Home / Extenders / Yealink DE300 4K60 AV over IP Decoder with USB 3.0 Capture

Yealink

Yealink DE300 4K60 AV over IP Decoder with USB 3.0 Capture

Name: Yealink DE300 4K60 AV over IP Decoder with USB 3.0 Capture
Brand: Yealink
SKU: DE300
Price: 952.80 GBP
Availability: InStock

£952.80inc. VAT

£794.00 ex. VAT

In stock, dispatched within 2 working days

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £317.60 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

In UK stock, ships from the UK
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

Key specifications

Yealink part number1303135

4K@60Hz 44:4 with 16ms low latency

Decoding — Video ResolutionUp to 4K@60Hz

Chroma sampling4:4:4

Color Depth8-bit

Bit RateBelow 1Gbps

LatencyLess than one frame

Copy ProtectionHDCP2.3

All 27 specifications

Description

Engineered for high-performance AV environments, the DE300 utilizes 1Gbps Ethernet to provide 4K@60Hz video with 4:4:4 chroma sampling and ultra-low latency. Equipped with HDMI input/output, USB capture, RS232, IR, and multiple USB ports, it offers versatile control and connectivity options. Its scalable architecture supports AV signal distribution across multiple endpoints.

Full specifications Compare alternatives

Key features

4K@60Hz 4:4:4 with ultra-low latency transmission

Delivers 4K@60Hz 4:4:4 video with minimal latency - less than one frame delay.

USB 3.0 capture for MTR Core streaming

Equipped with a USB 3.0 capture card, the DE300 enables transmission of audio and video to a PC for content sharing. In meeting rooms it can output audio and video directly to the MTR Core as a secondary stream input.

Seamless 2 x 2 video matrix switching

The DE300's 2 x 2 video matrix simplifies video link management, offering switching between sources.

Multiple USB connectivity for local and remote control

Multiple USB interfaces offer local control with KVM devices like keyboards and mouse, while also enabling remote device control through USB over IP technology.

Comprehensive display control

Offers display control through RS232, IR, and CEC, enabling operations including power on/off and volume up/down for TVs and other devices.

HDCP 2.3 and plug-and-play deployment

The Yealink AVoIP Series supports the HDCP 2.3 standard. By connecting the encoder and decoder within the same local area network, the devices automatically identify and pair.

Technical specifications

Display

4K@60Hz 44:4 with 16ms low latency

Decoding — Video ResolutionUp to 4K@60Hz

Connectivity

Video — Input1 × HDMI input 1 × IP input

Output1 × HDMI output 1 × video capture output

Audio — Input1 × digital input, de-embedded from HDMI input 1 × IP input

Output1 × HDMI output 1 × video capture output 1 × stereo analog audio output (balanced or unbalanced)

Communication — NetworkProtocol: Multicast, DHCP, IPv4, HTTPSTransmission Distance: 100 meters / 330 feet over CAT5e and above

USBUSB 2.0 Type-C for computer management

RS232Bi-directional control, supports up to 115200 baud

IROut carrier frequency: 34kHz to 42kHz

USB-A Output5V/0.5A

Audio

Audio FormatLPCM multi-channel

Power & Physical

Color Depth8-bit

Power Supply — Power ConsumptionAverage: 8 W Peak: 8.5 W Standby: 5.4 W

Dimensions and Weight (W × D × H)Giftbox size: 259 × 193 × 124 mm Carton size: 635 × 265 × 209 mm Dimensions: 216 × 160 × 36 mm G.W/CTN: 9.9 kg N.W/CTN: 9.178 kg Weight: 1.24 kg Quantity/carton: 5 pcs

General

Yealink part number1303135

Chroma sampling4:4:4

Bit RateBelow 1Gbps

LatencyLess than one frame

Copy ProtectionHDCP2.3

AdvancedHDR

Power AdapterDC 12V/2A

PoEPoE+, 802.3at, class 4

Installation — Installation MethodRack installation Under-desk installation Flat installation

Hardware Interface — Hardware Interface1 × HDMI in 1 × HDMI out (supports CEC) 1 × USB 3.0 Type-B capture output 2 × USB 3.0 Type-A 1 × Audio out 1 × RS232 (each pin separately for TX, RX, and ground) 1 × IR Out (each pin separately for TX and ground) 1 × MGMT port 1 × PoE port 1 × power supply (12V/2A)

Other Information — Package Contents1 × DE300 1 × 1.8 m HDMI Cable 2 × 2.5 m USB 3.0 Type-B to Type-A Cables 1 × 1.0 m USB 3.0 Type-C to Type-A Cable (for management port) 2 × 5-Pin Male Phoenix Connectors (for analog audio and control) 1 × Infrared Emitter (for IR output control) 1 × Power Adapter (12V / 2A) 1 × Mounting Kit (for wall, flat surface, or rack installation). Includes mounting ears, rack connection piece, and screws. 3

Environmental FactorsOperating humidity: 10 - 95 % Operating temperature: -10 - +45°C Storage temperature: -30 - 70°C
