Home / Microphones / Biamp Devio DTM-1

Biamp

Biamp Devio DTM-1

Name: Biamp Devio DTM-1
Brand: Biamp
SKU: 910-00434
Price: 951.60 GBP
Availability: OutOfStock

£951.60inc. VAT

£793.00 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £317.20 with PayPal Pay in 3.

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

2 Years Warranty Included

Key specifications

Primary ApplicationMeeting & Conference AV

Height2.2 inches (56 mm)

Width5.1 inches (130 mm)

Depth4.8 inches (121 mm)

Weight0.6 lbs (0.27 kg)

PowerPower Requirements: < 1 W, phantom powered from SCR-20/SCR-25 Max Distance Between Devices: 49 feet (15 meters) from SCR-20/SCR-25 to DTM-1; 49 feet (15 meters) for daisy-chained connections between DTM-1 microphones

TAA CompliantTAA Compliant

CertificationsCompliance: FCC Part 15B (USA) CE marked (Europe) UL and C-UL listed (USA and Canada) RoHS Directive (Europe)

All 13 specifications

Description

The Devio DTM-1 tabletop microphone includes beamtracking™ technology with three 120-degree zones, providing full 360-degree coverage of the meeting space. The DTM-1 microphone actively tracks and intelligently mixes conversations from around the table, allowing far-end conference participants to experience the conversation naturally.

Full specifications Datasheet Compare alternatives

The DTM-1 ships with a mounting plate for securing it to a table, and a second DTM-1 microphone can be added to the meeting room if needed.

The Devio DTM-1 complies with the United States Trade Agreement Act (TAA), allowing it to be included in GSA Schedule contractors’ sales bids for the U.S. federal government.

Key features:

- Beamtracking technology actively tracks and intelligently mixes conversations around the table

- Three 120-degree zones for 360 degrees of coverage

- Three LED mute status indicators

- Three capacitive touch mute buttons

- Two selectable directivity modes

- Mounting plate for secure installation included

- Easy single-cable installation process

- Additional RJ-45 for daisy-chain connection to another DTM-1 microphone (maximum of two microphones per daisy chain)

- 2-year warranty

- Compliant with the US Trade Agreement Act (TAA)

Key features

Beamtracking technology actively tracks and intelligently mixes

Beamtracking technology actively tracks and intelligently mixes conversations around the table

Three 120-degree zones for 360 degrees of coverage

Three LED mute status indicators

Three capacitive touch mute buttons

Two selectable directivity modes

Mounting plate for secure installation included

Easy single-cable installation process

Additional RJ-45 for daisy-chain connection to another DTM-1

Additional RJ-45 for daisy-chain connection to another DTM-1 microphone (maximum of two microphones per daisy chain)

Technical specifications

Choose a section to view its specifications.

Audio (1)

Audio: Microphone Technology: 8-Element Digital Array Frequency Response (150 Hz - 16 kHz): ± 3 dB Polar Pattern: Active Beamformed Sensitivity (94 dB SPL, 1 kHz): > 70 dB, A-Weighted Maximum SPL (at 0.5% THD): 106 dB SPL Dynamic Range (THD+N < 10%): 92 dB, A-Weighted Automatic Noise Suppression: 4 modes: Off, Low (Default), Medium, High Selectable Directivity Modes: 2 modes: Middle of Table (360°) or End of Table (120°) Mute Switching: 3 Capacitive Touch Buttons Indicators: Mute Indicator (Green/Red LED) Digital Interface: Custom/Proprietary Connectors: Two RJ-45: One between DTM-1 and Devio SCR-20/SCR-25; One between DTM-1 and additional DTM-1

Power & Physical (4)

Height: 2.2 inches (56 mm)
Width: 5.1 inches (130 mm)
Depth: 4.8 inches (121 mm)
Weight: 0.6 lbs (0.27 kg)

Certifications & Warranty (1)

Certifications: Compliance: FCC Part 15B (USA) CE marked (Europe) UL and C-UL listed (USA and Canada) RoHS Directive (Europe)

General (7)

Primary Application: Meeting & Conference AV
Power: Power Requirements: < 1 W, phantom powered from SCR-20/SCR-25 Max Distance Between Devices: 49 feet (15 meters) from SCR-20/SCR-25 to DTM-1; 49 feet (15 meters) for daisy-chained connections between DTM-1 microphones
TAA Compliant: TAA Compliant
Operating Environment: .
Ambient Operating Temperature Range: 32-104° F (0-40° C)
Humidity: 0-95% relative humidity (non-condensing)
Altitude: 0-6,600 ft (0-2000 m) MSL

Documents

Biamp Devio DTM-1 datasheet
