Home / Amplifiers / ATEN AP206 2 x 60W Power Amplifier with DSP

ATEN

ATEN AP206 2 x 60W Power Amplifier with DSP

Name: ATEN AP206 2 x 60W Power Amplifier with DSP
Brand: ATEN
SKU: AP206
Price: 833.42 GBP
Availability: LimitedAvailability

£833.42inc. VAT

£694.52 ex. VAT

Low stock (1 left), order soon

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £277.81 with PayPal Pay in 3.

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

In UK stock, ships from the UK
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

2 Years Warranty Included

Key specifications

Rated Power60Wrms / 120Wpeak per Channel @4Ω; 120Wrms / 240Wpeak @70/100V Under Bridge Mode

DistortionTHD+N: <0.1%, 1kHz, 3dB before clipping

Frequency Response50~20kHz, +/-3dB @4Ω, 1W

SensitivityBalanced: +4dBu; Unbalanced: -10dBV; (0dBu=0.775Vrms, 0dBV=1Vrms)

Amplifier TypeClass D

Interfaces2 x 3-pin 3.5mm Euroblock (Bal/Unbal Line In)

ImpedanceBalanced: 20kΩ / Unbalanced: 10kΩ

Detect Threshold-50dBu

All 15 specifications

Description

The ATEN AP206 is a 2 x 60W Power Amplifier with DSP from ATEN's Professional Audio range, built for meeting rooms, lecture theatres and other installed systems where the audio chain has to be set once and then left alone.

Also in this range:AP212 Full specifications Datasheet Compare alternatives

Key figures from ATEN's specification: Rated Power: 60Wrms / 120Wpeak per Channel @4Ω; Interfaces: 2 x 3-pin 3.5mm Euroblock (Bal/Unbal Line In); Frequency Response: 50~20kHz, +/-3dB @4Ω, 1W; Distortion: THD+N: <0.1%, 1kHz, 3dB before clipping.

Control is over RS-232 on a 3-pin 3.5 mm terminal block for integration with a room control system, and the unit is FCC, CE and UKCA marked. Processing is handled by the on-board DSP, and ATEN lists short-circuit, over/under-voltage, high-frequency overload and thermal protection on the output stage.

Available to order from TopAV with ATEN's standard 24-month product warranty.

Key features

Rated power

60Wrms / 120Wpeak per Channel @4Ω; 120Wrms / 240Wpeak @70/100V Under Bridge Mode

Interfaces

2 x 3-pin 3.5mm Euroblock (Bal/Unbal Line In)

Frequency response

50~20kHz, +/-3dB @4Ω, 1W

Distortion

THD+N: <0.1%, 1kHz, 3dB before clipping

Technical specifications

Choose a section to view its specifications.

Connectivity (2)

Interfaces (Audio Outputs): Line Output: 1 x 5-pin 3.5mm Euroblock; Speaker Output: 1 x 4-pin 5.08mm Euroblock
Impedance (Audio Outputs): Lo-Z: 4Ω / Hi-Z: 70V (40Ω), 100V (80Ω); Line Output: 600Ω

Power & Physical (2)

Weight: 2.15 kg ( 4.74 lb )
Dimensions (L x W x H): 20.00 x 32.30 x 4.40 cm; (7.87 x 12.72 x 1.73 in.)

General (11)

Rated Power: 60Wrms / 120Wpeak per Channel @4Ω; 120Wrms / 240Wpeak @70/100V Under Bridge Mode
Distortion: THD+N: <0.1%, 1kHz, 3dB before clipping
Frequency Response: 50~20kHz, +/-3dB @4Ω, 1W
Sensitivity: Balanced: +4dBu; Unbalanced: -10dBV; (0dBu=0.775Vrms, 0dBV=1Vrms)
Amplifier Type: Class D
Interfaces: 2 x 3-pin 3.5mm Euroblock (Bal/Unbal Line In)
Impedance: Balanced: 20kΩ / Unbalanced: 10kΩ
Detect Threshold: -50dBu
Housing: Metal
Operating Temperature: 0~50℃
Storage Temperature: -20~60℃

Documents

ATEN AP206 datasheet (PDF, published by ATEN)
