Chief DVM27U4E TiLED dvLED Universal 27-Inch Wall Mount - 4 High Extender

The DVM27U4E is a direct-view LED extender, not an LCD bracket. It stacks above a TiLED Universal starter mount to add another four 27.5-inch class dvLED cabinets - 600 mm wide by 337.5 mm high - to the same column. The system is built bottom-up: the starter takes the load and every extender above it inherits that column's rating.

Adjustment matches the rest of the range: 8 mm of lateral shift, up to 50.8 mm of height adjustment and micro depth adjustment, so cabinets added higher up the wall land in pixel alignment with those below. Floating button-capture hardware and the included M6 and M8 button kits suit interlocking cabinets from most major dvLED manufacturers. Equipment depth range is 19.05 mm.

The extender sits 51 mm deep, needs a plywood-reinforced wall and ships at 6.1 kg. It is TAA compliant. Order it with a matching starter - it is not a standalone mount. Supplied by TopAV. Manufacturer part number DVM27U4E.
