Home / Amplifiers / Biamp Tesira AMP-450P

Biamp

Biamp Tesira AMP-450P

Name: Biamp Tesira AMP-450P
Brand: Biamp
SKU: 920-00010-00001
Price: 894.00 GBP
Availability: InStock

£894.00inc. VAT

£745.00 ex. VAT

In stock, dispatched within 2 working days

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £298.00 with PayPal Pay in 3.

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

In UK stock, ships from the UK
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

5 Years Warranty Included

Key specifications

Primary ApplicationConferencing

Height1.18-inches (30 mm)

Width7.67 inches (195 mm)

Depth4.72-inches (120 mm)

Weight1.54 lbs (0.7 kg)

PowerPoE+ (IEEE 802.3at Class 4 , 30W)

Power Indicator(s)Power Indicator (Green/Yellow/Red LED); Amp Status Indicator (Green/Yellow/Red LED)

OperatingOperating Power: 4Ω

All 23 specifications

Description

The Tesira AMP-450P is an AVB/TSN enabled, PoE+, 4-channel amplifier. The output channels are software configurable, including selectable power versus channel count. The AMP-450P includes an internal limiter, and is capable of providing 3 watts of continuous power to all four channels. The Tesira AMP-450P is also capable of operating in a burst mode to handle peak signals, providing up to 50 watts (4Ω) or 30 watts (8Ω) per channel.

Full specifications Datasheet Compare alternatives

The Tesira AMP-450P complies with the United States Trade Agreement Act (TAA), allowing it to be included in GSA Schedule contractors’ sales bids for the U.S. federal government.

Key features:

- 4-channel amplifier; 3 watts continuous power per channel

- Burst mode to handle peak signals; supports up to 50 watts (4Ω) or 30 watts (8Ω) per channel

- PoE+ powered

- Class-D amplifier topology

- Fanless operation

- Software-selectable power vs. channel count

- Includes internal limiter function

- Evaluated to the requirements of UL 2043 and is suitable for use in air handling spaces

- LED indicators for power/status and amp status

- Configurable via Tesira software

- CE marked, UL listed, and RoHS compliant

- 5-year warranty

- Compliant with the US Trade Agreement Act (TAA)

Key features

4-channel amplifier

4-channel amplifier; 3 watts continuous power per channel

Burst mode to handle peak signals

Burst mode to handle peak signals; supports up to 50 watts (4Ω) or 30 watts (8Ω) per channel

PoE+ powered

Class-D amplifier topology

Fanless operation

Software-selectable power vs. channel count

Includes internal limiter function

Evaluated to the requirements of UL 2043 and is suitable for use

Evaluated to the requirements of UL 2043 and is suitable for use in air handling spaces

Technical specifications

Choose a section to view its specifications.

Connectivity (2)

Power Output: Burst Power Output: 4 Ω (per channel) (per ANSI/CTA-2006-B @ 1kHz) = 50 8 Ω (per channel) (per ANSI/CTA-2006-B @ 1kHz) = 30 Continuous Power Output: Single Channel Driven, (4Ω, 8Ω): 15W Dual Channel Driven (4Ω, 8Ω): 7W Four Channel Driven, (4Ω, 8Ω): 3W
Network Connection(s): Gigabit Ethernet, RJ-45 (Cat 5e and above)

Audio (2)

Audio: 4-pin 5.08 mm Phoenix connectors
Dynamic Range: (20Hz-20kHz BW): > 90dB

Power & Physical (4)

Height: 1.18-inches (30 mm)
Width: 7.67 inches (195 mm)
Depth: 4.72-inches (120 mm)
Weight: 1.54 lbs (0.7 kg)

Certifications & Warranty (1)

Certifications: FCC Part 15B (USA) UL and C-UL listed (USA and Canada) CE Marked (Europe) KCC (Korea) RoHS Directive (Europe) Evaluated to the requirements of UL 2043 and is suitable for use in air handling spaces

General (14)

Primary Application: Conferencing
Power: PoE+ (IEEE 802.3at Class 4 , 30W)
Power Indicator(s): Power Indicator (Green/Yellow/Red LED); Amp Status Indicator (Green/Yellow/Red LED)
Operating: Operating Power: 4Ω
Channels: 4 Channels
Amplifier: Class D
Distortion: Intermodulation Distortion (SMPTE at continuous power): <0.3%
Cooling: Convection
TAA Compliant: TAA Compliant
Operating Environment: Ambient Operating Temperature Range: 32-104° F (0–40° C) Humidity: 0–98%, non-condensing Altitude: 0-6,600 feet (0–2000 Meters) MSL
Humidity: 0-95% relative humidity (non-condensing)
Altitude: 0-10,000 ft (0-3000m) MSL
THD+N: (20Hz-20kHz, at continuous power): < 0.3%
Frequency Response: (20Hz-20kHz): ± 1dB

Documents

Biamp Tesira AMP-450P datasheet
