diagonal image


2.15 m × 1.35 m

Lens position

0.8 m

Side view: drag the projector to try its available lens positions

Position fits

Image size	Image dimensions	Lens distance
60"	1.29 m × 0.81 m	0.5 m
80"	1.72 m × 1.08 m	0.6 m
100"	2.15 m × 1.35 m	0.8 m
120"	2.58 m × 1.62 m	0.9 m
150"	3.23 m × 2.02 m	1.1 m

Planning from a real wall? Use the projector screen size calculator to upload a photo, preview the image to scale and find projectors that fit within your maximum available space. Replacing an existing projector? The projector replacement calculator checks whether this lens covers the ratio your current mount needs.

Distances are lens-to-screen, calculated from the manufacturer's stated throw ratio; allow for lens shift and mounting hardware. Always confirm against the manufacturer's installation guide before fixing mounts.

See it on your wall, to scale

Choose a picture size, then upload a wall photo, or scan the QR code and take it on your phone. We'll show the projected picture at its real size.

Picture size

100" 16:10 · 2.15 m × 1.35 m

On a computer, the QR code sends your phone photo straight back to this page.

Loading the wall preview…

Documents

Epson ELPLX01WS ultra short-throw lens specification sheet (PDF)
